PRODUCT OVERVIEW

• Night vision up to 7.5 meters indoors*

• Pan 340° side-to-side and tilt 115° up-and-down

• High speed wireless n connection

• Program motion detection recording, recording schedules, email alerts and more with complimentary software

• 1-way audio

TV-IP651WI

Rev: 03.15.2012

Wireless N Day / Night PTZ Internet Camera

TV-IP651WI (v1.0R)

The Wireless N Day / Night PTZ Internet Camera, model TV- IP651WI,

provides day and night security over a large area. Pan the camera

side-to-side a remarkable 340 degrees and tilt up-and-down 115 degrees

from any Internet connection. Record indoor video in complete darkness for

distances of up to 7.5 meters. Wireless n technology provides unsurpassed

wireless coverage and improved streaming video quality. Add this camera

to your wireless network at the touch of a button with Wi-Fi Protected Setup

(WPS).

Record 640 x 480 pixel (VGA) video at up to 20 frames per second (fps).

Manage up to 32 TRENDnet cameras with the included complimentary

camera management software. Advanced features include adjustable motion

detection recording areas, email alerts, scheduled recording sessions,

pan / tilt Auto-Patrol, date-and-time overlays, one-way audio, an adjustable

lens, and four times digital zoom. A wall / ceiling mounting kit is included and

the camera’s off white housing blends into most environments.

Wireless N Day / Night PTZ Internet Camera

TV-IP651WI (v1.0R)

TV-IP651WI

Rev: 03.15.2012

FEATURES

• Wi-Fi compliant with IEEE 802.11n standard

• Backwards compatible with IEEE 802.11g and IEEE 802.11b devices

• One touch WPS connection button

• 1 x 10/100Mbps Auto-MDIX RJ-45 port (for optional wired installation)

• Power and activity LED indicators (can be disabled)

• Night vision up to 7.5 meters indoors*

• 1-way audio

• 4 x digital zoom

• Pan left or right 170° for a total of 340°

• Tilt the camera up 90° and down 25° for a total of 115°

• Dynamic DNS support

• Supports up to 640 x 480 pixel resolution at up to 20 frames per second (fps)

• Image controls: Brightness, contrast, saturation, ﬂ ip image vertically, mirror image horizontally, and day / night mode

• Deﬁ ne a recording schedule or motion detection recording

• Create motion detection ﬁ elds over the viewing area

• Supports TCP/IP networking, Email, HTTP, and other Internet protocols

• System controls:

• Deﬁ ne up to 64 user login accounts

• Set the date and time or synchronize with an NTP server

• Supports wireless encryption up to WPA2-PSK

• Quick Universal Plug and Play (UPnP) installation

• Complimentary SecurView™ Pro software: manage up to 32 cameras **

• SecurView™ Pro software compatible with Windows operating systems

• Mounting base and mounting hardware included

• 3-year limited warranty

*This camera is designed for indoor use. For outdoor surveillance applications we recommend TRENDnet outdoor cameras

**Monitoring multiple cameras may require a high performance CPU

Wireless N Day / Night PTZ Internet Camera

TV-IP651WI (v1.0R)

TV-IP651WI

Rev: 03.15.2012

SECURVIEW PRO CAMERA SOFTWARE FEATURES

• Manage up to 32 cameras

• Compatible with Windows and Microsoft Server 2008

• Multiple language support

• Camera Viewing

• Preset viewing modes

• Program custom viewing modes

• Full screen view

• Drag and drop live feeds to a new location

• Program camera cycle viewing sequence

• Motion detection brings video forward

• Side, top, and bottom tool bars can be hidden

• Web based access from smart phones and tablets

• Recording options

• Program weekly recording schedules

• Motion detection recording

• Deﬁ ne motion detection areas of any shape

• Deﬁ ne motion detection sensitivity

• Event trigger recording

• Date and time overlay

• Mask overlay to conceal sensitive areas

• Save a single video stream to multiple locations simultaneously

• Deﬁ ne recording quotas by recording time or space allocation

• Disk clean feature condenses and optimizes old ﬁ les

• Real time recording stats to help manage ﬁ les

• Search and Playback

• Navigation timeline provides a quick visual reference to the recorded content

• Search continuous recordings by motion

• Search recordings by motion within a deﬁ ned ﬁ eld (a portion of the viewing area)

• Time laps playback search

• Map cameras on an image such as a ﬂ oor plan

• Map cameras on Google Maps™

Wireless N Day / Night PTZ Internet Camera

TV-IP651WI (v1.0R)

SPECIFICATIONS

CAMERA

General • Sensor: 1/5” CMOS Sensor

• Board Lens

• Focal Length: 4 mm

• F/No: 1.5

• Minimum illumination: 0 lux

• Focus Depth: 20 cm ~ inﬁ nity

• View:

• Horizontal: 38.0 degrees

• Vertical: 28.7 degrees

• Diagonal: 46.5 degrees

• Digital Zoom: 4x

Audio • Built-in omni-directional microphone

• Sensitivity: -38dB +/- 3dB (5 meters max.)

• Frequency: 100~20000Hz

• S/N: >60dB

• Format: PCM

Pan & Tilt • Pan: -170° ~ +170°

• Tilt: up 90°and down 25°

• Auto-Patrol preset positions: 24

Day / Night • Built-in ICR

• Night vision (IR) supports up to 7.5 meters

HARDWARE

Network • IEEE 802.3u 10/100Mbps Auto-MDIX Fast Ethernet

LED • Power, Link/Act

WPS Button • Push to enable WPS

Reset Button • Reset to factory default

Privacy Button • Privacy mode on / off

Power Consumption • Max 7.2 Watts

Power • Input: 100~240V, 50/60Hz, 0.5A

• Output: 12V, 1.25A external power adapter

Dimension • 113 x 113 x 130 mm (4.5 x 4.5 x 5.1 in.)

Weight • 505 g (1.1 lbs.)

Temperature • Operating: 0°C ~ 40°C (32°F ~ 104°F)

• Storage: -25°C ~ 70°C (-13°F ~ 158°F)

Humidity • Max 90% (non-condensing)

Certiﬁ cations • CE, FCC

REQUIREMENT

Management Interface • Internet Explorer 7.0 or higher

• Firefox 3.5 or higher

• Safari 4.0 or higher

To Run software • Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)

• Windows Server 2003, 2008

SecurView Software • Channel: supports up to 32 cameras

• Record / Playback / Motion Detection / Audio

Network Protocols • IPv4, ARP, TCP, UDP, ICMP

• DHCP Client, NTP Client, DNS Client, DDNS Client, SMTP Client, FTP Client

• HTTP

• PPPoE

• UPnP

TV-IP651WI

Rev: 03.15.2012

SPECIFICATIONS

WIRELESS

Standard • IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n

Frequency • 2.4 ~ 2.497 GHz ISM band

Antenna • 1 x detachable 2dBi dipole antenna (Reverse-SMA connector)

Date Rate • 802.11b: up to 11Mbps

• 802.11g: up to 54Mbps

• 802.11n: up to 150Mbps

Security • 64/128-bit WEP, WPA / WPA2-PSK

Output Power • 802.11b: 18dBm (typical)

• 802.11g: 15dBm (typical)

• 802.11n: 15dBm (typical)

Receiving Sensitivity • 802.11b: -85dBm at 11Mbps

• 802.11g: -76dBm at 54Mbps

• 802.11n: -65dBm at 150Mbps

Channels • 1~11 (FCC), 1~13(ETSI)

MANAGEMENT

Accounts • Up to 64 user accounts

Remote Login • Remote management supported

Backup / Restore • Save / retrieve conﬁ guration ﬁ les

SETTINGS

Image • Brightness, contrast, saturation, ﬂ ip, mirror (horizontal / vertical)

Video Setting • Encoding: MJPEG

• Resolution: 640 x 480, 320 x 240, 160 x 120

• Max frame rate: VGA @ 20fps, QVGA @ 30fps, QQVGA @ 30fps

• JPEG quality: Very Low, Low, Medium, High, Very High

Recording • Event based (motion detection) and scheduled

Snapshot • Trigger event: motion detection

• Action: send alert email and / or upload to FTP

• Real time snapshot

Port Settings • HTTP port: 80 (default)

Time • Synchronize with NTP server or set time / date manually

Wireless N Day / Night PTZ Internet Camera

TV-IP651WI (v1.0R)

TV-IP651WI

Rev: 03.15.2012

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TV-IP651WI

CD-ROM (Utility & User’s Guide)

Multi-Language Quick Installation Guide

Network cable (1.5 m / 5 ft.)

Power adapter (12V DC, 1.25A)

Camera mounting kit
