XYZprinting 3D Printer

User Manual

Model : 3C10A

P 1 V1

English

P 2 V1

XYZprinting 3D Printer User Manual

Contents

1. Introducing the Product ............................................................................................ 3

1-1 Product appearance ............................................................................................4

1-2 Accessories..............................................................................................................5

1-3 Specifications ......................................................................................................... 5

2. Introducing product operations ............................................................................. 6

2-1 My Recipe ................................................................................................................ 8

2-2 Printing from the USB drive ...........................................................................10

2-3 Printing from the PC .........................................................................................11

2-4 Settings ...................................................................................................................12

2-5 Cartridge loading demonstration - play-doh..........................................15

3. Reminders .....................................................................................................................16

4. Safety regulations ......................................................................................................17

P 3 V1

XYZprinting 3D Printer User Manual

　　Technology is no longer limited to labs or factories. People of all ages, including

children, can now enjoy the fun made possible by technological developments.

　　 XYZprinting has continued to make remarkable achievements in the field of 3D

printing. In the past 2 years, we have successfully introduced 3D printing technologies

to family settings. In 2015, XYZprinting released 3D Printer never seen before in the

market. 3D printing technology can now be used to print different food ingredients

through an easy to use interface. XYZprinting 3D Printer allows users to simply press

a few buttons and create innovative work that integrates digital information with a di-

verse selection of materials that may include clay or the Play-doh is not only capable

of creating materials in the desired shape and form; it can also be used for post-pro-

duction processing and decorations. Inbuilt sensors allow the printer to accurately

measure the item's height and print the materials directly upon the item. Users may

print different materials in a variety of colors on the object to enhance visual aesthet-

ics.

　　The principle of 3D printing is to extrude materials from the cartridge in a

three-dimensional space, generating layers stacked upon each other to build the de-

sired form. Users can download pictures from the cloud database. Alternatively, they

may also use their own 3D graphics software to create their favorite images. Since the

emergence of this technology, digital technology enthusiasts will be able to demon-

strate their skills by actually creating their designs.

　　XYZprinting has identified market opportunities and lifestyle applications offered

by 3D printing technology, releasing a number of novel 3D printing products that

emphasize convenience and diversity. Our products extend to personal, family, and

educational settings. With the help of printing technology, everyone can become a

designer and creator. We hope that in the not too distant future, the once exclusive

space-age technology of 3D printing will become an integral part of every household.

1. Introducing the Product

P 4 V1

XYZprinting 3D Printer User Manual

USB port

Touch panel

Ingredient tube

room

Printing room

Power jack

USB port

1-1 Product appearance

P 5 V1

XYZprinting 3D Printer User Manual

Ingredient tube x 3, Screw cap

with 1 mm, 2 mm, and 4 mm

diameters (3 of each)

Printing bed

Tray

Power adapter

Power cord

USB cable

Printing room

front door

1-2 Accessories

1-3 Specifications

Printer

dimension

Printing

method

Extruder

diameter

Operations

Connection

Maximum

printing

dimension

Printing

thickness

Software

System

support

File format

150 x 200 x 150 mm

0.8-3.2mm

Slicing software from

XYZprinting

Win 7/Win 8

STL and XYZ format (.3wf)

471 x 480 x 610 mm

Extrusion and injection

(mutilple ingredients tubes)

1 / 2 / 4 mm (Optional)

5" touchscreen

USB 2.0

P 6 V1

XYZprinting 3D Printer User Manual

The power switch is located at the

side of the printer near the bottom.

Please make sure that the printer is

placed on a stable platform before

plugging it into a power source and

switching it on.

This printer model is capable of

being loaded with 3 ingredient tubes

for 3 different material types. Opening

the cover of the Ingredient tube room

will reveal 3 slots numbered 1, 2, and

3 from right to left. Ingredient tubes

must be loaded in a proper sequence.

You must start loading from slot 1 be-

fore proceeding to the slot on the left.

If the ingredient tubes are not installed

in this particular sequence (1 to 3), the

carrier will be unable to retrieve the

ingredient tubes (such conditions may

arise when: Only 1 cartridge is placed

in slot 2 or slot 3 while slot 1 is left

empty).

Plug in the power socket

and switch on the printer

The printing chamber cover

is provided together with the

printer. Please refer to the

picture and install the cover

securely.

Install the printing

chamber cover

Installing the cartridges

in the cartridge chamber

2. Introducing product operations

P 7 V1

XYZprinting 3D Printer User Manual

When printing, place the lining paper

on the printing bed. The user may also

use double-sided tape to temporarily

secure and smoothen the lining paper.

Note! Unevenness of the lining paper

will severely affect printing quality.

Placing the lining paper

on the printing bed

●Cartridges that have been detect-

ed by the printer will be colored

to provide easy identification. This

shows that the printer has already

detected the Ingredient tube.

Please refer to the steps below to combine the printing bed and tray

and load them into the printing room.

Loading the material plate and tray

Place the material

plate in the center

of the tray (the ori-

enting hole must be

pointing outside).

Orient the tray so

that it becomes

horizontal and slide

it into the printing

room (please make

sure that the tray can

slide back and forth

smoothly on the roll-

ing rail)

Please slide the front

edge of the tray

diagonally so that it

makes contact with

the rolling wheel.

●Once the Ingredient tube has been

installed, return to the Main Screen

to check if the printer has detected

the Ingredient tube.

Check if the printer has

detected the ingredient

tubes

P 8 V1

XYZprinting 3D Printer User Manual

Confirm the picture displayed on the

screen and press the print icon dis-

played at the bottom right corner.

Press the Print Icon

My Recipe

Select the option of "My Recipe" and

click on the picture of your desired

printing project. If you want to print

from a USB drive, please enter the

file name and skip to Step 14.

Print data can be derived from 3 sources:

●My Recipe

●USB

●Computer connection (for printing

using computer connections, please

refer to the software manual)

Select "My Recipe"

Return to the Main Screen and

press "Make" to start your printing

project.

Select "Make" from the

touch panel

2-1 My Recipe

P 9 V1

XYZprinting 3D Printer User Manual

Before pressing the button to initiate

printing, please check that: 1. The

Ingredient tubes have been installed

in the slots; 2. The lining paper has

been placed upon the material plate;

3. There are no Ingredient tubes on

the moving platform.

The touch panel shall display printing

time, remaining time, and percentage

progress.

Press "Start" to confirm

printing or "X" at the top left

corner to cancel the printing.

"Cartridge Replacement"

option

Start printing

After printing is complete, wait for the Ingredient tube

to be returned to its original location before retrieving

the finished product.

When materials run out during the

printing process, the user may use

the Cartridge Replacement option

to use materials from "Cartridge 1

Only" or "Cartridge 2&3".

"Cartridge 1 Only": The printer will return the spent Ingredient tubes to the

Ingredient tube room. The user may take out the Ingredient tube and place

a new Ingredient tubes in slot 1. The printer will then load a new Ingredient

tube and continue printing.

"Cartridge 2&3": The printer will return Cartridge 1 to its slot in the Ingredi-

ent tube room and automatically load Ingredient tube from slot 2 and slot 3

accordingly to continue printing.

P 10 V1

XYZprinting 3D Printer User Manual

Enter "My Recipe" folder

and click on the "pen and

paper" icon at the top right

corner to start editing

The "Option" screen will be

displayed. Select the "Add"

or "Remove" icons to add

or remove files respectively

from your USB.

Insert your USB drive.

"USB" will be shown in the

Main Screen

Ensure that the USB is successfully

read (an arrow will be displayed at

the bottom of the USB when suc-

cessfully read)

2-2 Printing from the USB drive
