StarTech.com ST121UTPEP Manual de usuario

VGA Video Extender over

Cat5

VGA Video Extender over Cat5

- Point to Point

ST121UTPEP

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

Installation....................................................................... 1

Hardware Installation...................................................................1

Receiver Unit/Transmitter Unit.....................................................2

Distances and Resolutions ............................................ 2

Speciﬁcations.................................................................. 3

Technical Support........................................................... 4

Warranty Information...................................................... 4

Introduction

Packaging Contents

1 x ST121UTPEP Transmitter Unit•

1 x ST121UTPEP Receiver Unit•

1 x Power Adapter•

1 x Installation Bracket•

1 x Instruction Manual•

System Requirements

VGA capable output on video source•

VGA capable monitor/display•

Installation

Hardware Installation

Turn off the PC and remote display.1.

Connect the ST121UTPEP Transmitter unit’s “VGA In” connector2.

with a standard VGA (DE-15) male to male cable to PC video card.

Connect the ST121UTPEP Transmitter and ST121UTPEP Receiver3.

units together with a straight through Cat5e cable.

Connect the ST121UTPEP Receiver unit’s “VGA Out” connector with4.

a standard VGA (DE-15) male to male cable to the monitor/display.

Connect the power adapter to either the Transmitter unit or Receiver5.

Unit, whichever is more convenient. It is not necessary to have

power connected to both.

Turn on the monitor and PC.6.

Receiver Unit/Transmitter Unit

Distances and Resolutions

50m 1920x1200 / 1600x1200

80m 1280x1024 / 1024x768

Power LED

RJ45 port

Power

Connector

“VGA Out” to

monitor/display

“VGA In” from

video source

Installation

Bracket

Specications

Connectors (Transmitter Unit)

DE-15 VGA connector•

RJ45 Ethernet connector•

DC Power connector•

Connectors (Receiver Unit)

DE-15 VGA connector•

RJ45 Ethernet connector•

DC Power connector•

Maximum Resolution 1920x1200 (50 m/150 ft)

Maximum Distance 80 m (250 ft)

Operating Temperature 0 - 70 degrees C

Storage Temperature -20 - 85 degrees C

Dimensions 100.0 mm x 138.0mm x 25.0 mm

Weight Transmitter: 135 g•

Receiver: 140 g•

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government, education

and industrial facilities to name just a few. We offer an unmatched

selection of computer parts, cables, A/V products, KVM and Server

Management solutions, serving a worldwide market through our

locations in the United States, Canada, the United Kingdom and

Taiwan.

Visit www.startech.com today for complete information about all

our products and to access exclusive interactive tools such as the

Cable Finder, Parts Finder and the KVM Reference Guide.
