XYZ Printing da Vinci Super Manual de usuario
da Vinci Super
Quick Guide
Safety Precautions
Product instructions
Unboxing and Installation
Product specication
Function Operation and Instructions
Setting
Print
Supporting information
ENG
da Vinci Super 3D printer
September . 2017
da Vinci Super
P 2
da Vinci Super 3D printer
da Vinci Super
The manual is mainly intended for users to understand how to use the da Vinci Super 3D printer (“da Vinci Super”)
correctly. In this manual, users can learn more about the operating tips, application skills and maintenance of the da Vinci
3D printer.
For more information on the da Vinci Super 3D printer and the complete XYZprinting product line, please contact your
local dealer or visit the ofcial website of XYZprinting: http://www.xyzprinting.com.
Safety Precautions
Safety and Compliance
Important Safety Precautions
Please read through this manual and all safety precautions carefully before using, operating, unpacking, replacing,
removing any part or maintaining this product. Please also comply with the instructions of relevant safety
precautions.
●
●
Do not move the machine by yourself as it is heavy.
Do not place the printer on a soft or tilted surface. Otherwise, the machine will fall / ip over and become
damaged or cause personal injury.
Do not place the printer in a dusty, humid or outdoor environment.
Weak odors may be generated during the printing process. We recommend working in a well-ventilated
and open area to ensure operational comfort.
Do not leave the product or power cord to unattended children. Otherwise, personal injury or electric
shock might occur.
Use the provided power cord. Otherwise, incorrect grounding might lead to damage.
Do not place any liquid container on top of the product. Otherwise, overow or spill might go into the
machine and pose the risks of danger or safety concern.
Do not wipe the printer with alcohol or ammable chemicals. Otherwise, danger might occur.
Do not move the machine when it’s powered on.
Do not reach into the machine with your hands during operation. Otherwise, risks of impact from moving
printing parts or burn from high temperature might occur.
The machine becomes hot during operation and thus run in high temperature. Do not touch or replace
parts when they are not cooled down.
After startup, the parts in the machine will heat up or move depending on the user’s instructions. During
product operation, do not touch or block the operation of the parts.
Defect reparation must be carried out according to the contents of this instruction manual. Where the
defect cannot be repaired, please contact your printer dealer or the customer service center.
Trademarks
All trademarks and registered trademarks are the properties of their respective owners.
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
P 3
da Vinci Super 3D printer
da Vinci Super
Scraper Print head cleaning wirewire Feed hole cleaning wire Wire brush Gear cleaning brush
Product instructions
Accessory List
●
①5” color touch panel
②Rear feeding motor
③Print bed
④Filament holder
⑤Print head
⑥Power inlet
⑦USB socket
⑧Power switch
⑨USB Port
Precautions and Instructions of Maintenance Tools
Maintenance and Service
●
The following maintenance tool shall only be used with adult guidance or supervision. To prevent accidents,
do not allow a child to access maintenance tools without proper training.
• Make sure the maintenance work of the printer is carried out when the printing bed is cooled down.
• Filament residues generated during the course of printing may be stuck on the print head and gears of the printing module. The printing quality and
printer operation as well as the measurement of the printing bed may be affected. When this happens, clean the printing module with the wire brush.
• When printing is completed and the printing bed is cooled down to room temperature, the printed object can be removed from the printing bed with
the scraper.
When the printer needs to be serviced during the term of the warranty, it is recommended that the machine is packed with original packaging
materials prior to shipment. For this purpose, the packaging materials are better to be kept. If other packaging materials are used instead,
the printer might be damaged during printing. We reserve the right to assess relevant service fees.
2
7
8
9
6
USB drive
(including XYZware Pro installer,
da Vinci SUPER user manual and
XYZware Pro user manual)
Filament guide tubePLA lament Power cord USB cable
Front-feeding motor Wireless Top cover Mask tape
● ●● ● ●
● ● ●●
1
2
4
3
5
P 4
da Vinci Super 3D printer
da Vinci Super
Unboxing and Installation
1
3
6
9
12
2
4
7
10
13
5
8
11
Remove the plastic wrap and PP strap.
Remove the top cover box and the
packaging materials.
Place the printer on a table or platform
(please do not move the printer alone).
Remove the cable tie and foam situated
behind the front door.
Plug-in the power cord
Remove the top cover.
Remove the side of the carton .
Remove all tape from the body (4
pieces in total).
Insert the guide tube through the
top cover, and then insert one end
into the extruder module.
power on the printer.
Remove the assessory box.
Remove the foam next to the guide
screws on both sides, and then remove
the foam under the print bed. (total 4
pieces)
Insert the other end of the guide
tube into the feed module and
secure it tightly.
P 5
da Vinci Super 3D printer
da Vinci Super
Product specication
Printing technology
Dimensions (W*D*H)
Gross weight
Printing dimensions (W*D*H)
Print resolution
Automatic feed system
Printing bed heating
Automatic printing bed calibration
Print head diameter
Print material
Language
Connection method
Printing software
File format
Operation System
FFF (fused lament fabrication)
511*581*670 mm
35.5kg
Front-feeding motor: 290 x 290 x 300 mm
Rear-feeding motor: 300 x 300 x 300 mm
0.02 - 0.4 (mm)
Yes
Yes
Yes
0.4 (mm)
ABS / PLA / TPE / Tough PLA / PETG , open-lament
Multi language
USB 2.0 / Wi-Fi
XYZware Pro
.stl / .3w
Windows 7+ / Mac OS X 10.10 to 10.12
P 6
da Vinci Super 3D printer
da Vinci Super
Function Operation and Instructions
USB printing
●
1. Check if the USB drive is plugged to the machine.
2. Tap the USB Printing Menu in the main screen.
3. Select the le (.3w le) to print.
4. Check le information and tap “PRINT”.
P 7
da Vinci Super 3D printer
da Vinci Super
Loading the filament
●
1. Remove the side cover and place the lament on
the side of the machine.
2. Tap Filament Load and Unload in the main screen.
4. Conrm the operation.
7. Once the print head extrudes lament in a continuous thread,
loading is complete. After the lament is loaded, tap to conrm.
5. Insert the lament into the auto-feed module.
3. Tap Load.
6. The print head will pre-heat until it reaches 240°C
(XYZprinting PLA).
Once the set temperature is reached, the feeding motor will
feed the lament along the guide tube into the print head.
P 8
da Vinci Super 3D printer
da Vinci Super
Unloading the lament
●
1. Tap Filament Load and Unload in the main screen.
3. Conrm the unloading operation.
5. When the unloading operation is complete,
tap to conrm.
2. Tap “Unload” and conrm the operation.
4. Once the print head pre-heating reaches 240°C,
the feeding motor will unload the lament.
P 9
da Vinci Super 3D printer
da Vinci Super
Filament Installation (Rell)
●
1. Tap the icon when printing.
3. The nozzle will be preheated and the lament will be unloaded
automatically.
5. The nozzle will be preheated and the machine will notify you when to insert lament into the feed module.
6. Check if lament has been extruded from the nozzle, after conrmation, the printer will resume printing.
4. Replace the empty spool with a new one.
(please refer to the LOADING section in this
manual) and then tap "PROCEED".
2. Tap Rell Filament and then tap Rell.
da Vinci Super will prompt you to rell material.
P 10
da Vinci Super 3D printer
da Vinci Super
Temperature settings
Auto-detection (Auto)
Manual settings (Manual)
●
●
●
da Vinci Super allows the user to use different materials or third party laments. To satisfy the parameters or
characteristics of various laments, da Vinci Super allows the user to manually adjust extruder temperature,
printing bed temperature, and lament unloading temperature.
The printer will automatically read the NFC chip provided on the XYZprinting lament spool to automatically
adjust extruder temperature, printing bed temperature, and lament unloading temperature.
You can adjust the nozzle temperature, print bed temperature and nozzle unloading temperature, to suit you
lament type.
Print Bed
Temperature range 40~100℃170~300℃170~300℃
Nozzle Unloading
