TRENDnet TV-IP300W Manual de usuario

TRENDnet's TV-IP300W Internet Camera Server is the perfect

device for remote monitoring and transmitting real-time events over

t h e I n t e r n e t . T h e T V - I P 3 0 0 W f u n c t i o n s a s a

video/audio/surveillance camera allowing you to view live events

with your web browser via Internet or Intranet. Up to 4 cameras can

be remotely managed with the bundled IPViewSP software. This

Internet Camera Server has MPEG4 quality streaming video,

automatic image capture, and event notification via e-mail, making it

the ideal solution for Internet video broadcasting applications.

TV-IP300W

Advanced Wireless Day/Night

Internet Camera Server

TEW-503PI (07-28-2005) TV-IP300W

rev:02.02.2007

• Wi-Fi Compliant with IEEE 802.11b/g Devices on 2.4 GHz ISM Frequency Band

• Wireless Supports Infrastructure and Ad-Hoc Modes

• Wireless Supports WEP 64/128-Bit Encryption (ASCII & HEX)

• Supports High Quality MPEG4 Compression

• Supports Night Vision with IR Lens

• Supports Audio Monitoring and RS-485 Port for PAN & TILT Control

• Supports CCD Image Sensor and DC-Iris Control

• Supports DirectX 9.0 Control for Internet Explorer

• Allows for Remote Access from Web Browser for Live Image Viewing

• Supports TCP/IP networking, SMTP e-mail, HTTP and other Internet related protocols

• Supports Web configuration with password protection

• Powerful Windows IPView SP Application Software for multiple cameras monitoring, image capturing, and video recording

(Windows 98/ME/2000/XP)

• Built-in I/O Ports to Trigger Alarm and Email Notification

• Broad Range of Applications for Monitoring Homes, Offices, Banks, Hospitals, and a Variety of Private and Public Monitoring

• 3-Year Warranty

FEATURES

Resolution

Lens

MIC Input

Speed

Up/Down Reversal

Left/Right Reversal

Quality Selection

Control

Data Rate

Standard

Motion Detection

Bit Rate Selection

Max Frame Rate Selection

• Sharp 1/4” type CCD

• CIF(350x240NTSC, 352x288PAL) • QCIF(176x120NTSC, 176x144PAL)

• 512 x 480(NTSC), 512 x 576(PAL)

• Yes

• Yes (Brightness/ Contrast/ Flicker/ Saturation/ Hue)

• Yes

•

• 11g: 54, 48, 36, 24, 12, 9 & 6Mbps • 11b: 11, 5.5, 2 & 1Mbps

• Built-in f 6.0mm F1.8 IR Lens (CS-Mount Standard, Replaceable)

• Internal MIC (mono) • S/N ratio: More than 60dB • Frequency: 50 ~ 16000Hz

• 24Kbps bit Rate • 8K Sampling Rate

• 8 Levels

• 30fps@CIF(NTSC) • 25fps@CIF(PAL)

• 9 Levels

• 5 Levels

• IEEE 802.11b/g

• Automatic

• DSSS

• Detachable 2dBi Diversity Antenna (Reversed SMA Connector)

Frame Rate

Compression

Audio

Video

Wireless

Sensor

Image Sensor

SPECIFICATIONS

• MPEG4 short header mode compression

Gain/Exposure/White Balanced Control

Modultechnik

Antenna

Iris Level

Frequency

• Adjustable • VR for Iris Control Adjustment

• 2.4 ~ 2.4835Ghz (ISMB)

RELATED PRODUCTS

PACKAGE CONTENTS

TV-IP200W

TPH-5000

TV-IP300 Advanced Day/Night Internet Camera Server

• Utility CD-ROM

• Metal Camera Stand

Wireless Internet Camera Server

• TV-IP300W

• Power Adapter

Outdoor Camera Housing

• Quick Installation Guide

NETWORKING SOLUTIONS

Advanced Wireless Day/Night Internet Camera Server

TV-IP300W

Internet

Cable/DSL

Modem

Office Monitoring

(TV-IP300)

Front Gate Monitoring

(TV-IP300)

Parking Monitoring

(TV-IP300W)

Warehouse Monitoring

(TV-IP300W)

Wireless

Access Point

(TEW-430APB)

100Mbps

54Mbps Wireless

Firewall Router

(TW100-BRF114)

Workstation with

PCI Adapter

(TE100-PCIWN)

TV-IP300W

rev:02.02.2007

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

Advanced Wireless Day/Night Internet Camera Server

TV-IP300W

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

SPECIFICATIONS

System

Generic Output

RAM/Flash ROM

Generic Input

RS-485

Memory Size

Weight

Application

LED

Power

Certifications

LAN

Consumption

Protocol

Dimension

Browser

Temperature

Stand Height

OS Support

Humidity

• xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

• 2 pin (Half Duplex)

• 128M (256 Recommended)

• 270 grams (9.5 oz)

• IPView SP Software

• Power: Blue • Link/Active: Red

• 7 watt ( 580mA x 12V), max

• HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP, TCP/IP, DDNS, UPnP

• Pentium III, 450 MHz or above • VGA card resolution: 800 x 600 or above

• 16Mbytes/2Mbytes

• 1 set, 2 pin (photo coupler, 12V DC 50mA max)

• Philips Trimedia • PNX1300 VLIW DSP

• Linux

• 120 mm (4.7 inches)

• Windows 98SE, ME, NT4, 2000,XP

• 5% ~ 95% Non-Condensing

• 195x90x50 mm (7.7x3.5x2 inches)

• IE 5.0 or above

• Operating: 5°C ~ 40°C (41°F ~ 104°F) • Storage: -25°C ~ 50°C (-13°F ~ 122°F)

• 12V DC, 1.5A External Adapter

• FCC. CE, VCCI Class B

• 10/100Mbps Ethernet, Auto-Sensing

CPU

I/O & Control

Requirements

Physical/Environmental

Software

Communication

• 1 set, 2 pin (relay, 24V DC 1A/125V AC 0.5A)

* NTSC: US Version; PAL: AU/EU/UK Version

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com
