Ranger design ACCESS STOW Manual de usuario

ACCESS STOW

OPERATOR'S MANUAL

ACCESS STOW

LOADING INSTRUCTIONS

Release the latch and pull

the system out.

• CAREFULLY place ladder

onto the system.

DO NOT DROP!

• Pull strap upwards to tighten,

DO NOT USE beltstow when

storing ladder.

1-800-565-5321 /rangerdesign.com

4• Set as shown and tighten

bolts to 12Nm. Highest

rung within reach.

• Pull strap downwards to

tighten, DO NOT USE

beltstow when storing

ladder.

Set Load Stops against

the side of the ladder.

ACCESS STOW

OPERTING INSTRUCTIONS

LOWER LADDER

Release the latch and pull

the system out.

Pull down. Beware of

overhead obstructions.

1-800-565-5321 /rangerdesign.com

RAISE LADDER

Pull up. Beware of overhead

obstructions.

Push forward untill the

latches are engaged

There are 5 different settings to suit

the weight on the system.

Gas ram 'gas spring' can be adjsuted.

Optimum Adjustment & setup Guide

The Access Stow setup is inuenced and effected by the following

physical factors:

1. Ladder weight

2. Ladder Height

3. Quantity of ladder ( i.e 1 or 2 ladders, if applicable )

To provide optimum performance of your ladder lift assistance

& drop down, there is a degree of adjustment to aid the weight

& length of your ladder type.

These two form of adjustment are provided by:

1. The gas ram 'gas spring' hole position.

2. The centre Access Stow extrusion drop height.

! Please refer to the chart below to aid the

optimum setting and safe ladder weight and

sizes which can be accommodated.

As an Example:

A high roof van model with 118" length ladder weighing 53lbs,

should be set on position F5 on the gas ram lobe 'gas spring', with

the drop down height of the centre extrusion set to 2.6m on the

underside increment ruler scale.

In this instance a double ladder option can be specied as the total

weight of the 118" ladders does not exceed the maximum

permissible carrying weight of some 132lbs.

ACCESS STOW

SETUP INSTRUCTIONS

1-800-565-5321 /rangerdesign.com

RAM PromAster & medium roof ford trAnsit

Sprinter, trAnsit HiGH roof & nissAn nV

ACCESS STOW

ANTI THEFT INSTRUCTIONS

MIN. 47"

Fit single SafeClamp as shown.

Fit Double SafeClamp as shown.

There is a location for a padlock

if desired. (Padlock not

provided).

1-800-565-5321 /rangerdesign.com

ACCESS STOW

MAINTINANCE INSTRUCTIONS

ACCESS STOW

WARNING

The system will carry a maximum of

triple section ladder.

Apply oil to pivot points

when required.

DO NOT climb on the system.

[email protected]

1-800-565-5321

rangerdesign.com
