HDMI over Cat6
Splitter Kits, 4K/60 Hz
Splitter Models: B127A-002-BH,
B127A-004-BH, B127A-008-BH
Splitter and Receiver Kit Models:
B127A-002-BHPH2, B127A-004-BHPH3
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Owner's Manual
WARRANTY REGISTRATION
Register your product today and be automatically entered to win
an ISOBAR®surge protector in our monthly drawing!
tripplite.com/warranty
Este manual está disponible en español en la página de Tripp Lite:
tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite :
tripplite.com
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website
verfügbar: tripplite.com
21-08-019-933DB9-EN.indd 121-08-019-933DB9-EN.indd 1 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM
2
External
Power Supply
Mounting
Hardware
(Y/N)
HDMI
Accessory
Cable
B127A-002-BH Y Y N
B127A-002-BHPH2 Y Y N
B127A-004-BH Y Y Y
B127A-004-BHPH3 Y Y Y
B127A-008-BH Y Y N
All
• Extend 4K audio and video signals up to 230 ft. away to an
HDMI display
• Support video resolutions up to 4K x 2K (3840 x 2160) @
60 Hz, as specified in HDMI 2.0, with 4:4:4 Chroma
Subsampling
• Carry High Dynamic Range (HDR) signals for expanded color
accuracy
• Comply with HDCP 2.2 standards
• Power over Cable (PoC) technology provides power from splitter
to connected receiver units over Cat6 cabling
• Plug and play – no software or drivers required
Package Contents
Product Features
21-08-019-933DB9-EN.indd 221-08-019-933DB9-EN.indd 2 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM
3
Product Features
B127A-002-BH
• Extends and splits a 4K audio/video signal with power to two
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Compatible with Tripp Lite B127A-Series Receiver units such
as B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Included mounting hardware allows splitter unit to be wall-
mounted, rack-mounted or pole-mounted
B127A-002-BHPH2
• Extends and splits a 4K audio/video signal with power to two
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Kit includes two pigtail receivers that each support 4K/60 Hz
video resolutions
• Compatible with Tripp Lite B127A-Series Receiver units such
as B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
21-08-019-933DB9-EN.indd 321-08-019-933DB9-EN.indd 3 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM
4
Product Features
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Included mounting hardware allows splitter unit to be wall-
mounted, rack-mounted or pole-mounted
B127A-004-BH
• Extends and splits a 4K audio/video signal with power to four
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Compatible with Tripp Lite B127A-Series Receiver units such
as B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Local HDMI port supports 4K/60 Hz video resolution to display
the image being transmitted to connected displays
• Cascade an additional B127A-002-BH, B127A-004-BH
or B127A-008-BH splitter unit from the local HDMI port to
expand your installation
21-08-019-933DB9-EN.indd 421-08-019-933DB9-EN.indd 4 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM
5
Product Features
• Included mounting hardware allows splitter unit to be wall-
mounted, rack-mounted or pole-mounted
B127A-004-BHPH3
• Extends and splits a 4K audio/video signal with power to four
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Kit includes three pigtail receivers that each support 4K/60 Hz
video resolutions
• Compatible with Tripp Lite B127A-Series Receiver units such as
B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Local HDMI port supports 4K/60 Hz video resolution to display
the image being transmitted to connected displays
• Cascade an additional B127A-002-BH, B127A-004-BH
or B127A-008-BH splitter unit from the local HDMI port to
expand your installation
• Included mounting hardware allows splitter unit to be wall-
mounted, rack-mounted or pole-mounted
21-08-019-933DB9-EN.indd 521-08-019-933DB9-EN.indd 5 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM
6
Product Features
B127A-008-BH
• Extends and splits a 4K audio/video signal with power to eight
displays up to 230 ft. away over 24 AWG Cat6 cabling
• Compatible with Tripp Lite B127A-Series Receiver units such
as B127A-1A0-FH or B127A-1A0-BH (sold separately)
• Supports true uncompressed 7.1-channel digital audio and
Dolby TrueHD
• Multi-resolution support allows receiver units to be used on any
display that supports 1080p, 4K/30 Hz or 4K/60 Hz without
affecting the video resolution of the other connected receiver
• Power over Cable (PoC) technology provides power from the
splitter unit to the connected receivers via Cat6 cabling
• Local HDMI port supports 4K/60 Hz video resolution to display
the image being transmitted to connected displays
• Cascade an additional B127A-002-BH, B127A-004-BH
or B127A-008-BH splitter unit from the local HDMI port to
expand your installation
• Included mounting hardware allows splitter unit to be
wall-mounted, rack-mounted or pole-mounted
21-08-019-933DB9-EN.indd 621-08-019-933DB9-EN.indd 6 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM
7
Disclaimer
Product Features
Before installation, please check the following settings of your
source(s) and TV/monitor(s):
1. Set display to 60 Hz. Double-check factory settings, as
default can be set to a lower frequency (Hz) than advertised.
2. Ensure the input setting of your monitor is set at HDMI 2.0.
Some displays may have default setting at HDMI 1.4.
3. Verify your monitor has the HDR feature enabled. Some
displays may have this feature disabled as a factory setting.
4. Check if the Ultra HD (UHD) Deep Color setting is enabled on
your TV/monitor. Confirm with your TV/monitor manufacturer
which HDMI ports support UHD Deep Color.
Note for B127A-004-BH, B127A-004-BHPH3 and B127A-008-BH:
To connect a local monitor to your installation, the UHD Deep Color
setting may need to be disabled on your local TV/monitor (depending
on make) to achieve 4K @ 60 Hz resolution.
Optional Accessories:
• N202-Series Cat6 24 AWG Solid Wire Patch Cables
• P569-XXX-CERT or P568-XXX-2A Series High-Speed
HDMI 2.0 Cables
• B127A-010-H Signal Booster
• B127A-1A0-BH Box-Style Receiver
• B127A-1P0-PH Pigtail Receiver
• B127A-1A0-FH Faceplate Receiver
21-08-019-933DB9-EN.indd 721-08-019-933DB9-EN.indd 7 8/24/2021 3:07:47 PM8/24/2021 3:07:47 PM
8
Mounting Instructions
The B127A-002-BH, B127A-004-BH, B127A-008-BH,
B127A-002-BHPH2 and B127A-004-BHPH3 include mounting
hardware that allows for a variety of mounting methods.
The following images illustrate how the included mounting
brackets can be attached for different installations.
Note: The model shown in the below images is for illustrative purposes
only. Your product may vary by model number, size or port orientation.
The mounting options for all over IP units are the same.
Wall-Mount
19” Rack-Mount Pole-Mount
21-08-019-933DB9-EN.indd 821-08-019-933DB9-EN.indd 8 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM
9
Installation
Standard Splitter Kit Installation
(2-Port Models)
Notes:
1) Test to ensure the entire installation works properly before pulling
cables through ceilings/walls.
2) To achieve maximum distance and performance, use 24 AWG solid
wire Cat6 cable. Using stranded wire Cat6 cable or cable with a gauge
(AWG) size higher than 24 AWG will result in shorter extension distance.
Higher gauge cabling, such as 26 AWG, has a more limited transmission
capability than lower gauge cabling. All Tripp Lite N202-Series Cat6
cables are made with 24 AWG solid wire cabling.
3) The first installation diagram shows a B127A-002-BHPH2 kit, which
includes a B127A-002-BH splitter unit and two B127A-1P0-PH receiver
units. The second diagram shows the B127A-002-BH splitter used with
an included B127A-1P0-PH receiver and B127A-1A0-BH receiver (sold
separately at tripplite.com).
4) External power is not required for remote receiver units because of
Power over Cable (PoC) technology incorporated in the transmitter units.
21-08-019-933DB9-EN.indd 921-08-019-933DB9-EN.indd 9 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM
10
Installation
B127A-002-BH
1Up to 230 ft. (70 m) Cat6 cable at 4K/60 Hz
2Up to 15 ft. (4.5 m) HDMI 2.0 cable at 4K/60 Hz
MONITOR
HDR PLAYER
B127A-1A0-BH
B127A-002-BH
B127A-1P0-PH
21-08-019-933DB9-EN.indd 1021-08-019-933DB9-EN.indd 10 8/24/2021 3:07:48 PM8/24/2021 3:07:48 PM
