Vello FreeWave Fusion Basic Manual de usuario

FREEWAVE

FUSION

USER MANUAL

INTRODUCTION

Thank you for choosing the Vello FreeWave

Fusion Wireless Shutter/Flash/Grouping

Remote. This device triggers o-camera

lights remotely from up to 300 feet away.

With its multiple groups feature, you can

easily conﬁgure up to three dierent light

groups, which can be triggered individually

or simultaneously, for a total of seven

dierent combinations. (Simultaneous

triggering of multiple light groups requires

additional FreeWave Fusion Receivers

available for purchase separately.)

Additionally, the FreeWave Fusion

incorporates the conveniences of a wireless

shutter release, allowing you to trip the

shutter without disturbing the camera. It’s

ideal for taking pictures of subjects that are

dicult to approach, such as wildlife. It also

eliminates vibrations caused by pressing

your camera’s shutter release button

during macro, close-up, and long-exposure

photography.

The FreeWave Fusion does not require line-

of-sight alignment, as its radio waves pass

through and around objects such as walls,

windows, and ﬂoors.

Your Vello FreeWave Fusion Wireless

Shutter/Flash/Grouping Remote Kit

contains:

Wireless Transmitter

Wireless Receiver

Shutter Release Cable

Studio Trigger Cable (3.5 mm Mini)

Studio Trigger Cable (2.5 mm Mini to

1/4" Phono)

2 AAA Batteries

1 Lithium-ion Battery (pre-installed)

KEY FEATURES

2.4 GHz Radio Frequency: Reduced

interference and improved wireless

signal quality.

Extended Range: up to 100 m (320 ft.)

Multi-Purpose: Use as an individual or

group wireless ﬂash trigger, and/or as a

shutter release remote trigger.

Multiple Groups: Conﬁgure up to three

dierent light groups and up to seven

dierent group combinations.

Flash Sync Speed of up to 1/320s: Take

advantage of sync speeds that match the

rating of your camera all the way up to

1/320s (on compatible cameras only).

Flash Wake-Up: Wake-up function in TTL

compatible ﬂash units.

Versatile: One Receiver works with

multiple camera and light models. Just

swap out the connecting cables.

Dual-Function Shutter Release Button:

Press halfway to focus; press fully to

trigger shutter.

LED Indicators: Conﬁrm pre-focus,

shutter release, ﬂash wake-up, and ﬂash

trigger in wireless mode.

COMPATIBLE DEVICES

We recommend using a fully manually

controlled ﬂash with this device. Since the

FreeWave Fusion does not transmit TTL

settings, you will need to set the power

output manually.

The FreeWave Fusion is compatible with

most cameras, ﬂash units and studio lights.

However, for ﬂash wake-up functionality

and/or high shutter speeds, you will need

full TTL support via your camera, ﬂash and

FreeWave Fusion trigger.

For instance, if you have a Canon camera,

and you’d like to take advantage of the ﬂash

wake-up feature; you will need a Canon

camera with TTL metering, a compatible

Canon ﬂash which supports TTL, and a

dedicated Canon compatible FreeWave

Fusion ﬂash trigger.

Similarly, if you have a Nikon camera, and

you’d like to take advantage of the ﬂash

wake-up feature, you will need a Nikon

camera with TTL metering, a compatible

Nikon ﬂash which supports TTL, and a

dedicated Nikon compatible FreeWave

Fusion ﬂash trigger.

SAFETY WARNINGS

• There are no user-serviceable parts inside

the devices. Do not attempt to

disassemble or perform any unauthorized

modiﬁcation.

• Do not operate the FreeWave Fusion in

the presence of ﬂammable gas or vapors.

• Do not handle with wet hands or immerse

in or expose to water or rain. Failure to

observe this precaution could result in ﬁre

or electric shock.

• Keep out of the reach of children. This

device contains small parts which may

pose a choking hazard.

• Observe caution when handling batteries.

Batteries may leak or explode if

improperly handled. Use only the batteries

listed in this manual. Make certain to align

batteries with correct polarity.

• Batteries are prone to leakage when

fully discharged. To avoid damage to the

product, be sure to remove the batteries

when leaving the product unattended for

prolonged periods or when no charge

remains.

• Do not use or leave the devices in

conditions of extreme heat, severe cold,

or high humidity.

• Turn o the camera’s power before

inserting or removing the remote cord.

• Dispose used batteries, packaging, and old

devices in accordance with appropriate

local environmental regulations.

Hot Shoe Mount

Shutter Release Button

Group Indicator

Power Switch / Setting Button

Conﬁrmation LED

Receiver

Transmitter

Power (Group) Switch

2.5 mm Output Jack

Conﬁrmation LED

FEATURES DIAGRAM

GETTING STARTED

Set the DIP switch located in the battery

compartment of the Transmitter and

Receiver.

The DIP switches set a dierent radio

frequency for each Transmitter/Receiver

set, so that multiple sets of the FreeWave

Fusion and/or additional Fusion Receivers

can be used simultaneously. You can use a

pen to set the DIP switches to your desired

code. Any combination will work so long

as the switches are set identically in both

the Transmitter and Receiver(s) of a single

FreeWave Fusion set.

Insert 2 AAA batteries into the Receiver.

POWERING UP

Turn on the Receiver:

Slide the Group Switch to either A, B, or

C and the unit will power up. The LED will

ﬂash red at 2 second intervals to indicate

that the Receiver is working.

To power down after use, slide the Group

Switch back to the O position.

Turn on the Transmitter:

Press and hold the power button for 2

seconds to power up the Transmitter. The

Group Indicator light will turn on and show

the currently selected group. The Group

indicator light will turn o after 2 seconds

and the Transmitter will enter Standby

mode.

To power down after use, press and hold

the power button for 2 seconds. The LED

at the top of the unit will ﬂash 4 times at

half second intervals before shutting itself to

indicate that it is powering o.

MOUNTING THE TRANSMITTER

1. With your camera and Receiver o,

loosen the Transmitter’s hot shoe locking

ring.

2. Insert the Transmitter’s hot shoe on the

camera’s hot shoe mount.

3. Tighten the hot shoe locking ring.

MOUNTING THE RECEIVER

Mount the receiver on your tripod or stand

via one of the two provided mounting

options:

1. Threaded socket for a standard 1/4"

screw mount

2. Accessory shoe (cold shoe) foot
