VESA Monitor Mount (P-MNMT-01)
Assembly Manua l
Stand Mounng Clamp Monitor Mount
2
Mount the monitor mount on the stand and
secure it completely.
Note: Monitor Mount provides an addional
3/8”-16 thread on the top for accessory
mounng, e.g. Compable LCD arms, mounts,
etc.
By loosening the side knob, you can move the
monitor mount up to 180° up-down, as shown
in the images.
Aer loosening the inbuilt bolt, you can rotate
the monitor mount up to 360°, as shown in
the images.
Monitor Mount Setup
Aer the rotaon, ghten the bolt and
reaach the knob.
Loosen the side knob of the stand mounng
clamp as per your requirement.
Loosen and remove the knob from the other
side of the stand mounng clamp and loosen
the inbuilt bolt using an Allen key.
3
Bolt-together the LCD and the monitor mount
and then aach it to the stand mounng
clamp.
Remove the monitor mount from the stand
mounng clamp and aach it to the LCD.
Once the monitor mount is aached to the
stand mounng clamp, secure it properly
using an Allen key as shown in the image.
Your setup is now ready.
YOUR PROAIM VESA MONITOR MOUNT
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
4
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
