Vello BG-C10 Manual de usuario

BG-C10

BAT TERY GRIP

Designed for the Canon

EOS 70D, 80D, and 90D

DSLR Cameras

USER’S MANUAL

Introduction

Thank you for choosing Vello and congratulations on

your new BG-C10 battery grip purchase. Enjoy the many

beneﬁts that a battery grip oers such as extended

shooting time and more control and comfort when

shooting in a vertical (portrait) orientation.

The Vello BG-C10 is compatible with the Canon EOS

70D, 80D, and 90D DSLR cameras. The BG-C10 accepts

two Canon LP-E6 rechargeable batteries. Alternatively

six AA batteries (alkaline, Ni-MH, lithium, or nickel-

manganese) can be used for added convenience. The

BG-C10 is equipped with an alternate shutter-release

button, AF area selection mode button, AF point

selection, AE lock/FE lock button, AF Start, and main

dial for shooting in a vertical position.

Please read through this entire manual before using the

B G- C10 battery grip.

Precautions

1. The BG-C10 should only be used with compatible

devices specified in this manual.

2. Only use with batteries and battery holders

recommended in this manual.

3. Cover the power terminals with the contact cap

when the BG-C10 is not in use. This prevents

electrical shorts caused by metal objects touching

the power terminals.

4. When the battery holder is removed from the

grip, remove the batteries or place the holder in

a container to prevent electrical shorts caused by

contact with other metal objects.

5. If you notice smoke, an unusual smell or noise from

the battery pack, discontinue use immediately.

Remove the batteries and take the device to a Vello

authorized reseller.

6. Turn the grip power off when not shooting

vertically.

7. The battery level may not display properly if

batteries are inserted before mounting the grip.

8. Remove batteries from the grip when not in use.

9. Do not attempt to disassemble.

10. Avoid water or extreme humidity and keep in a

dry and cool place.

11. Keep out of reach of children.

OVERVIEW INTRODUCTION

ASSEMBLY

Overview

1Mounting Screw

Aligns with the camera’s tripod socket.

2Guide Pin

Helps align the camera to the grip.

3Attachment Wheel

Secures the grip to the camera.

4Battery Compartment Cover

5DC Coupler Cord Mount

Groove for use with the Canon AC

Power Adapter (ACK-E6).

6AF Point Selection/Magnify Button*

AE Lock/FE Lock/Index/Reduce

Button*

AF On Button*

BG-C10 Grip Power ON/OFF

Camera Battery Chamber Cover

Holder

Stores the camera’s battery chamber

cover when the grip is mounted.

11 Electrical Contacts

Communicates with the camera’s

electronics.

Contact Cap

Protects grip contacts. Keep covered

when the grip is not in use.

13 Battery Holder

Holds up to two Canon LP-E6

batteries.

14AA Battery Holder

Holder for six AA batteries.

15 Main Dial*

16 AF area selection mode button

17 Shutter-Release Button*

18 Tripod Socket

For mounting on a tripod.

19 Hand Strap Mount

Optional hand strap may be mounted

for a secure hold while shooting.

* Performs the same function as on the

camera. Consult your camera’s manual

on the use of these functions.

OVERVIEW INTRODUCTION

ASSEMBLY

Attaching The Grip

1. Ensure that the power is

turned off on the camera

and that the power switch

is set to OFF on the battery

grip.

2. Remove the battery

from the camera battery

compartment.

3. Open the camera battery

chamber cover at a 35º

angle and gently pull

the cover to remove it.

4. To prevent loss, slide the

camera battery chamber

cover into the BG-C10

battery chamber holder

A. To remove the cover,

press lightly on the cover

hinge Band pull it up at an

angle C.

5. Remove the protective

cap and connect the BG-

C10 grip to the camera,

while aligning the grip’s

mounting screw with the

camera’s tripod socket.

6. Rotate the attachment

wheel in the direction

shown by the arrow until it

is firmly tightened.

When removing the grip, turn

the camera power off, remove

batteries, and replace protective

contact cap.

OVERVIEW INTRODUCTION

ASSEMBLY

Inserting Batteries

1. Ensure that the power

is turned off on the

camera and grip. Pull the

lever down Aand twist

counter-clockwise Bto

open the battery chamber

door. Pull the release lever

outward and remove the

battery holder C.

2. Canon LP-E6 Batteries:

Insert up to two batteries

by orienting the arrow on

the battery toward the

interior of the holder.

Press the front of the

battery down Aand slide

forward while pressing on

the back of the battery B.

3. AA Batteries: Place six

new AA batteries of

the same type into the

AA battery holder as

shown, while ensuring

that they are in the

correct orientation.

4. Slide the battery holder

into the grip, twist the

lever clockwise to lock,

and ﬂip it up to secure it.

5. Switch the grip power

to ON and then turn

on the camera’s power.

Check the battery level

in the control panel or

viewﬁnder.

Household Power Outlet:

To mount the Canon

ACK-E6 AC Power

Adapter Kit (sold

separately), insert the

DC coupler into the side

of the handler with the

release lever just like a

battery. Pass the cord

through the groove on the

back of the grip.

Ensure that camera power is

turned off before mounting the

DC coupler. Ensure that the DC

cord doesn’t get pinched by the

battery holder.

OVERVIEW INTRODUCTION

ASSEMBLY

Specifications

Power Source 1. One or two Canon LP-E6 rechargeable Li-ion batteries

2. Six AA/LR6 Alkaline, Ni-MH, Lithium or Nickel-Manganese batteries

3. Works with the Canon AC Adapter Kit (ACK-E6)

Operating Temperature 32º – 104° F (0 – 40° C)

Dimensions 5.7" × 4.4" × 3.4" (145.6 × 111.3 × 85.3 mm)

Weight 10.4 oz. (295g) excluding holder and batteries

Speciﬁcations and design are subject to change without notice.

AA batteries do not provide as much shooting time as LP-E6 rechargeable batteries. Performance of AA batteries may also be dependent on

brand and storage conditions.

Please note: When using the AA battery tray, the battery indicator will only work with Ni-MH batteries.

This product is not compatible with Duracell®brand alkaline batteries.
