HDMI over HDBaseT Extender

User Manual

Model : HE02P

4K HDMI & IR/RS232/Ethernet/PoH CAT5e Extender 100M

User Manual

HE02P

Introduction

HE02P is a 4K HDMI over HDBaseT™ extender that can use a Ethernet cable to send uncompressed HDMI

bi-directional IR and RS232 signals with resolution up to 4K@60Hz 4:2:0 and transmission distance up to

100M. The extender also supports PoH (Power over HDBaseT), designed to provide power from one side

(TX/ RX) to another. A built-in Ethernet port with 10/100 bandwidth on both TX and RX sides allows HE02P to

connect with standard network devices such as 100Base-T routers, hubs, and computers.

Features

Resolution up to 4K@60Hz 4:2:0.

Signal extension up to 100M over CAT5e/6 cable.

Built-in 2 10/100Mbps Ethernet ports for network devices.

Support PoH (Power over HDBaseT™), no external power required for RX unit.

Supports bi-directional IR, RS232 transmission.

Supports EDID, and CEC pass through.

Installation view

Cable

Link cable recommend use high quality Cat.5e、Cat.6、Cat.6a、Cat.7 UTP / STP or FTP cable. Poor quality

cable or network connection or improper construction will cause unstable connection, video or sound

disruptions, picture noise appears.

Transmission Distance

The maximum transmission distance up to 100meters, use lower resolution won’t extend longer distance.

User Manual

HE02P

HDBaseT Distance chart by different cable

Cable Type

Range

Pixel Clock Rate

Video Data Rate

Supported Video

CAT5e / CAT6

100m

<=225Mhz

<=5.3Gbps

(HD Video)

Up to

1080p 60Hz 36 bits

70m

>225Mhz

>5.3Gbps

(Ultra HD Video)

1080p 60Hz 48bits,

1080p 60Hz 3D,

4K x 2K 30Hz

CAT6a / CAT7

100m

If connection through the wall socket, the cable length must less 5 meters between HDMI extender and

wall jack, as below drawing:

10/100Mbps network connection using general CAT5e cable and working distance up to 100M.

RJ45 Define

LED Indication

HDMI Port Status LED

Color

LED Function

HE02PT

HE02PR

Green

Power

On: Power On

Blue

IR Receive

On: IR Received Signal

Red

IR Emitter

On: IR Emitting

Transmitter

Wall Jack

Receiver

MAX 100M

< 5M

User Manual

HE02P

HDBaseT Port Status LED

Color

LED Function

HE02PT

HE02PR

Green

HDBaseT Linking

On: HDBaseT Linking , Flash: Low Power Mode

Blue

Reserve

No Function

Red

HDMI

On: With HDCP , Flash: Without HDCP , Off: HDMI Unlink

10/100 Ethernet Port

Color

LED Function

HE02PT

HE02PR

Green

Ethernet Linking

On: Linking , Flash: Data Transmission

Yellow

Reserve

No Function

Low-power Mode

When there is no HDMI video signal input, or TV is not connected or power off, this product will enter a

low-power mode to save power consumption of, under a low power mode still provides Ethernet, RS-232

(Max. 9600bps), IR, CEC of signal transmission.

Caution

1. The wiring must away from any equipment with electromagnetic wave, i.e.: mobile phone, microwave,

radio equipment, fluorescent lamp, high voltage power lines.

2. This device HDBaseT port is not general Ethernet signal which also carry power, do not connect with

Network to avoid damage.

3. IR transmitter do not put near from receiver to avoid mutual interference.

Panel view

HE02PT

HE02PR

User Manual

HE02P

Package Include

Transmitter x 1 piece

Receiver x 1 piece

Power adapter DC24V 1AMP x 1 piece

IR Emitter cable x 2 pieces

IR Receiver cable x 2 pieces

User Manual

HE02P

Specification

ITEM NO.

HE02PT

HE02PR

Support

Compliance

HDMI 1.4, HDCP, DVI

Max. Video Resolution

4K@30Hz 4:4:4

Max. Transmission Distance

100M over CAT6 or greater cable

Video Bandwidth

10.2 Gbps

Audio Format

7.1 LPCM 192KHz, Dolby TrueHD, DTS-HD MA

Network Bandwidth

10/ 100Mbps

IR Support

30-60Khz, ±15°, 5M, Bi-directional

30-60Khz, ±55°, 5M,

Bi-directional

RS232 Baud Rate

115200 bps/ Full Duplex

Ports & Interfaces

Video Input

1 x HDMI Type A

1 x HDBaseT

Video Output

1 x HDBaseT

2 x HDMI Type A

Ethernet Interface

1 x RJ45

RS232 Interface

1 x DB9 Female

1 x DB9 Male

IR Interface

1 x 3.5mm Phone Jack

Power

Power Supply

DC 24V 1A Regulated

Power from HE02PT

Power Consumption

15W (Max), 5W (Low Power) in Total

Ambient Temperature

Operation

0 to 55℃

Storage

-20 to 85℃

Humidity

up to 95%

Physical Characteristics

Dimensions

88 x 135 x 30mm

Weight

300g
