Owner’s Manual

VGA with Audio Over

Cat5 Extender/Splitter

Remote Unit

Model: B132-100A

Tripp Lite World Headquarters

1111 W. 35th Street, Chicago, IL 60609 USA

(773) 869-1234 • www.tripplite.com

Note: Follow these instructions to ensure proper operation and prevent damage

to this device and its connected equipment.

All trademarks are the property of their respective owners.

Español 7

Français 15

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

200901120 93-2871.indd 1 2/12/2009 4:50:46 PM

Package Contents

Speciﬁcations

• B132-100AVGAwithAudioOverCat5Extender/SplitterRemoteUnit

• 5V,2APowerSupply

• Screwdriver

• Owner’sManual

Product Features

• WorksinconjunctionwithaB132-004AVGAwithAudioOverCat5

Extender/SplitterLocalUnit(soldseparately)toextendaVGAandAudio

signalupto500ftusingstandardCat5e/6cable,orupto1,000ft(1024x

768,3db)usingZero-SkewUTPcable

• UtilizesinexpensiveCat5e/6cable

• CompatiblewithVGA,SVGA,XGA,SXGAandUXGAcomputerresolutions

• Supportsvideoresolutionupto1920x1440

• Featuresbuilt-inEqualizationandGaincontrolstoadjustthevideoimage

• Compatiblewithalloperatingsystems

• B132-004AVGAwithAudioOverCat5Extender/SplitterLocalUnit

• P502-SeriesMonitorCableswithRGBCoax,HD15Male/Male

• P504-SeriesMonitorCableswith3.5mmAudio;HD15Male/Maleand

3.5mmMale/Male

• P312-Series3.5mmMini-StereoCable

• P524-SeriesZero-SkewUTPBulkCables

• P525-SeriesZero-SkewUTPPatchCables

• N001-orN002-SeriesCat5ePatchCables

• N201-SeriesCat6PatchCables

Optional Accessories

SignalType................................ VGA,SVGA,XGA,UXGAandWUXGA

(upto1920x1440)

VideoAmplifierBandwidth......350Mbps

InputDDCSignal .....................0.7Voltsp-p(TTL)

SignalNoiseRatio ....................90dB

B132-100APorts ......................HD15Female,3.5mmFemale,RJ45Female

200901120 93-2871.indd 2 2/12/2009 4:50:46 PM

Speciﬁcations (continued)

B132-100ADimensions(Inches) ....... 1.1(H)x2(W)x3.75(D)

B132-100AWeight(lbs)..................... 0.4

Note:Speciﬁcations are subject to change without notice. Mass and dimensions are

approximate; please take the products as a standard.

Function Description

12 3 4 5

1Remote Audio-Out Port:3.5mmFemale.

2Remote Video-Out Port:HD15Female.

3Power Jack:5V,2Apowersupplyconnectstotheunithere.

4Power LED: ThePowerLEDilluminateswhentheunitispluggedin

and receiving power.

5Input:RJ45Female;connectCat5e/6*cablebetweenthisportandone

oftheB132-004ALocalUnit’s(soldseparately)Outputports.

6Equalization Control:Usetheincludedscrewdrivertoadjustthe

Equalizationofthepicture.

7Gain Control:UsetheincludedscrewdrivertoadjusttheGainofthe

picture.

*UseZero-SkewUTPcablewhenextendingthesignalover500ftfromthesource.

200901120 93-2871.indd 3 2/12/2009 4:50:46 PM

Installation

Note: Test to make sure the entire installation works properly before pulling cables

through ceilings/walls.

1 FollowtheinstructionsthatcomewiththeB132-004ALocalUnitbefore

connectingtheB132-100ARemoteUnit.

2 UseCat5e/6*cabletoconnectoneoftheOutputportsontheB132-

004ALocalUnittotheInputportontheB132-100ARemoteUnit.

3Connect a monitor to the VideoportoftheB132-100ARemoteUnit

usingaTrippLiteP502-SeriesVGAcable.

4Connect speakers to the AudioportoftheB132-100ARemoteUnit

usingaTrippLiteP312-Series3.5mmMini-Stereocable.

5 Firstturnonthemonitor,andthenturnonthecomputerconnectedtothe

B132-004A’s Sourceport.Ifyourpictureistoodark,orisdisplayinga

“ghostingeffect,”usethescrewdriverincludedwiththeB132-100Ato

adjusttheEqualizationandGaincontrols.

*UseZero-SkewUTPcablewhenextendingthesignalover500ftfromthesource.

B132-100A

Remote Unit

B132-004A Local Unit

200901120 93-2871.indd 4 2/12/2009 4:50:46 PM

Safety Information

• Toreducetheriskofelectricshock,donotexposethisproducttorainor

moisture.

• Operatethisproductusingonlytheincludedexternalpowersupply.Use

ofotherpowersuppliescouldimpairperformance,damagetheproduct,

orcausefire.

• Useonlyrecommendedaccessoriestoavoidfire,shockorotherhazards.

• Unplugthisproductbeforecleaning.Useadampclothforcleaning.Do

notusecleaningfluidsoraerosols,whichcouldentertheunitandcause

damage,fireorelectricalshock.

• Donotattempttoservicetheunit.Instead,disconnectitandcontactyour

AuthorizedResellerortechnician.

• Useofthisequipmentinlifesupportapplicationswherefailureofthis

equipmentcanreasonablybeexpectedtocausethefailureofthelife

supportequipmentortosignificantlyaffectitssafetyoreffectiveness

isnotrecommended.Donotusethisequipmentinthepresenceofa

flammableanestheticmixturewithair,oxygenornitrousoxide.

200901120 93-2871.indd 5 2/12/2009 4:50:46 PM

WARRANTY REGISTRATION

Visitwww.tripplite.com/warrantytodaytoregisterthewarrantyforyournewTrippLiteproduct.You’llbe

automaticallyenteredintoadrawingforachancetowinaFREETrippLiteproduct!*

*Nopurchasenecessary.Voidwhereprohibited.Somerestrictionsapply.Seewebsitefordetails.

1-YEAR LIMITED WARRANTY

Sellerwarrantsthisproduct,ifusedinaccordancewithallapplicableinstructions,tobefreefromoriginal

defectsinmaterialandworkmanshipforaperiodof1yearfromthedateofinitialpurchase.Iftheproduct

shouldprovedefectiveinmaterialorworkmanshipwithinthatperiod,Sellerwillrepairorreplacethe

product,initssolediscretion.ServiceunderthisWarrantycanonlybeobtainedbyyourdeliveringor

shippingtheproduct(withallshippingordeliverychargesprepaid)to:TrippLite;1111W.35thStreet;

ChicagoIL60609;USA.Sellerwillpayreturnshippingcharges.CallTrippLiteCustomerServiceat(773)

869-1234beforesendinganyequipmentbackforrepair.

THISWARRANTYDOESNOTAPPLYTONORMALWEARORTODAMAGERESULTINGFROM

ACCIDENT,MISUSE,ABUSEORNEGLECT.SELLERMAKESNOEXPRESSWARRANTIES

OTHERTHANTHEWARRANTYEXPRESSLYSETFORTHHEREIN.EXCEPTTOTHEEXTENT

PROHIBITEDBYAPPLICABLELAW,ALLIMPLIEDWARRANTIES,INCLUDINGALL

WARRANTIESOFMERCHANTABILITYORFITNESS,ARELIMITEDINDURATIONTOTHE

WARRANTYPERIODSETFORTHABOVE;ANDTHISWARRANTYEXPRESSLYEXCLUDES

ALLINCIDENTALANDCONSEQUENTIALDAMAGES.(Somestatesdonotallowlimitationsonhow

longanimpliedwarrantylasts,andsomestatesdonotallowtheexclusionorlimitationofincidentalor

consequentialdamages,sotheabovelimitationsorexclusionsmaynotapplytoyou.ThisWarrantygives

youspeciclegalrights,andyoumayhaveotherrightswhichvaryfromjurisdictiontojurisdiction).

TrippLite;1111W.35thStreet;ChicagoIL60609;USA

TrippLitefollowsapolicyofcontinuousimprovement.Productspecicationsaresubjecttochange

withoutnotice.

MadeinChina.

Tripp Lite World Headquarters

1111 W. 35th Street, Chicago, IL 60609 USA

(773) 869-1234 • www.tripplite.com

20090112093-2871

200901120 93-2871.indd 6 2/12/2009 4:50:46 PM
