Socket SocketScan S550 Manual de usuario

Socetscn®S550

NFC Moble Wllet Reder

User Gude

Bluetooth® wireless technology

NFC Mobile Wallet Reader

socketmobile.com

Table of Contents

  550

Package Contents � � � � � � � � � � � � � � � � � 3

Optional Customization � � � � � � � � � � � � � � � 4

Charge the Battery � � � � � � � � � � � � � � � � � 5

Powering on/off � � � � � � � � � � � � � � � � � � 6

Reading NFC Tags � � � � � � � � � � � � � � � � � 7

 

Bluetooth Connection Modes � � � � � � � � � � �8-12

 

Configuration � � � � � � � � � � � � � � � � � 13-15

How to perform Factory Reset � � � � � � � � � � � 16

How to replace your battery � � � � � � � � � � � � �17

 

Status Indicators � � � � � � � � � � � � � � � � � 18



Product Specifications � � � � � � � � � � � � � 19-20

  

Helpful Resources � � � � � � � � � � � � � � � � �21

Limited Warranty� � � � � � � � � � � � � � � � � �31

   

Helpful Resources � � � � � � � � � � � � � � � � �21

Safety and Handling Information � � � � � � � � � � 22

Bluetooth Device United States � � � � � � � � � 23-27

Battery Warning Statements � � � � � � � � � � � 28-29

Regulatory Compliance � � � � � � � � � � � � � � 30

SocketScan S550

Security Cable

Active Surface

Thn ou for choosn Socet Moble

Let’s et strted

Membership

Demo Pass

Socket Mobile New Membership Pass

https://socketmobile.com/new-member-passes

TAP OR SCAN TO GET PASS

Package Contents

Charging Cable

Tap Here sticker

DuraScan™, Battery Friendly® are registered trademarks or trademarks of Socket Mobile, Inc�

Microsoft® is a registered trademark of Microsoft Corporation in the United States and other

countries� Apple®, iPad®, iPad Mini®, iPhone®, iPod Touch®, and Mac iOS® are registered trade-

marks of Apple, Inc�, registered in the U�S� and other countries� The Bluetooth® Technology

word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc� and any use

of such marks by Socket Mobile, Inc� is under license� Other trademarks and trade names are

those of their respective owners�

Optional Customization: Security Cable

Attch Securt Cble

Step 4

Pull tight so the string loop is secure�

Step 3

Pull the gimbal through the string

loop�

Step 2

Feed the string loop through the

eyelet�

Step 1

Remove battery door�

Mounting the S550

Step 1

Remove the screw and turn the battery door counterclockwise

to unlock� Remove the S550 battery door� The battery door

will not be used when using the Security Base�

If our S550 cme wth the Securt Bse ssembled,

sp to Step 4

Step 2

Line up power button with screw hole and place S550 onto

the security base� Rotate S550 counterclockwise 15 degrees to

lock into security base�

Step 3

Screw in set screw to secure the S550 to the security base�

Step 4

Mounting the S550 with Security Base�

1� Determine placement of the S550�

2� Remove adhesive from the bottom of the base�

3� Press the S550 down to secure�

Warning: adhesive tape is very strong and once the device is

placed using the tape, it will be difficult to remove�

Removing the Security Base

Step 1

Loosen set screw from the

Security Base�

Step 2

Rotate S550 clockwise

to unlock and separate

the Security Base from

the S550�

Step 3

Screw on the battery door to the S550�

Charge the Battery

The S550 must be fully charged before first use� Please allow

8 hours uninterrupted charging for the initial battery charge�

The reader can be battery operated for up to 8 hours or

connected to power for all day business use�

Yellow Lht = Charging Green Lht = Fully charged

Important: Charging from a computer USB port is not

reliable and not recommended.

Charging connector

Powering on/off

Powern On

Press and hold down the power button until the ring light

turns on and the S550 plays a melody�

*Automatically turns on when plugged in to the cable�

*Power button

Reading NFC Tags

Redn NFC ts nd moble psses

1� Launch your business app or Socket Mobile’s Nice 2CU

app�

2� Place tag/mobile pass on top of the S550�

By default, the S550 will beep and the ring light will change

to blue, to confirm a successful reading�
