Quantum DLT 8000 Manual

123456

How to care for, handle, inspect

and ship your cartridges.

DLTtape

Media Care

Guide

www.quantum.com

123456

Why Media

Care Is

Important

Get To Know

Your Cartridge

Media Care

Overview

Visual

Inspection

Shipping

and Storing

Cartridges

Quick Guide:

Do’s + Don’ts

DLTtape cartridges

are engineered to be

reliable, robust and

durable.

To get the most from

your DLTtape media

follow the guidelines in

this booklet.

The safety of your data

relies on proper care

and handling.

• Cartridge features

• Write protect switch

• Protecting

your cartridge

• Labeling your cartridge

• If you drop

your cartridge

• Proper storage

conditions

• When do I perform

a visual inspection?

• Performing a

visual inspection

• Spotting damaged

cartridges

DLTtape Media and

Super DLTtape Media

• How do I ship cartridges?

• Packing materials

• How do I pack cartridges?

A quick and easy guide

to caring for your media

and troubleshooting

problems.

Table of Contents

DLTtape Media Care Guide www.quantum.com

Write Protect SwitchCartridge Features

Get To Know

Your Cartridge

Tape Leader

Buckles with drive leader to

pull media from cartridge.

DLTtape cartridges (mylar loop)

Super DLTtape cartridges

(plastic buckle with metal pin)

Prevents overwrite or erasure of data.

You can change the position of the write

protect switch at any time.

Reel Lock

Prevents media reel in the

cartridge from spinning

when the cartridge is not

loaded in a drive.This ensures

that proper media tension

is maintained.

Cartridge Hub

Mechanical interconnect

between the cartridge and

the drive reel motor.

Serial Number

Needed for identification purposes

if calling for service.

DLTtape and

SUPER DLTtape

Write protected–

slide down toward label.

Orange indicator should

be displayed.

DLTtape VS1 and

DLT VS160 Cleaning

Write protected -

Indicator on top

points to closed lock

Cartridge Door

Provides access to the tape leader.

Super DLTtape

DLTtape

Get to Know Your Cartridge

DLTtape Media Care Guide www.quantum.com

Proper Storage Conditions

Normal Storage

(Non Archival)

• Between 61° F and 90° F (16° C and 32° C)

• Between 20% and 80% relative humidity

• Maximum wet bulb temperature 78° F (26° C)

• Between 64° F and 79° F (18° C and 26° C)

• Between 40% and 60% relative humidity

Data Archival

Storage (for one

or more years)

Media Use Proper Conditions

Protecting Your Cartridge Labeling Your Cartridge

Media Care

Overview

• Use the sliding labels provided.

Do not use adhesive labels or Post-it®notes.

• Do not write directly on the cartridge.

• Write in pen, not pencil. Using a pencil can

introduce contaminants to the tape path.

• Protect cartridges from shock, vibration,

moisture and magnetic fields.

• Keep media in protective cases and store

vertically when not in use

• Make sure that no loose labels in the storage

container stick to the bottom of the cartridge

when inserting into tape drive.

• Never touch the tape or tape leader.

Dust and oils from your skin can contaminate

the tape and affect performance.

• Avoid direct sunlight–can deform

cartridge and /or ruin media.

www.quantum.com

Media Care Overview

DLTtape Media Care Guide

Group 1: Case and Reel Inspection

When Do I Perform a Visual Inspection?

How Do I Perform a Visual Inspection?

• Best practices: Each time a tape is loaded or changed.

• When a tape cartridge is dropped or subject to a hard physical shock.

• When a shipment of tapes show any signs of shipping damage.

• If the DLT, DLT VS or SDLT drive becomes inoperable after loading a tape.

• If a drive error occurs, inspect the current and previous cartridge used in that drive.

• Go through all inspection steps in Group 1, 2 and 3 (see below).

• If issues are found in Group 1 only and no issues found in

Groups 2 or 3 then use cartridge with caution.

• Monitor software log for media degradation.

• Consider copying the data onto a new cartridge and

retiring the old cartridge.

• If any issues are found in Group 2 or 3 then retire the media

and use a different cartridge.

Case

Inspect the case for cracks,

chips, or signs of damage.

Cartridge Hub

Confirm that the spring-loaded

hub on the bottom of the cartridge

is centered.Press the hub. It should

spring back if operating properly.

Operation of the reel locks may

release the hub and re-center.

Visual

Inspection

www.quantum.com

DLTtape Media Care Guide

Visual Inspection

Group 2: External Cartridge Inspection

Cartridge

Inspect the exterior of the

cartridge for chips, cracks,

dents or missing screws.

Gently shake the cartridge,

listening for rattles or

loose pieces.

Write Protection Switch

Move the switch.It should be

able to snap into write-protected

mode and write-enabled mode.

Reel Locks

Check that both reel locks are

visible. Verify operation using

a small flat blade screwdriver.

The reel locks should spring back

when released.

Visual Inspection

Visual

Inspection

Cont’d

4.1

Cartridge Door

Ensure the door is

movable and that

the spring is present.

www.quantum.com

DLTtape Media Care Guide

Visual Inspection Cont’d

4.1

Group 3: Inspecting the Leader: DLTtape Cartridges

Visual Inspection

Normal

Normal DLTtape leader.

Tape Leader Missing

Swallowed cartridge leader or broken tape.

Excessive Debris

Stuck to tape leader and to tape.

Media Wrapped too Loosely

Excessive slack apparant.

(Note: OK to use cartridge if small amount

of slack at the tape leader is present,

but inspect cartridge again after use.)

Broken Tape Leader

Not always this obvious.

Visual

Inspection:

Spotting

Damaged

DLTtape Media

DLT

4.2

www.quantum.com

DLTtape Media Care Guide

Visual Inspection | DLTtape Cartridges | DLTtape Media

4.2

Group 3: Inspecting the Leader: Super DLTtape Cartridges

Visual Inspection

Excessive Debris

Stuck to tape.

Visual

Inspection:

Spotting

Damaged

Super DLTtape

Media

4.3

SDLT

Normal

Normal SDLT tape leader.

Toed-In Buckle

Buckle ends clearly extend

past edge of reel.

Buckle Missing

No buckle present.

Buckle Bent

One buckle end is bent and

buckle is not symmetrical.

Gap from Tape Leader Slack

Tape Leader is clearly visible.

Buckle Separated from

Tape Leader

Buckle has broken through tape

leader on one side.

www.quantum.com

DLTtape Media Care Guide

Visual Inspection | Super DLTtape | Super DLTtape Media

4.3

Shipping

and Storing

Media

2‘

10”

6”

14”

6“

1‘

How Do I Pack Cartridges for Shipping?

Do Not Use the following shipping materials:

Air pillows, Peanut packaging, Oversized boxes,

Standard Flat boxes, Fed Ex boxes for example

Fill in all air space with bubble wrap.

Orient tapes vertically in the shipping box

Wrap Each Cartridge Properly

2’ x 2’ sheets of bubble wrap, 1” thick

Use the Correct Shipping Box

Small box: 10” x 6” x 6” (Holds one cartridge ONLY)

Large box: 14” x 10” x 6” / Multiple Cartridge Box

with bubble wrap

Packing Single or Multiple Cartridges

1 sheet 1 small box

2 sheets 2 small boxes

3 sheets 1 large box

4 sheets 1 large box, 1 small box

5 sheets 1 large box, 2 small boxes

Ship in multiple boxes in combination following

the above guidelines.

# of Cartridges Bubble Wrap # of Boxes

www.quantum.com

DLTtape Media Care Guide

Shipping Cartridges

Media Do’s

and Don’ts

6Media Care Do’s Media Care Don’ts

Storage

• Store cartridges in their protective cases.

• Align cartridges so grooves in cases interlock.

Handling

• Handle cartridges with great care.

• Don’t touch the tape or tape leader with bare

fingers.

Usage

• Inspect cartridges prior to each use.

• Unload cartridges prior to powering down the drive

• Before using a new or stored cartridge, allow

the cartridge 24 hours to adjust to the present

operating temperature and humidity.

Storage + Shipping

• Don’t store near magnetic fields.

• Don’t ship cartridges in drive.

• Don’t stack cartridges horizontally.

Handling

• Don’t touch the media or leader with bare fingers.

• Don’t use pens or pencils during cartridge inspection.

• Don’t use adhesive labels.

• Don’t disassemble cartridges.

Usage

• Don’t drop cartridge or use a dropped cartridge.

For more information,

www.quantum.com

DLTtape Media Care Guide

visit quantum.com

United States of America

Quantum Corporation

141 Innovation Drive

Irvine, CA 92617

U.S.A.

phone 949.856.7800

fax 949.856.7799

European Headquarters

Quantum Corporaton

3 Bracknell Beeches

Old Bracknell Lane West

Bracknell

Berkshire RG12 7BW

United Kingdom

phone +44 1344 353500

fax +44 1344 353510

Asia Pacific

Quantum Corporaton

9 Temasek Boulevard, #08-03

Suntec Tower Two

Singapore 038989

phone +61 7 3839 0950

fax +61 7 3839 0955

Quantum Corporation. Other trademarks may be mentioned herein which belong to other companies.

81-81564-01 A01 February 2006

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Almacenamiento de Quantum

Quantum

Quantum DAT 160 Manual de servicio

Quantum

Quantum SNC 4000 Manual de usuario

Quantum

Quantum Quantum Bigfoot CY Manual de usuario

Quantum

Quantum P4000 Series Manual de usuario

Quantum

Quantum Scalar i40 Manual de usuario

Quantum

Quantum SuperLoader 3A Series Manual de usuario

Quantum

Quantum ATL PowerStor L200 Series Manual de usuario

Quantum

Quantum QXS 12G Series Manual técnico

Quantum

Quantum ValueLoader DLT VS160 Manual de usuario

Quantum

Quantum Superloader 3 Manual de usuario

Quantum

Quantum DLT-S4 Manual de usuario

Quantum

Quantum StorNext M660 Instrucciones de instalación

Quantum

Quantum Scalar 24 Instrucciones de funcionamiento

Quantum

Quantum DLT-V4 Manual de usuario

Quantum

Quantum DX100 Manual de usuario

Quantum

Quantum DLTtape DLT 4000 Manual de usuario

Quantum

Quantum DLTtape SDLT 600 Hoja de información del producto

Quantum

Quantum DLTtape DLT 4000 Manual de usuario

Quantum

Quantum FastStor 1 Manual de usuario

Quantum

Quantum Scalar i500 Manual de usuario

Quantum

Quantum DXi6900 Manual de usuario

Quantum

Quantum SNC 4000 Manual de instrucciones

Quantum

Quantum QXS G2 Series Manual de funcionamiento

Quantum

Quantum PowerStor L200 Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
