BG-N18

BAT TERY GRIP

Designed for the

Nikon D7500 DSLR Camera

USER’S MANUAL

Introduction

Thank you for choosing Vello and congratulations on your

new BG-N18 battery grip purchase. Enjoy the benefits

that a battery grip offers, such as comfort and control

when shooting in a vertical (portrait) orientation. The

Vello BG-N18 is compatible with the Nikon D7500 DSLR

camera. It accepts an EN-EL15a rechargeable battery and

offers an alternate shutter-release button.

Please read through this entire manual

before using the BG-N18 battery grip.

Precautions

The BG-N18 should be used with only compatible

devices specified in this manual.

2. Use only with batteries recommended in this manual.

If you notice smoke, an unusual smell, or noise from

the battery pack, discontinue use immediately. Remove

the batteries and take the device to a Vello authorized

reseller.

The battery level may not display properly if batteries

are installed before mounting the grip.

5. Remove batteries from the grip when not in use.

6. Do not attempt to disassemble.

Do not expose this product to water or extreme

humidity, and keep in a dry cool place.

8. Keep out of reach of children.

9. All images are for illustrative purposes only.

OVERVIEW INTRODUCTION

ASSEMBLY

Overview

1Shutter Release Button

Use as an alternate shutter release

button for shooting in vertical

(portrait) mode.

2Nonslip Rubber Grip

Provides a secure and comfortable

grip when shooting vertically.

31/4"-20 Tripod Socket

Allows for mounting to a tripod when

the grip is attached to your camera.

4Locking Wheel

Secures the grip to the camera’s

tripod socket.

5Camera Battery Door Holder

Stores the camera’s battery chamber

door when the grip is mounted.

62.5 mm Remote Cable Socket

Accepts 2.5 mm shutter release cable.

7Battery Tray Compartment

Houses the battery tray.

81/4"-20 Mounting Screw

Connects to the camera’s tripod

socket.

9Power Contacts

Slide into the camera’s battery

chamber and transmit power.

10 Battery Tray

Secures Nikon EN-EL15a battery.

11 Battery Chamber Lock

Locks and unlocks the battery tray.

2.5 mm Shutter Release Cable

(BG-N6RC)

Transmits shutter release signal from

battery grip to the camera.

ASSEMBLY OVERVIEW INTRODUCTION

Attaching the Grip

Ensure that the camera

power is turned off.

Turn the camera upside

down, and open the

camera’s battery chamber

door. Pull gently at a 45°

angle until the chamber door

detaches.

Slide the camera battery

chamber door into the

BG-N18 chamber door

holder for safekeeping.

Insert the BG-N18 grip

power contacts into the

camera’s battery chamber

as shown. Make sure to

align the camera’s tripod

socket with the BG-N18

mounting screw.

Rotate the locking wheel

counterclockwise until it is

firmly tightened.

Connect the shutter release

cable from the cable release

socket on the battery grip

to the remote release port

on the camera body.

OVERVIEW

ASSEMBLY INTRODUCTION

Inserting Batteries

Ensure that the power is

turned off on the camera.

Flip out the battery tray lock

with your finger tip, and

rotate counterclockwise.

Slide the battery tray out

of the grip.

3. Line up the contacts on the

battery with the contacts

inside the battery tray, and

insert the battery.

When removing the grip, turn the camera power off and

remove the batteries.

Insert the battery into the battery tray

compartment, and close and lock the tray.

OVERVIEW

ASSEMBLY INTRODUCTION

Power Source Nikon EN-EL15a rechargeable battery

Operating Temperature 32°F to 104°F (0°C to 40°C)

Dimensions (H × D × W) 4 x 2.9 x 5.3 in. (10.2 x 7.5 x 13.5 cm)

Weight 6.2 oz. (175.8 g)

The shutter release button on the

battery grip is not triggering the

camera.

•

Make sure the 2.5 mm Shutter Release Cable is connected from the battery

grip to the camera.

Specifications

Troubleshooting
