PROAIM CINEMA Series Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

Atlas 38” Producon Camera Cart (CT-ATLS-38)

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Assembly Manual

4 x Pneumac

Tires

4 x Supporng

rods Lower shelf

2 x crossbar

Upper shelf

2 x Handles

ATTACHING PNEUMATIC TIRES

Aach pneumac res with the lower base

Shelf of cart and secure the res with the help

of locking levers.

Atlas Cart Setup

NOTE: Lock Levers help to set the Cart in the

desired posion or to keep the Cart in a stac

place (non-movable). You can lock/unlock

Levers as per your requirement.

There is 360° Swivel Movement in Rear 2

Wheels, which oers greater turning exibility.

 Open up the outer rods, keep in a straight

posion and secure with the help of

provided locking adapters.

 You have received the atlas cart with

Pneumac Tires, Cross bars, handles and

already aached atlas rods.

 Press the side pin of the rod and insert the

crossbar and secure the crossbar with

provided knob.

ATTACHING HANDLE

Again press the pin to insert the Handle onto

rods, set the desired height posion as shown.

 Place the top shelf over the rods, push the

pins to assemble the shelf and secure

properly.

 There is a provision to unfold the lip by

releasing the inner locking pin.

YOUR PROAIM ATLAS 38” VIDEO PRODUCTION CAMERA CART

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
