StarTech.com ST222HDBT Manual de usuario

Manual Revision: 08/02/2018

User Manual

For the latest information and specications visit

www.startech.com/ST222HDBT

Dual HDMI over CAT5e/CAT6 Extender - 1080p

Actual product may vary from photos

SKU#: ST222HDBT

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names

and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Product installation and/or mounting should be completed by a certied

professional as per the local safety and building code guidelines.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• L’installation et/ou le montage du produit doit être réalisé par un

professionnel certié et dans le respect des normes locales et du code de

construction local.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでください。

• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に従い、有資格の専門業者が行うようにしてください。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回しを行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un

tecnico professionale certicato che conosca le linee guida locali sulle norme

edilizie e sulla sicurezza.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Installation och/eller montering får endast göras av behöriga yrkespersoner

och enligt gällande lokala förordningar för säkerhet och byggnormer.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Warning Statements

Make sure to assemble this product according to the instructions. Failure to do

so might result in personal injury or property damage.

Never use this product if parts are missing or damaged.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................3

Warning Statements ..............................................................................4

Product Diagram ....................................................................................4

Transmitter Front....................................................................................................................................... 4

Transmitter Back........................................................................................................................................ 4

Receiver Front............................................................................................................................................. 5

Receiver Back.............................................................................................................................................. 5

Product Information ..............................................................................6

Package Contents ..................................................................................................................................... 6

Requirements ............................................................................................................................................. 6

Installation ..............................................................................................7

Installing the HDMI Transmitter/Receiver ........................................................................................ 7

Optional Installation..............................................................................8

Installing the Ground Wire..................................................................................................................... 8

Connecting a Serial Device.................................................................................................................... 9

Using Digital Audio................................................................................................................................... 9

Using 3.5 mm Audio................................................................................................................................. 10

Using a Microphone................................................................................................................................. 10

Installing the IR Receiver and IR Blaster............................................................................................ 11

Video Resolution Performance ............................................................12

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Conguration..........................................................................................12

EDID Copy.................................................................................................................................................... 12

LED Indicators.........................................................................................13

Mounting the Extender.........................................................................13

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Actual product may vary from photos

Transmitter Front

Transmitter Back

EDID Copy

Button

RS-232

Port IR Out

Port IR In

Port Toslink In

Port

Grounding

Screw

DC 12V

Serial Mode

Switch

RJ45 Port

HDMI In 1

Port HDMI In 2

Port

Audio In

Port Audio Out

Port

LED

Indicator

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Receiver Front

Receiver Back

EDID Copy

Button

RS-232

Port

IR In

Port IR Out

Port

Toslink

Out Port

Grounding

Screw

DC 12V RJ45 Port

HDMI Out

1 Port

HDMI Out

2 Port

Audio Out

Port Mic In

Port

LED

Indicator

Serial Mode

Switch

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Information

Package Contents

• HDMI Transmitter x 1

• HDMI Receiver x 1

• Universal Power Adapters (NA/JP, EU, UK, ANZ) x 2

• Set of Mounting Brackets x 2

• IR Blaster x 1

• IR Receiver x 1

• CAT5 Cable x 1

• Rubber Feet x 8

• User Manual x 1

Requirements

For the latest requirements, please visit www.startech.com/ST222HDBT

Installation:

• Phillips Head Screwdriver x 1

• Grounding Wire x 1

• Level x 1

• Writing Utensil x 1

Display:

• HDMI Display (e.g. television, projector, etc.) x 2

Devices:

Device requirements are optional and will depend on the setup.

• HDMI Video Source (e.g. host computer, Blu-ray player, etc.) x 2

• Serial Communication Device x 1

• Audio Device x 1

• Microphone x 1
