PROAIM SnapRig Universal Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Assembly Manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

SnapRig Universal DSLR Camera Cage Rig with

Top & Side Handles (UC-01)

Proaim SnapRig DSLR Camera Cage

1 x Side

Rod Top Handle

1 x Wooden Handle

3 x Allen Keys Sizes:

(3mm,3/16mm & 4mm)

Height Adjustable Cage Setup

• Match the wooden side handle to the thread

of the slide rod of the camera cage, and then

aach it by aligning the thread through both

the knobs of the side handle and properly

ghten the knobs equally.

• Wooden side handle has been properly

aached to the slide rod of the camera cage.

Interchange Side Rods

NOTE: It comes with two interchangeable side

support rods of dierent heights that mount to a

15mm rod clamp and let you adjust the cage's

height to best t your camera. These side rod

connects to cheese-style top plate and baseplate

and let them slide up and down to adjust the

interior height.

• Mount the top handle by aligning it with the

thread of the plate.

NOTE: You Can mount the top handle on the top

plate, according via the Mounng Threads.

• Aer placing the top handle on the top plate,

insert the buon head by matching the bolt to

the side threads of the handle and then

properly ghten it using the 4mm Allen key.

• Remove the wooden side handle by loosening

its knob.

• Remove the slide rod (145mm) by loosening

the boom bolt of the rod, using the 4mm

Allen key.

• Insert the top quick release with the rod

mount on the side rod and then properly

secure it using the Allen key.

• Mount the side rod (125mm) on the quick

release with the rod mount and then properly

ghten it using the Allen key.

• Match the wooden side handle to the thread

of the slide rod of the camera cage, and then

aach it by aligning the thread through both

the knobs of the side handle and properly

ghten the knobs equally.

• Remove the side bolt of the Camera Cage with

slide rod, using the Allen key, as shown in the

image.

• Insert the rod by loosening the knob of the

top handle and matching the hole of the

handle.

• Aer inserng the rod, secure the top handle

by re-ghtening its knob.

• Loosen the bolt of the top cheese plate using

the 3mm Allen key, so that the shoe mount

can loosen up.

• Remove the top handle by loosening the

buon head of the handle using the Allen key.

NOTE: Camera cage oers beer mobility,

comfy handheld use, tripod and accessories

mounng Flexibility.

DSLM Camera Cage Setup

• Here is the proper assembled image of the

Camera cage.

• Aer sliding the shoe mount of the plate,

aach the bolt to the camera (Not Included)

and properly x it by ghtening it using the

3mm Allen key.

NOTE: It has a sophiscated & High-Grade CNC

aluminum body to ensure long-lasng durability

& stability. This top-notch cage is easy to use &

comfortable to carry.

• Place the top handle on the top plate, and

then insert the buon head. Properly secure

it using the Allen key.

• Loosen the knob of the top handle and then

insert the rod by matching it with the hole.

• Aer inserng the rod, secure the top handle

by re-ghtening its knob.

• Match the threads of the camera

(Not Included) to the boom threads of the

camera plate and then insert the screw.

Properly ghten it using the screw driver.

YOUR PROAIM SNAPRIG UNIVERSAL DSLR CAMERA CAGE RIG WITH TOP & SIDE HANDLES

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.

NOTE: It mounts directly to tripods with a 1/4″-20 or 3/8" -16 threaded mount and has mulple universal

connecons for mounng addional accessories. Built-in cold shoe mount on the top and mulple 1/4”-20

& 3/8”-16 thread holes let you aach mics, lights, arculang arms, and other devices and accessories.
