Vello BG-C4 Manual de usuario

BG-C4

BAT TERY GRIP

Designed for the Canon EOS 7D

DSLR Camera

USER’S MANUAL

Introduction

Thank you for choosing Vello and congratulations on

your new BG-C4 battery grip purchase. Enjoy the many

benefits that a battery grip offers, such as extended

shooting time and more control and comfort when

shooting in a vertical (portrait) orientation.

The Vello BG-C4 is compatible with the Canon EOS

7D DSLR camera. The BG-C4 accepts two Canon LP-

E6 rechargeable batteries, or six AA batteries (alkaline,

Ni-MH, lithium, or nickel-manganese) can be used

instead for added convenience. The BG-C4 is equipped

with an alternate shutter-release button, AF start

button, AF point selection, AE lock/FE lock button,

multi-function button, and main dial for shooting in a

vertical position.

Please read through this entire manual before

using the BG-C4 battery grip.

Precautions

1. The BG-C4 should only be used with compatible

devices specified in this manual.

2. Only use with batteries and battery holders

recommended in this manual.

3. Cover the power terminals with the contact

cap when the BG-C4 is not in use. This prevents

electrical shorts caused by metal objects touching

the power terminals.

4. When the battery holder is removed from the

grip, remove the batteries or place the holder in

a container to prevent electrical shorts caused by

contact with other metal objects.

5. If you notice smoke, an unusual smell or noise from

the battery pack, discontinue use immediately.

Remove the batteries and take the device to a Vello

authorized reseller.

6. Turn the grip power off when not shooting

vertically.

7. The battery level may not display properly if

batteries are inserted before mounting the grip.

8. Remove batteries from the grip when not in use.

9. Do not attempt to disassemble.

10.Avoid water or extreme humidity and keep in a dry

and cool place.

11. Keep out of reach of children.

OVERVIEW INTRODUCTION

ASSEMBLY

Overview



Contact Cap

Protects grip contacts. Keep covered

when the grip is not in use.

2Electrical Contacts

Communicates with the camera

electronics.

3Camera Battery Chamber Cover

Holder

Stores the cover when the grip is

mounted.

4Battery Compartment Lever

Locks and unlocks the battery

compartment door.

5Mounting Screw

Aligns with the camera’s tripod socket.

6Guide Pin

Helps align the camera to the grip.

7Attachment Wheel

Secures the grip to the camera.

Battery Release Levers

Secures the batteries when inserted.

Press both levers to release batteries.

9DC Coupler Cord Mount

Groove for use with the Canon AC

Power Adapter (ACK-E8)

0

Battery Compartment Cover

 Battery Compartment

Holds up to two Canon LP-E6

batteries.

2 AF Point Selection/Magnify Button*

3

AE Lock/FE Lock/Index/Reduce

Button*

4 AF Starter Button

5 Shutter-Release Button*

6 Multi-Function Button

7 Main Dial*

8 Grip Power ON/OFF

9 Hand Strap Mount

20 Tripod Socket

21 BG-HC42 Battery Holder

Holder for six AA batteries

* Performs the same function as on the

camera.

OVERVIEW INTRODUCTION

ASSEMBLY

Attaching The Grip

1. Ensure that the power is

turned off on the camera

and that the power switch

is set to OFF on the battery

grip.

2. Remove the battery

from the camera battery

compartment.

3. Open the camera battery

chamber cover and

remove as indicated above.

4. To prevent loss, place the

camera battery chamber

cover into the BG-C4

battery chamber holder.

5. Remove the protective

cap and connect the BG-

C4 grip to the camera,

while aligning the grip’s

mounting screw with the

camera’s tripod socket.

6. Rotate the attachment

wheel in the direction

shown by the arrow until it

is firmly tightened.

When removing the grip, turn

the camera power off, remove

batteries, and replace protective

contact cap.

OVERVIEW INTRODUCTION

ASSEMBLY

Inserting Batteries

1. Ensure that the power is

turned off on the camera

and grip. Slide the battery

compartment lever as

indicated above and open

the battery chamber door.

Press both release levers

outward and remove the

AA battery holder.

2. Canon LP-E6 Batteries:

Insert up to two

batteries by sliding them

into any slot inside the

BG-C4 battery grip, while

ensuring the correct

orientation as shown

on the battery door

compartment. Close the

compartment cover.

3. AA Batteries: Place six

new AA batteries of

the same type into the

AA battery holder as

shown, while ensuring

that they are in the

correct orientation.

4. Slide the AA holder into

the grip until it clicks into

place. Close the battery

compartment.

5. Switch the grip power

to ON and then turn

on the camera’s power.

Check the battery level

in the control panel or

viewﬁnder.

6. Household Power Outlet:

The Canon ACK-E8

AC Power Adapter Kit

(sold separately) can be

connected to the grip.

Place the DC coupler

through the small groove

on the back of the grip.

Ensure that the cord

doesn’t get pinched by the

battery holder.

To remove either the batteries

or the battery holder, hold

down the two battery release

levers to unlock.

OVERVIEW INTRODUCTION

ASSEMBLY

Specifications

Power Sources 1. One or two Canon LP-E6 rechargeable Li-ion batteries

2. Six AA/LR6 Alkaline batteries

3. Works with the Canon AC Adapter Kit ACK-E8 (sold separately)

Operating Temperature 32 – 104 °F (0 – 40 °C)

Dimensions Approximately 5.8" × 4.5" × 3" (14.7 × 11.4 × 7.7 cm)

Weight Approximately 12 oz. (340 g) excluding holder and batteries

Speciﬁcations and design are subject to change without notice.

AA batteries do not provide as much shooting time as LP-E6 rechargeable batteries. Performance of AA batteries may also be dependent on brand

and storage conditions. AA batteries may not function under 68º F (20º C).
