Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

HDMI over Cat5 Extenders

and Extender/Splitters

Extender Kit Model: B126-1A1 and B126-1A1-WP

Local Unit Models: B126-002 and B126-004

Remote Unit Models: B126-1P0, B126-1P0-WP-1,

B126-1A0, B126-1A0-WP-1 and B126-110

Warranty

Registration:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

Package Contents 2

Product Features 2

Mounting Instructions 7

Standard Extender Kit Installation 8

Extender Kit with Remote/Repeater Installation 10

Standard Extender/Splitter Installation 13

Extender/Splitter with Remote/Repeater Installation 16

Extender/Splitter Daisy-Chain Installation (B126-004 only) 20

Extender/Splitter Daisy-Chain with Remote/Repeater 23

Installation (B126-004 only)

Warranty & Warranty Registration 27

201109206-93-3023-EN.indd 1 10/24/2011 10:01:17 AM

Package Contents

Product Features

B126-1A1

B126-1A1-WP

B126-002

B126-004

B126-1A0

B126-1A0-WP-1

B126-1P0

B126-1P0-WP-1

B126-110

Local Unit (L), Remote Unit (R),

or Both (B) B B L L R R R R R

External Power Supplies

(0, 1, or 2) 221111001

Mounting Hardware X X X X X

Wallplate Screws X X X

Screwdriver for

Equalization Adjustment X X X X X

HDMI Daisy-chain Cable X

All

• Supportamaximumvideoresolutionof1080p(60Hz)

• Plug-and-play;nosoftwareordriversrequired

• Supportupto7.1channelsurroundsoundaudio

• HDCPand3Dcompatible

201109206-93-3023-EN.indd 2 10/24/2011 10:01:17 AM

Product Features

B126-1A1

• HDMIoverCat5ActiveExtenderKit(Box-style)

• Extendsa1080i(60Hz)signalupto200ft.fromthesource,ora

1080p(60Hz)signalupto150ft.fromthesource

• FeaturesanadditionalHDMIportonthelocaltransmitterunitforthe

connection of local monitor

• Remotereceiverunitfeaturesabuilt-inEqualizationcontrolforvideo

image adjustment

• Includesmountinghardwarethatallowsboththelocaltransmitter

and remote receiver units to be wallmounted, rackmounted or pole

mounted

B126-1A1-WP

• HDMIoverCat5ActiveExtenderWallplateKit

• Extendsa1080i(60Hz)signalupto200ft.fromthesource,ora

1080p(60Hz)signalupto150ft.fromthesource

• Remotereceiverunitfeaturesabuilt-inEqualizationcontrolforvideo

image adjustment

• RJ45-stylewallplatesallowfortheuseofstandardCat5e/6patch

cables;110punchdownconnectionnotrequired

B126-002

• 2-PortHDMIoverCat5Extender/SplitterLocalTransmitterUnit

(Box-style)

• SplitsanHDMIsignalinto2

• Workswithremote/repeaterandreceiverunitstoextendanHDMI

signalpastthe16ft.(5m)distancelimitation

• Includesmountinghardwarethatallowsunittobewallmounted,

rackmounted or pole mounted

201109206-93-3023-EN.indd 3 10/24/2011 10:01:17 AM

Product Features

B126-004

• 4-PortHDMIoverCat5Extender/SplitterLocalTransmitterUnit

(Box-style)

• SplitsanHDMIsignalinto4

• FeaturesanadditionalHDMIport,whichcanbeusedtoconnecta

local monitor or to daisy-chain additional B126-004 units.

Upto3B126-004unitscanbedaisy-chainedtogethertoincrease

the number of connected monitors.

• Workswithremote/repeaterandreceiverunitstoextendanHDMI

signalpastthe16ft.(5m)distancelimitation

• Includesmountinghardwarethatallowsunittobewallmounted,

rackmounted or pole mounted.

• Upto3B126-004unitscanbemountedinaB132-004-RB1U

rackmount bracket

B126-1A0

• HDMIoverCat5ActiveExtenderRemoteReceiverUnit(Box-style)

• WorkswithB126-002andB126-004extender/splitterstoextend

a1080i(60Hz)signalupto200ft.fromthesource,ora1080p

(60Hz)signalupto150ft.fromthesource

• Featuresabuilt-inEqualizationcontrolforvideoimageadjustment

• Includesmountinghardwarethatallowstheunittobewallmounted,

rackmounted or pole mounted

201109206-93-3023-EN.indd 4 10/24/2011 10:01:17 AM

Product Features

B126-1A0-WP-1

• HDMIoverCat5ActiveExtenderWallplate

• WorkswithB126-002andB126-004extender/splitterstoextend

a1080i(60Hz)signalupto200ft.fromthesource,ora1080p

(60Hz)signalupto150ft.fromthesource

• Featuresabuilt-inEqualizationcontrolforvideoimageadjustment

• RJ45-stylewallplateallowsfortheuseofstandardCat5e/6patch

cables;110punchdownconnectionnotrequired

B126-1P0

• HDMIoverCat5PassiveExtenderRemoteReceiverUnit(Box-style)

• WorkswithB126-002andB126-004extender/splitterstoextend

a1080i(60Hz)signalupto100ft.fromthesource,ora1080p

(60Hz)signalupto50ft.fromthesource

• Featuresabuilt-inHDMIcable;aseparateHDMIcableisnotrequired

• Noexternalpowerrequired

B126-1P0-WP-1

• HDMIoverCat5PassiveExtenderWallplate

• WorkswithB126-002andB126-004extender/splitterstoextend

a1080i(60Hz)signalupto100ft.fromthesource,ora1080p

(60Hz)signalupto50ft.fromthesource

• RJ45-stylewallplateallowsfortheuseofstandardCat5e/6patch

cables;110punchdownconnectionnotrequired

• Noexternalpowerrequired

201109206-93-3023-EN.indd 5 10/24/2011 10:01:17 AM

Product Features

B126-110

• HDMIoverCat5ActiveExtenderRemote/RepeaterUnit(Box-style)

• ExtendsandexpandsTrippLiteHDMIoverCat5installation,allowing

multiple monitors to be located at different points in a chain of up to

700ft.

• Extendsa1080i(60Hz)signalupto175ft.,ora1080p(60Hz)

signalupto125ft.fromthelocaltransmitterunittotherstremote/

repeater unit in the installation

• Extendsa1080i(60Hz)signaluptoanadditional175ft.,ora

1080p(60Hz)signaluptoanadditional125ft.fromeachremote/

repeater unit to the next unit in the chain. In a full 4 level daisychain

installation,a1080i(60Hz)signalcanbeextendedupto700ft.,

ora1080p(60Hz)signalupto500ft.fromthesourcetothelast

remote unit in the chain.

• Connectupto4remoteunits(3remote/repeatersand1receiver),

with a monitor located at each point in the chain

• Featuresabuilt-inEqualizationcontrolforvideoimageadjustment

• Includesmountinghardwarethatallowstheunittobewall-mounted,

rack-mounted or pole-mounted

Optional Accessories:

• B132-004-RB1URackmountBracket

• N202-SeriesCat624AWG,solidwirepatchcables

• P568-SeriesHigh-SpeedHDMIcables

201109206-93-3023-EN.indd 6 10/24/2011 10:01:17 AM

Mounting Instructions (select models only)

The B126-002, B126-004, B126-1A1, B126-1A0 and B126-110

come with mounting hardware that allows them to be mounted in

a variety of ways. The following images show the different ways the

included mounting brackets can be attached for different mounting

methods.Note:TheB126-004canalsobemountedtoaTrippLite

B132-004-RB1URackmountBracket.Upto3B126-004localunits

canbeconnectedtoaB132-004-RB.

Wallmount

19” Rackmount Pole Mount

201109206-93-3023-EN.indd 7 10/24/2011 10:01:19 AM

OPTIONAL LOCAL

MONITOR

LOCAL

TRANSMITTER

REMOTE

RECEIVER

Up to 200 ft. at 1080i (60Hz)

Up to 150 ft. at 1080p (60Hz)

BLU-RAY

Standard Extender Kit Installation

Notes:

1) Test to make sure the entire installation works properly before pulling

cables through ceilings/walls.

2) To achieve maximum distance and performance, use 24 AWG solid

wire Cat5e/6 cable. Using stranded wire Cat5e/6 cable, or cable

with a gauge (AWG) size higher than 24 AWG, will result in shorter

extension distance. Higher gauge cabling, such as 26 AWG, has a

more limited transmission capability than lower gauge cabling. All

Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire

cabling.

3) The B126-1A1 and B126-1A1-WP are set to transmit a stereo audio

signal by default. Press the Audio button on the local unit to switch to

7.1-channel surround-sound audio.

4) The installation diagram shows a B126-1A1 unit. The B126-1A1-WP

installation is the same, except there is no local monitor port.

201109206-93-3023-EN.indd 8 10/24/2011 10:01:20 AM

Standard Extender Kit Installation

1Make sure the HDMI source is powered OFF.

2ConnecttheHDMIsourcetotheINPUTportontheB126-1A1or

B126-1A1-WPlocalunitusingaTrippLiteP568-SeriesHDMICable.

3Optional for B126-1A1: Connect a local monitor to the LOCAL port

ontheB126-1A1localunitusingaTrippLiteP568-SeriesHDMI

Cable.

4Connect the external power supply to the local unit and plug it into

a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU) or

Uninterruptible Power Supply (UPS). The green LED illuminates to

indicate the unit is receiving power from the external power supply.

5UsingCat5e/6cable,connecttheRJ45portonthelocalunittothe

RJ45portontheremoteunit.

6Connect the external power supply to the remote unit and plug it

into a Tripp Lite Surge Suppressor, PDU or UPS. The green LED

illuminates to indicate the unit is receiving power from the external

power supply. The orange LED illuminates to indicate the unit is

connectedtoapoweredONlocalunit.

7Connect the remote unit’s HDMI port to a monitor using a Tripp Lite

P568-SeriesHDMICable.

8Turn on the power to the HDMI source. The orange LED on the

local unit illuminates to indicate a signal is being received from the

source.

9If necessary, use the Equalization control on the remote unit to

adjust the video image. Note: An improper Equalization setting

can cause the monitor not to display a picture at all. Try each

Equalization setting until an acceptable picture is displayed.

201109206-93-3023-EN.indd 9 10/24/2011 10:01:20 AM

OPTIONAL LOCAL

MONITOR

B126-1A1 LOCAL

TRANSMITTER

B126-1A1 REMOTE

RECEIVER

B126-110 REMOTE

REPEATER

B126-110 REMOTE

REPEATER

B126-110 REMOTE

REPEATER

Up to 175 ft. at 1080i (60Hz)

Up to 125 ft. at 1080p (60Hz)

Up to 175 ft. at 1080i (60Hz)

Up to 125 ft. at 1080p (60Hz)

BLU-RAY

Up to 175 ft. at 1080i (60Hz)

Up to 125 ft. at 1080p (60Hz)

Up to 175 ft. at 1080i (60Hz)

Up to 125 ft. at 1080p (60Hz)

Extender Kit with Remote/Repeater Installation

Notes:

1) Test to make sure the entire installation works properly before pulling

cables through ceilings/walls.

2) To achieve maximum distance and performance, use 24 AWG solid

wire Cat5e/6 cable. Using stranded wire Cat5e/6 cable, or cable

with a gauge (AWG) size higher than 24 AWG, will result in shorter

extension distance. Higher gauge cabling, such as 26 AWG, has a

more limited transmission capability than lower gauge cabling. All

Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire

cabling.

3) The B126-1A1 and B126-1A1-WP are set to transmit a stereo audio

signal by default. Press the Audio button on the local unit to switch to

7.1-channel surround-sound audio.

4) The installation diagram shows a B126-1A1 unit. The B126-1A1-WP

installation is the same, except there is no local monitor port.

1Make sure the HDMI source is powered OFF.

2ConnecttheHDMIsourcetotheINPUTportontheB126-1A1or

B126-1A1-WPusingaTrippLiteP568-SeriesHDMICable.

201109206-93-3023-EN.indd 10 10/24/2011 10:01:21 AM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Extensor de Tripp Lite

Tripp Lite

Tripp Lite HDMI B122-000-60 Manual de usuario

Tripp Lite

Tripp Lite B126-1A1 Manual de usuario

Tripp Lite

Tripp Lite B126-1A1-PLHD Manual de usuario

Tripp Lite

Tripp Lite P130-000-AUDIO2 Manual de usuario

Tripp Lite

Tripp Lite Cat5 Smart KVM Extender Manual de usuario

Tripp Lite

Tripp Lite B126-004 Manual de usuario

Tripp Lite

Tripp Lite B125-101-60-IR Manual de usuario

Tripp Lite

Tripp Lite B126-1A1-WP Manual de usuario

Tripp Lite

Tripp Lite B126-1P0-MINI Manual de usuario

Tripp Lite

Tripp Lite B203-101-IND-ER Manual de usuario

Tripp Lite

Tripp Lite B127-1A1-CH Manual de usuario

Tripp Lite

Tripp Lite B126-1A1-WHD4HH Manual de usuario

Tripp Lite

Tripp Lite B125-150 Manual de usuario

Tripp Lite

Tripp Lite U444-06N-HD Manual de usuario

Tripp Lite

Tripp Lite B130-101-WP Manual de usuario

Tripp Lite

Tripp Lite B126-1A1-IR Manual de usuario

Tripp Lite

Tripp Lite Wireless Console Extender B014-000 Manual de usuario

Tripp Lite

Tripp Lite B126-1P1M-U-POC Manual de usuario

Tripp Lite

Tripp Lite B130-101A Manual de usuario

Tripp Lite

Tripp Lite B126-2P2M-POC Manual de usuario

Tripp Lite

Tripp Lite B136-101 Manual de usuario

Tripp Lite

Tripp Lite B203-101-PNP Manual de usuario

Tripp Lite

Tripp Lite B130-101S-WP Manual de usuario

Tripp Lite

Tripp Lite B121-000 Manual de usuario

Manuales populares de Extensor de otras marcas

SY HDBT-60T Manual de usuario

Appsys ProAudio

Appsys ProAudio ADX-16 Manual de usuario

Atlona

Atlona RS232 Manual de usuario

IDK

IDK OPF-TH1000-A Manual de usuario

Enable-IT

Enable-IT 824WP Manual de usuario

Worx

Worx Landroid RadioLink WA0864 Hoja de especificaciones

TP-Link

TP-Link TL-WA730RE Manual de usuario

Camplex

Camplex CMX-HDMI-SFPL Manual de usuario

SC&T

SC&T HE03-4K Manual de usuario

Marmitek

Marmitek MegaView70 Manual de usuario

Samsung

Samsung SCS-26UC4 Manual de usuario

Foxun

Foxun SX-GES24 Manual de usuario

MuxLab

MuxLab 500771 Manual de usuario

foxunhd

foxunhd SX-AEX01 Manual de usuario

TERK Technologies

TERK Technologies LFIRX2 Manual de usuario

Devolo

Devolo Audio Extender Manual

Edimax

Edimax EW-7438RPn V2 Manual de usuario

Shinybow USA

Shinybow USA SB-6335T5 Manual de usuario
