Vello BG-C6 Manual de usuario

BG-C6

BAT TERY GRIP

Designed for the Canon

EOS 60D SLR Camera

USER’S MANUAL

Introduction

Thank you for choosing Vello and congratulations on

your new BG-C6 battery grip purchase. Enjoy the many

benefits that a battery grip offers, such as extended

shooting time and more control and comfort when

shooting in a vertical (portrait) orientation.

The Vello BG-C6 is compatible with the Canon EOS

60D SLR camera. The BG-C6 accepts two Canon LP-E6

rechargeable batteries, or six AA batteries (alkaline, Ni-

MH, lithium, or nickel-manganese) can be used instead

for added convenience. The BG-C6 is equipped with an

alternate shutter-release button, AF point selection, AE

lock/FE lock button, AF Start, and main dial for shooting

in a vertical position.

Please read through this entire manual before

using the BG-C6 battery grip.

Precautions

The BG-C6 should only be used with compatible

devices specified in this manual.

Only use with batteries and battery holders

recommended in this manual.

Cover the power terminals with the contact cap

when the BG-C6 is not in use. This prevents electrical

shorts caused by metal objects touching the power

terminals.

When the battery holder is removed from the

grip, remove the batteries or place the holder in

a container to prevent electrical shorts caused by

contact with other metal objects.

5. If you notice smoke, an unusual smell or noise from

the battery pack, discontinue use immediately.

Remove the batteries and take the device to a Vello

authorized reseller.

Turn the grip power off when not shooting vertically.

The battery level may not display properly if batteries

are inserted before mounting the grip.

8. Remove batteries from the grip when not in use.

9. Do not attempt to disassemble.

10.

Avoid water or extreme humidity and keep in a dry

and cool place.

11. Keep out of reach of children.

OVERVIEW INTRODUCTION

ASSEMBLY

Overview

1Mounting Screw

Aligns with the camera’s tripod socket.

2Guide Pin

Helps align the camera to the grip.

3Attachment Wheel

Secures the grip to the camera.

4Battery Compartment Cover

5DC Coupler Cord Mount

Groove for use with the Canon AC

Power Adapter (ACK-E6).

6AF Point Selection/Magnify Button*

AE Lock/FE Lock/Index/Reduce

Button*

AF Start Button

BG-C6 Grip Power ON/OFF

Camera Battery Chamber Cover

Holder

Stores the cover when the grip is

mounted.

11 Electrical Contacts

Communicates with the camera’s

electronics.

Contact Cap

Protects grip contacts. Keep covered

when the grip is not in use.

13 Battery Holder

Holds up to two Canon LP-E6

batteries.

14AA Battery Holder

Holder for six AA batteries.

15 Main Dial*

16 Shutter-Release Button*

17 Tripod Socket

For mounting on a tripod.

18 Hand Strap Mount

Optional hand strap may be mounted

for a secure hold while shooting.

* Performs the same function as on the

camera.

OVERVIEW INTRODUCTION

ASSEMBLY

Attaching The Grip

Ensure that the power is

turned off on the camera

and that the power switch

is set to OFF on the battery

grip.

Remove the battery

from the camera battery

compartment.

Open the camera battery

chamber cover at a 35º

angle and gently pull

the cover to remove it.

To prevent loss, slide the

camera battery chamber

cover into the BG-C6

battery chamber holder

To remove the cover, press

lightly on the cover hinge

and pull it up at an angle C.

Remove the protective

cap and connect the BG-

C6 grip to the camera,

while aligning the grip’s

mounting screw with the

camera’s tripod socket.

Rotate the attachment

wheel in the direction

shown by the arrow until it

is firmly tightened.

When removing the grip, turn

the camera power off, remove

batteries, and replace protective

contact cap.

OVERVIEW INTRODUCTION

ASSEMBLY

Inserting Batteries

Ensure that the power

is turned off on the

camera and grip. Pull the

lever down

and twist

counter-clockwise

open the battery chamber

door. Press both release

levers outward and

remove the battery holder

Canon LP-E6 Batteries:

Insert up to two batteries

by orienting the arrow on

the battery toward the

interior of the holder. Press

the front of the battery

down Aand slide forward

while pressing on the back

of the battery B.

AA Batteries: Place six

new AA batteries of the

same type into the AA

battery holder as shown,

while ensuring that they are

in the correct orientation.

Slide the battery holder

into the grip, twist the

lever clockwise to lock,

and ﬂip it up to secure it.

Switch the grip power to

ON and then turn on the

camera’s power. Check the

battery level in the control

panel or viewﬁnder.

Household Power Outlet:

To mount the Canon

ACK-E6 AC Power

Adapter Kit (sold

separately), insert the DC

coupler into the side of the

handler with the release

lever just like a battery.

Pass the cord through

the groove on the back of

the grip.

Ensure that camera power is

turned off before mounting DC

coupler. Ensure that the DC

cord doesn’t get pinched by the

battery holder.

OVERVIEW INTRODUCTION

ASSEMBLY

Specifications

Power Source 1. One or two Canon LP-E6 rechargeable Li-ion batteries

2. Six AA/LR6 Alkaline batteries

3. Works with the Canon AC Adapter Kit (ACK-E6)

Operating Temperature 32º – 104° F (0 – 40° C)

Dimensions 5.7" × 4.4" × 3.4" (145.6 × 111.3 × 85.3 mm)

Weight 10.4 oz. (295 g) (excluding holder and batteries)

Speciﬁcations and design are subject to change without notice.

AA batteries do not provide as much shooting time as LP-E6 rechargeable batteries. Performance of AA batteries may also be dependent on brand

and storage conditions. AA batteries may not function under 68º F (20º C).

Please note: When using the AA battery tray, the battery indicator will only work with Ni-MH batteries.

This product is not compatible with Duracell®brand alkaline batteries.
