FD8136 – 2012/04

FD8136 World Smallest Network Fixed Dome Camera

Commercial Series, H.264, 1-Megapixel, Stylish Design, Easy & Quick

Installation

Architectural and Engineering Specification

2.01 Manufacturer

A. VIVOTEK Inc.

6F, No.192, Lien-Cheng Rd.

Chung-Ho, New Taipei City, Taiwan 23553

Phone +886 8245-5282

Fax +886 8245-5532

Email [email protected]

B. Manufacturer shall warrant the camera to be free from defects in

material and workmanship for two years from the purchase date.

2.02 General Network Camera Descriptions

A. The product represents the next-generation in video quality in network

cameras. With its 1-Megapixel resolution users will be able to

experience the utmost in picture clarity. The camera supports the

industry-standard H.264 compression technology, drastically reducing

file sizes and conserving valuable network bandwidth. With MPEG-4 and

MJPEG compatibility also included, video streams can be transmitted

in any of these formats for versatile applications.

B. The camera has a built-in web server for users to configure the camera

to meet different purposes. It is IEEE 802.3af compliant

Power-over-Ethernet ready, and with such feature the installation can

be very convenient.

C. The camera shall have on-board storage supporting Micro SD/SDHC cards.

2.03 General Camera Requirements

A. The H.264 camera specified shall incorporate a progressive scan CMOS

imager with a 1/4-inch optical format, not less than 1280(H) x 800(V)

pixels.

B. The image resolution shall be no less than 1280(H) x 800(V) pixels.

Users can specify many resolutions smaller than default for a specific

purpose.

C. The camera shall produce a frame rate of 30 frames per second (fps)

at resolution of 1280(H) x 800(V) 16:10 aspect ratio in H.264 and MJPEG

codec.

D. The camera shall produce a frame rate of 25 frames per second (fps)

at resolution of 1280(H) x 800(V) 16:10 aspect ratio in MPEG-4 codec.

E. Minimum light requirement to produce an image shall be approximately

0.45 lux with an F1.8 lens 50 IRE.

FD8136 – 2012/04

F. The camera shall provide automatic white balance, automatic exposure,

automatic gain control, automatic electronic shutter, backlight

compensation, and motion detection. The camera shall also provide

manual white balance, manual exposure, manual gain control and manual

shutter speed.

G. The camera shall have at least 128MB of RAM and 16MB of flash memory

and will use MJPEG compression for standard web browsers. H.264 and

MPEG-4 video can be available by ActiveX, ActiveX in web pages,

Quick-time Player, Real Player and VLC Player. In cell phone, the

camera is accessible by web browsers, or any built-in player that

supports RTSP and MPEG-4 video.

H. The camera shall provide a RTSP/RTP/RTCP protocol video output via an

Ethernet connection.

I. The camera shall provide on-screen text displays.

J. Viewer, Operator and Administrator password protection levels shall

be provided.

K. A mechanical reset button shall be provided to return the camera to

factory default settings.

L. The camera shall provide lens options with different focal lengths of

2.5mm / 3.6mm / 6mm.

M. The camera shall provide board lens, fixed focal, f=2.5 mm(F2.0), f=3.6

mm(F2.0) and f=6 mm(F1.8).

N. The camera shall support privacy masks.

O. The camera shall provide motion detection (3 configurable windows) and

offer “profile” capability to configure the different motion detection

settings.

P. The camera shall provide built-in microphone.

Q. The camera shall provide ePTZ capability for data efficiency. 4x

Digital Zoom shall be provided.

R. The camera shall provide camera tampering detection.

2.04 Camera Networking Requirements

A. The camera shall incorporate a built-in web server.

B. Camera functionality shall be available to users running versions of

Internet Exploreror Mozillareleased after January 1, 2010.

C. The camera shall provide integrated support for IPv4, IPv6, TCP/IP,

IGMP, DHCP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, DDNS, DNS, NTP, SNMP, ,

SMTP, FTP, PPPoE, CoS, QoS, and 802.1X.

D. The camera shall be ONVIF compliant.

FD8136 – 2012/04

E. No unique or proprietary client software shall be required for viewing

or controlling the camera.

F. The camera shall be configurable and users may modify the camera’s web

pages according to a specific purpose.

G. The camera shall be able to transmit H.264/MPEG4 streaming over HTTP

to pass the firewall protection (RTSP over HTTP).

H. The camera shall be able to transmit H.264/MPEG4 streaming over UDP

for time-sensitive applications to achieve a better real-time

Streaming.

I. The camera shall be able to transmit H.264/MPEG4 streaming over TCP

for applications where the video quality is a top-priority, preventing

packet losses.

J. The camera shall support encrypted data transmission (HTTPS) to

increase the overall security.

K. The camera shall allow the live viewing for up to 10 clients

simultaneously.

L. The camera shall offer at least 2 simultaneous streams.

2.05 Camera Audio/Video Requirements

A. The camera shall provide 4~8000 Kbps H.264 video bit rate.

B. The camera shall support H.264 Main Profile, H.264 Baseline Profile,

H.264 High Profile.

C. The camera shall provide 9 levels of exposure compensation.

D. The camera shall able to adjust the minimum and maximum of gain control.

E. The camera shall provide shutter time from 1/5 sec.to 1/32000 sec..

F. The image shall have up to 713 TVL.

G. The camera shall provide SNR of 62 dB.

H. The camera shall able to provide the audio codec G.711 which is most

widely supported.

I. The camera shall provide 2 audio quality levels for G.711.

J. The camera shall provide the possibility to sync the frequency with

the power line frequency to eliminate a flickering image.

K. The camera shall be able to provide the possibility to flip and/or

mirror the video image for increase the flexibility of the

installation.

FD8136 – 2012/04

L. The camera shall provide scheduled profile settings for the exposure

management to offer different exposure settings for day and night.

2.06 Connectors

A. RJ-45 Ethernet connector (IEEE 802.3af, Class 1 PoE compliant)

B. One digital input .

2.07Electrical Specifications

A. Power Consumption: IEE 802.3af Power-over-Ethernet on CAT-5 cable

(maximum 3.84 W)

2.08 Mechanical Specifications

A. Weight: 143g

B. Dimensions: (Ø) 90 mm x 50 mm

2.09 Environmental Specifications

A. Operating temperature range: 0oC to 50oC (32oF to 122oF)

2.10 Certifications and Approvals

A. Electromagnetic Compatibility

a. Emissions:

i. FCC, Class B

ii. CE

iii. LVD

iv. VCCI

v. C-Tick

B. RoHS

a. All material and/or components used in the manufacture of the

product shall be in compliance with the EU Directive 2002/95/EC

Restriction of Hazardous Substance (RoHS).
