Watchguard AP325 Instrucciones de instalación

WatchGuard

AP325

Hardware Guide

AP325

Access Point

About This Guide

Information in this guide is subject to change without notice. Companies, names, and data used in

examples herein are fictitious unless otherwise noted. No part of this guide may be reproduced or

transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express

written permission of WatchGuard Technologies, Inc.

Guide revised: 6/4/2020

mentioned herein, if any, are the property of their respective owners.

Complete copyright, trademark, patent, and licensing information can be found in the Copyright and

Licensing Guide, available online at https://www.watchguard.com/wgrd-help/documentation/overview.

About WatchGuard

WatchGuard® Technologies, Inc. is a global leader in network

security, providing best-in-class Unified Threat Management, Next

Generation Firewall, secure Wi-Fi, and network intelligence

products and services to more than 75,000 customers worldwide.

The company’s mission is to make enterprise-grade security

accessible to companies of all types and sizes through simplicity,

making WatchGuard an ideal solution for Distributed Enterprises

and SMBs. WatchGuard is headquartered in Seattle, Washington,

with offices throughout North America, Europe, Asia Pacific, and

Latin America. To learn more, visit WatchGuard.com.

For additional information, promotions and updates, follow

WatchGuard on Twitter, @WatchGuard on Facebook, or on the

LinkedIn Company page. Also, visit our InfoSec blog, Secplicity,

for real-time information about the latest threats and how to cope

with them at www.secplicity.org.

Address

505 Fifth Avenue South

Suite 500

Seattle, WA 98104

Support

www.watchguard.com/support

U.S. and Canada +877.232.3531

All Other Countries +1.206.521.3575

Sales

U.S. and Canada +1.800.734.9905

All Other Countries +1.206.613.0895

WatchGuard Technologies, Inc. i

Contents

WatchGuard AP325 Hardware Guide 1

Requirements 1

About Your Hardware 1

Hardware Specifications 1

Environmental Requirements 2

Hardware Description 3

Device Connections and Buttons 3

Device Indicators 5

Mounting Instructions 8

Flat Surface Bracket (Optional) 9

Connect the AP 11

Connect the AP for Link Aggregation 11

Ethernet Power Injector (Optional) 12

Power Adapter 13

Notices 14

Safety Notices 14

Product Safety Certification 14

Safety Warning 14

Disclaimer 14

HINWEISE ZUR SICHERHEIT 14

Sicherheitshinweis 15

AVISO DE SEGURIDAD 15

Certificación de seguridad del producto 15

Advertencia de seguridad 15

FCC Certification 16

CE Notice 17

ii WatchGuard Technologies, Inc.

Industry Canada Certification 17

Europe – EU Declaration of Conformity (Wireless) 18

Brasil ANATEL 21

Mexico NOM 21

Taiwan Class B Notices 21

Taiwan NCC 21

Taiwan RoHS 22

Japan VCCI Notice (Class B ITE) 22

RoHS Statement 23

WEEE Statement 23

REACH Certificate of Compliance 23

WatchGuard Technologies, Inc. iii

WatchGuard AP325 Hardware Guide

WatchGuard AP325 devices are intended for low to medium density environments and feature 2x2 MU-

MIMO with dual concurrent 5 GHz and 2.4 GHz radios supporting 802.11a/n/ac Wave 2, 802.11b/g/n, two

spatial streams, and data rates of up to 876 Mbps and 300 Mbps, respectively. The AP325 also contains a

third 2x2 MIMO 802.11ac radio for dedicated multi-function security and wireless network scanning (Wi-Fi

Cloud mode only).

Requirements

There are two ways you can manage your AP325:

Total Wi-Fi and Secure Wi-Fi with WatchGuard Wi-Fi Cloud

A powerful cloud-based enterprise wireless management solution for AP configuration, security, and

monitoring.

Basic Wi-Fi with WatchGuard Firebox Gateway Wireless Controller

Local management, configuration, security, and monitoring of APs directly from your WatchGuard

Firebox. The WatchGuard Firebox requires Fireware v12.1 and higher.

The third radio is not available when you manage the AP325 locally with a Gateway

Wireless Controller.

About Your Hardware

Hardware Specifications

This table shows the hardware specifications for the AP325.

Processor and RAM Qualcomm IPQ4028 717 MHz quad-core ARM processor with 256 MB RAM

and 64 MB Flash

Radio Type and

Frequency Band

2.4GHz, 802.11b/g/n. Max data rate: 300 Mbps

5GHz, 802.11a/n/ac. Max data rate: 876 Mbps

Third radio for dedicated RF and security scanning in Wi-Fi Cloud mode

only.

Antenna 6 integrated omnidirectional antennas

n2 antennas: 2.4 GHz radio

n2 antennas: 5 GHz radio

WatchGuard Technologies, Inc. 1

n2 antennas: Third scanning radio

Ethernet Interface 1 x 10/100/1000 Mbps Gigabit Ethernet (LAN1)

802.3at/af PoE for a wired LAN connection through a switch or hub.

1 x 10/100/1000 Mbps Gigabit Ethernet (LAN2) for a wired extension of an

SSID, VLAN extension, or link aggregation.

Power Interface Power over Ethernet: 802.3at (PoE+) / 802.3af (PoE)

DC jack (6.3mm connector): 12V DC input, 1.5A

Power

Consumption

Max: PoE+ (802.3at): 16W

Max:PoE (802.3af): 12.95W

Max: DCpower: 16W

Min: 6.5W

Average: 13.8W

MTBF Rating 1,081,559 hours at 25°C

535,205 hours at 45°C

Dimensions L = 196 mm (7.72")

W = 196 mm (7.72")

H = 43 mm(1.69")

Weight 850g (1.87lb)

Environmental Requirements

To safely install your WatchGuard AP, we recommend that you:

nInstall the device indoors.

nMake sure the device has adequate clearance for air flow and cooling.

nConnect it to a surge-protected power supply to prevent damage from sudden power changes

Other environmental requirements:

Operating Temperature 0° to 40°C (32° to 104°F)

Operating Humidity 0% to 95% non-condensing

Non-operating Temperature –20° to 85°C (-4° to 185°F)

Non-operating Humidity 5% to 95%, non-condensing

WatchGuard AP325 Hardware Guide

2 WatchGuard Technologies, Inc.

WatchGuard AP325 Hardware Guide

Hardware Description

Device Connections and Buttons

This table shows the device connections and buttons on the AP325.

Ethernet Network Interfaces

LAN1: Standard RJ45 connector that supports link speeds of 10/100/1000 Mbps and PoE

connectivity.

LAN2: Standard RJ45 connector that supports link speeds of 10/100/1000 Mbps. When managed by

Wi-Fi Cloud, you can use this interface for a wired extension of an SSID, a VLAN extension, or link

aggregation. For more information, see the

WatchGuard Wi-Fi Cloud

Help.

For APs managed locally by a Gateway Wireless Controller with Fireware v12.2.1 and higher, you

can bridge together the LAN ports on AP models that have two LAN interfaces. This enables you to

extend the wired network on the second LAN interface. For more information, see the

Fireware Help

Power Input

You can power the WatchGuard AP325 by 802.3at PoE+ or 802.3af PoE on the LAN1 (PoE)

interface, or an optional power adapter.

In 8.8.2 and higher, the AP can use 802.3af PoE with no loss in functionality.

In 8.8.1 and lower, the use of 802.3af PoE results in limited feature functionality of the AP:

nUSB port and LAN2 Ethernet extension port are disabled.

nThe 2.4 GHz radio is downgraded to 1x1 12dbm or lower, or as set in the device template.

nThe 5 GHz radio is downgraded to 2x2 12dbm or lower, or as set in the device template.

nThird scanning radio is downgraded to 1x1 with 12dBm transmit power. Lower PoE power

results in reduced performance and effectiveness of WIPS scanning and intrusion prevention

functions.

WatchGuard Technologies, Inc. 3

USB Port

The USB port is currently not in use.

Reset Button

Resets the WatchGuard AP to factory-default settings. You must use a paper clip or other small

object to press the reset button through the hole.

To reset the device to factory-default settings, while the AP is powered on, press and hold the reset

button for up to 10 seconds until all LEDs go off to indicate that the AP has rebooted.

If you press the reset button while the AP is not powered on or is booting, the reset

button will have no effect.

WatchGuard AP325 Hardware Guide

4 WatchGuard Technologies, Inc.

WatchGuard AP325 Hardware Guide

Device Indicators

The LED device indicators show the status of the AP.

WatchGuard Technologies, Inc. 5

The AP325 operates in AP combo mode where the 2.4 GHz and 5 GHz radios work in AP mode to

broadcast Wi-Fi, while the third radio operates in WIPS (Wireless Intrusion Prevention System) sensor

mode (Wi-Fi Cloud management only).

Device Indicators in AP Firmware 8.8.1 and Higher

LED Status Description

Power Off Powered off.

Solid

Green

Powered on.

Flashing

Green

APcannot connect to Wi-Fi Cloud or the Gateway Wireless Controller.

Flashing

Amber

APdid not receive an IP address from the DHCPserver.

LAN1

(PoE)

Off No Ethernet link.

Solid

Green

Network interface is up and connected at 10/100/1000 Mbps.

LAN2 Off No Ethernet link.

Solid

Green

(Wi-Fi

Cloud

mode)

8.8.2 and higher: For APs with additional LAN ports, interface will be green if the

interface is up and a wired extension or link aggregation is enabled on the

interface in Wi-Fi Cloud.

8.8.1: Network interface is up and connected at 10/100/1000 Mbps.

Solid

Green

(Local

mode)

Network interface is up and connected at 10/100/1000 Mbps.

2.4

GHz

and

5 GHz

radios

Off 8.8.2 and higher: No SSID enabled on the radio.

8.8.1: Wireless radio is inactive.

WatchGuard AP325 Hardware Guide

6 WatchGuard Technologies, Inc.
