Watchguard AP420 Instrucciones de instalación

WatchGuard

AP420

Hardware Guide

AP420

Access Point

About This Guide

Information in this guide is subject to change without notice. Companies, names, and data used in

examples herein are fictitious unless otherwise noted. No part of this guide may be reproduced or

transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express

written permission of WatchGuard Technologies, Inc.

Guide revised: 6/4/2020

mentioned herein, if any, are the property of their respective owners.

Complete copyright, trademark, patent, and licensing information can be found in the Copyright and

Licensing Guide, available online at https://www.watchguard.com/wgrd-help/documentation/overview.

About WatchGuard

WatchGuard® Technologies, Inc. is a global leader in network

security, providing best-in-class Unified Threat Management, Next

Generation Firewall, secure Wi-Fi, and network intelligence

products and services to more than 75,000 customers worldwide.

The company’s mission is to make enterprise-grade security

accessible to companies of all types and sizes through simplicity,

making WatchGuard an ideal solution for Distributed Enterprises

and SMBs. WatchGuard is headquartered in Seattle, Washington,

with offices throughout North America, Europe, Asia Pacific, and

Latin America. To learn more, visit WatchGuard.com.

For additional information, promotions and updates, follow

WatchGuard on Twitter, @WatchGuard on Facebook, or on the

LinkedIn Company page. Also, visit our InfoSec blog, Secplicity,

for real-time information about the latest threats and how to cope

with them at www.secplicity.org.

Address

505 Fifth Avenue South

Suite 500

Seattle, WA 98104

Support

www.watchguard.com/support

U.S. and Canada +877.232.3531

All Other Countries +1.206.521.3575

Sales

U.S. and Canada +1.800.734.9905

All Other Countries +1.206.613.0895

WatchGuard Technologies, Inc. i

Contents

WatchGuard AP420 Hardware Guide 1

Requirements 1

About Your Hardware 2

Hardware Specifications 2

Environmental Requirements 4

Hardware Description 5

Device Connections and Buttons 5

Device Indicators 7

Mounting Instructions 11

T-Rail Mount Installation 12

Flat Surface Bracket (Optional) 13

Connect the AP 14

Connect the AP for Link Aggregation 14

Ethernet Power Injector (Optional) 15

AC Power Adapter (Optional) 17

Notices 18

Safety Notices 18

Product Safety Certification 18

Safety Warning 18

Disclaimer 18

HINWEISE ZUR SICHERHEIT 18

Sicherheitshinweis 19

AVISO DE SEGURIDAD 19

Certificación de seguridad del producto 19

Advertencia de seguridad 19

FCC Certification 20

ii WatchGuard Technologies, Inc.

CE Notice 21

Industry Canada Certification 21

Europe – EU Declaration of Conformity (Wireless) 23

Brasil ANATEL 26

Mexico NOM 26

Taiwan Class B Notice 26

Taiwan NCC 26

Japan VCCI Notice (Class B ITE) 26

RoHS Statement 26

WEEE Statement 27

REACH Certificate of Compliance 27

WatchGuard Technologies, Inc. iii

WatchGuard AP420 Hardware Guide

WatchGuard AP420 devices are high performance, enterprise access points that feature 4x4:4 MU-MIMO

802.11ac Wave 2 capabilities with dual concurrent 5 GHz and 2.4 GHz radios supporting 802.11a/n/ac

Wave 2, 802.11b/g/n, and data rates of up to 1.73 Gbps and 800 Mbps, respectively. The AP420 also

contains a third 2x2 MIMO 802.11ac Wave 2 radio for dedicated multi-function security and wireless

network scanning (Wi-Fi Cloud mode only).

Requirements

There are two ways you can manage your AP420:

Total Wi-Fi and Secure Wi-Fi with WatchGuard Wi-Fi Cloud

A powerful cloud-based enterprise wireless management solution for AP configuration, security, and

monitoring.

Basic Wi-Fi with WatchGuard Firebox Gateway Wireless Controller

Local management, configuration, security, and monitoring of APs directly from your WatchGuard

Firebox. The WatchGuard Firebox requires Fireware v11.12.4 and higher.

The third radio is not available when the AP is managed locally with a Gateway Wireless Controller.

WatchGuard Technologies, Inc. 1

About Your Hardware

Hardware Specifications

Chipset Qualcomm QCA9994

Processor and RAM Qualcomm IPQ8064 1.4GHz dual core ARM processor with 256 MB

RAM and 128 MB Flash

Radio Type and

Frequency Band

2.4 GHz, 802.11b/g/n. Max data rate: 800 Mbps

5 GHz, 802.11a/n/ac. Max data rate: 1.733 Gbps

Third radio for dedicated RF and security scanning in Wi-Fi Cloud mode

Antenna 10 integrated omnidirectional antennas

n4 antennas: 2.4 GHz radio

n4 antennas: 5 GHz radio

n2 antennas: Third scanning radio

Ethernet Interface 1 x 10/100/1000 Mbps Gigabit Ethernet (LAN1) 802.3at PoE+ / 802.3af

PoE, PoE input voltage: 48V

1 x 10/100/1000 Mbps Gigabit Ethernet (LAN2) for a wired extension of

an SSIDor link aggregation.

1 x RJ45 serial console

RS232 Serial

Bits per second: 115200

Data Bits: 8, Stop Bits: 1

Parity: None, Flow Control: None

USB Port 1 USB 2.0 port (not in use)

Power Interface Power over Ethernet: 802.3at (PoE+) / 802.3af (PoE)

DC jack (6.3 mm connector): 12V DC input, 2.0A

Power Consumption Max: PoE+(802.3at): 21.5W

Max: PoE (802.3af): 12.95W

Max:DC power: 17.9W

Min: 8.1W

Average: 16W

WatchGuard AP420 Hardware Guide

2 WatchGuard Technologies, Inc.

WatchGuard AP420 Hardware Guide

MTBF Rating 1,320,756 hours at 25°C

662,479 hours at 40°C

Dimensions L = 220 mm (8.66")

W = 220 mm (8.66")

H = 57 mm(2.24")

Weight 1.3 kg(2.86 lbs)

WatchGuard Technologies, Inc. 3

Environmental Requirements

To safely install your WatchGuard AP, we recommend that you:

nInstall the device indoors

nMake sure the device has adequate clearance for air flow and cooling

nConnect the device to a surge-protected power supply to prevent damage from sudden power changes

Other environmental requirements:

Operating Temperature 0° to 40°C (32° to 104°F)

Operating Humidity 0% to 95% non-condensing

Non-operating Temperature -25° to 75°C (-13° to 167°F)

Non-operating Humidity 0% to 95%, non-condensing

WatchGuard AP420 Hardware Guide

4 WatchGuard Technologies, Inc.

WatchGuard AP420 Hardware Guide

Hardware Description

Device Connections and Buttons

Ethernet Network Interfaces

LAN1 (PoE+): Standard RJ45 connector that supports link speeds of 10/100/1000 Mbps and PoE+

connectivity.

LAN2: Standard RJ45 connector that supports link speeds of 10/100/1000 Mbps.

You can configure this interface as a wired extension for an SSID or for link aggregation. For more

information, see the

WatchGuard Wi-Fi Cloud Help

For APs managed locally by a Gateway Wireless Controller with Fireware v12.2.1 and higher, you

can bridge together the LAN ports on AP models that have two LAN interfaces. This enables you to

extend the wired network on the second LAN interface. For more information, see the

Fireware Help

Power Input

The WatchGuard AP420 can be powered by 802.3at PoE+ or 802.3af PoE on the LAN1 (PoE+)

interface, or an optional power adapter.

To make sure that LLDP-capable switches provide appropriate PoE+ power to the AP420:

nYou must enable LLDP on the switch

nDisable static allocation of maximum power of 30W (if previously configured)

For more information, see WatchGuard APs and PoE+ power with switches and LLDP.

The use of 802.3af PoE results in limited feature functionality of the AP:

nUSB port and LAN2 Ethernet extension port is disabled.

nThe 2.4 GHz radio is downgraded to 1x1 15dbm or lower, or as set in the device template.

nThe 5 GHz radio is downgraded to 1x1 15dbm or lower, or as set in the device template.

nThird scanning radio is downgraded to 1x1 with 12dBm transmit power. Lower PoE power results

in reduced performance and effectiveness of WIPS scanning and intrusion prevention functions.

WatchGuard Technologies, Inc. 5

Console Port

Standard RJ45 connector for serial console access.

USB Port

The USB port is currently not in use.

Reset Button

Resets the WatchGuard AP to factory-default settings. You must use a paper clip or other small

object to press the reset button through the small hole on top of the device.

To reset the device to factory-default settings, press and hold the reset button for up to 10 seconds

until all LEDs go off to indicate that the device has rebooted.

Kensington Security Lock Slot

Kensington security lock slot for use with a security cable to secure your device.

WatchGuard AP420 Hardware Guide

6 WatchGuard Technologies, Inc.
