Quantum E240 Manual de usuario

E240

User Manual

The New Vision of Touch™

Downloaded from Elcodis.com electronic components distributor

E240

User Manual

OVERVIEW

The E240 is designed to let you evaluate and develop with the QT240 4 key QTouch™ IC. It

includes four independent touch sensitive electrodes with corresponding LEDs to indicate

touch. Connections are provided for external interfacing. The E240 is powered from an

external 7V to 12V DC source (such as a common 9V battery).

For more detailed information about this product please refer to the latest QT240

datasheet at www.qprox.com/datasheets.

Materials Provided:

1 x Clear plastic panel

1 x E240 self-adhesive eval board with battery clip

1 x 9V battery

4 x Rubber feet

2 x Sample QT240-ISS chips

1 x QRG product CD-ROM (with QT240 datasheet but check website for latest)

1 x User guide

Downloaded from Elcodis.com electronic components distributor

BOARD MOUNTING

The E240 can be adhered to plastic, glass, or any other dielectric panel with its peel-back

adhesive strip. You do not have to use the supplied panel if you would rather stick it on your own

panel. Here’s how to mount it:

1Place the plastic panel face down on a table; tape down the edges of the panel to the table

so it cannot move.

2Remove the peel-back paper from the E240 PCB and adhere the E240 to the back of the

panel. Flex the E240 slightly while pressing down lightly on it to help eliminate trapped air.

Take care to flex the board only slightly to prevent the delicate SMT parts on the board from

cracking and failing.

Tip: Line up the PCB with the alignment marks on the back of the slider panel. The PCB must

be positioned as shown below so that the keys line up with the graphics.

3 Un-tape the board from the table, and mount the four rubber feet as shown above to make

the E240 mechanically stable in use.

Downloaded from Elcodis.com electronic components distributor

RUNNING THE E240

To run the E240, simply:

1Place the E240 on a table, touch side up.

2Connect the 9V battery while making sure your fingers are clear of the touch areas to allow

proper no-signal calibration.

The E240 is now ready to use! Touch the keys to see the LEDs light up.

A continuous touch of 10 seconds will cause the key to recalibrate. Releasing the key

after such an event and waiting a few seconds will cause the key to recalibrate yet again,

and the key will function normally thereafter.

Downloaded from Elcodis.com electronic components distributor

THEORY OF OPERATION

The E240 scans the keys using bursts of charge-transfer pulses. Immediately after power up, the

signals from these bursts are used to calibrate the baseline reference values of the keys. This

makes the device highly adaptive to mechanical differences (i.e. varying panel thicknesses). The

QT240 chip also performs drift compensation on a continuous basis, so that the signals are

constantly being adjusted at a slow rate to accommodate drift.

The calibration process (done at power-up) should be performed in a ‘not disturbed’

neutral condition, i.e. all fingers away from the keys and with the board situated in the

location where it will be used. Changes in location can alter the amount of signal coupling

from the board back to the local environment and thereby change the sensitivity of the

keys. If the calibrations are in error, just leaving the board alone for up to 30 seconds will

allow the drift calibration process to settle the keys into the correct calibration values.

The QT240 features spread-spectrum pulse modulation which heavily suppresses external noise

effects, while also suppressing radiated emissions. This powerful feature provides for highly

reliable, compliant operation under a wide variety of operating conditions.

The QT240 chip also uses a ‘Detect Integrator’ to protect against false detection reporting by

verifying that a key is reporting touch for 6 bursts in a row; if the device fails to detect a touch

during any of these 6 signal samples the chip will refuse to report a key touch on an Out pin.

Combined with spread-spectrum operation, the detect integration process provides a powerful

mechanism to suppress false detections from external noise sources.

If a key is touched for longer than 10 seconds, the key is flagged as a ‘stuck key’ and the QT240

recalibrates it so that the corresponding LED will go out, and the key will operate again normally

while suppressing the object (ie, a touch) that caused the prolonged detection. Only the ‘stuck

key’ is recalibrated, as all electrodes operate independently. The 10s timeout can be changed to

60s or infinite with jumpers; see page 10 for details.

Downloaded from Elcodis.com electronic components distributor

BOARD DETAILS

The E240 is a simple double-sided PCB on industry standard FR4 material. All parts are

standard surface mount types. Here is a brief description of some of the parts and features.

Keys — Keys consists of capacitive electrodes formed using copper areas on the E240 which

project a capacitive field through the overlying dielectric panel material.

Electrodes — Copper areas on the PCB which define the touch keys.

LEDs — The board has one ‘Power’ LED which remains on as long as the board is powered,

plus one LED per key to indicate touch.

Connector CN1 — The main interface connector is located at one end of the E240 board. The

pinout of this connector is shown in Table 1 (next page). The pin functions are as follows:

[1] SYNC — Not used in fast mode (the default setting). SYNC is available in slow mode

only and is used to synchronize the E240 burst with an external falling edge signal,

usually derived from a 50 or 60Hz source to suppress mains interference, or to allow

two or more QT240 chips to synchronize to to each other, to prevent cross-interference

effects between the adjacent keys of different chips.

[2..5] OUT ‘A’ ~ OUT ’D’ — OUT pins are low when the corresponding key is inactive and

high when active, and are controlled by the QT240 chip. These lines also control the

LEDs.

[6] /RESET — Can be left floating, as the board has its own internal reset circuit. To reset

the E240 externally (for example to force all keys to recalibrate), connect RESET to

GND for at least 1ms, then release it; the board will restart, recalibrate and be ready to

detect touches again after about 180ms.

[7, 8] +POWER, GND — Use +7 to +12VDC connected between the +POWER and GND to

power the E240 board. The battery snap feeds the same two connections, and can also

be used for power input.

Downloaded from Elcodis.com electronic components distributor

BOARD LAYOUT

Figure 1 —

Board Layout

Electrodes

(on user side)

Battery Connector

Connector (CN1)

Table 1 — Connector (CN1) Pinout

Pin Description Pin Description

1 SYNC 5 OUT ‘A’

2 OUT ‘D’ 6 /RESET

3 OUT ‘C’

7 GND (Ground, 0V)

4 OUT ‘B’ 8 +POWER (+7 .. +12V)

Downloaded from Elcodis.com electronic components distributor

SCHEMATIC

Figure 2 — Schematic Diagram

Downloaded from Elcodis.com electronic components distributor

PCB LAYERS

Figure 3 — Silk Layer

Figure 4 — Top Layer (user side)

Downloaded from Elcodis.com electronic components distributor

BOARD OPTIONS

Warning: Changing components on the board involves soldering and unsoldering; please take

care not to overheat the board or to leave excessive flux which can affect signal stability

and performance. If in doubt, clean the board with a commercial flux remover and dry it prior to

use.

Figure 5 — Jumper Positions Showing Default Configuration

The E240 as shipped is factory configured to operate in fast mode with spread spectrum

enabled, and with a 10-second recalibration delay. The user can re-configure the jumpers to

change these settings using zero-ohm 0603 SMD resistors or bits of fine wire.

See next page for available jumper combinations.
