StarTech.com USBthere USB100EXT Manual de usuario

USBthere - 1 Port Bus Powered 330 Foot (100 meter) USB Webcam Extender

StarTech ID: USB100EXT

Boost the distance of your USB connection with the USBthere, a one-port USB extender from StarTech.com.

You’ll be able to place your USB device up to 330 feet (100m) away from your computer, an incredible 20

times greater than normal USB cable length restrictions. The Local and Remote units connect using

standard Cat 5e Ethernet cable and there’s no need to buy additional hubs, repeaters, power adapters

or software, you just plug in and go.

Perfect for security and surveillance devices like USB video cameras, the USBthere maintains the

USB 1.1 standard with data transfer rates of up to 12 Mbits/sec. Extending the range of your USB

devices has never been easier.

Note: Not for use with low speed devices like mice or keyboards. Please use the USB110EXT or USB120EXT

for low speed USB devices

Applications and Solutions

> Ideal for use with remote digital recorders, USB web cameras, printers, scanners and other full-speed USB devices

> Security/Surveilance

Features

> Extends the range of one USB device up to 330 feet (100 meters) using standard Cat 5e Ethernet cables

> Compliant with USB 1.1 specifications

> Data transfer rates of up to 12 Mbits/sec

> Comes complete with a 6 foot USB cable

> Requires no external power adapter

Specifications

> Color Black

> Enclosure Type Plastic

> Product Height 1.18 in [30 mm]

> Product Length 3.94 in [100 mm]

> Number of Ports 1

> Operating Temperature 4 to 40

> Carton Quantity 30

> Industry Standards USB 1.1

> Shipping (Package) Weight 0.84 lb [0.38 kg]

> Product Weight 3.53 oz [100 g]

> Product Width 2.76 in [70 mm]

> Extension Distance 330 feet (100 meters)

> Data Transfer Rate Up to 12 Mbits/sec

> Local Unit Connectors Upstream: 1 x 4 pin USB (Type B)<br>Downstream: 1 x RJ-45

> Remote Unit Connectors Upstream: 1 x RJ-45<br>Downstream: 1 x 6 pin USB (Type A)

> USB Hub Support Up to 5 hubs connected to the local unit

> Dimensions 3.9 x 2.7 x 1.2 Inches (100 x 70 x 30 mm)

> Weight 0.2 lbs (0.1 kg)

> Maximum power available to USB at the Remote Unit 300 mA when the Local Unit is supplied with 500
