PROAIM Bazooka BZ-FLXN-01 Manual de usuario
1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Assembly Manua l
Euro Adapter
Female Euro Adapter
Male
Flexino Bazooka Set for Video Film Camera Dolly
(BZ-FLXN-01)
Double Male Thread
Adapter
4 x Extensions
1 x L-Type Allen key (Size: 5/16”)
Flexino Bazooka Setup
2
• Insert the 1st extension (32cm) into the Euro
Female Adapter, then rotate and ghten it
properly.
NOTE: A Euro Female Adapter at the base
facilitates easy aachment for addional
extensions and a ratchet lock lever for locking
the extensions in place .
• The Double Male thread Adapter has been
properly mounted on the 1st Extension.
• Insert the 2nd Extension into the Double Male
Thread Adapter, then rotate and ghten it
properly.
Assembling of Extension 1 (32cm)
Assembling of Double Male Thread Adapter (2cm)
Assembling of Extension 2
• Insert the Double Male Thread Adapter to the
1st Extension, then rotate and ghten it
properly.
3
• Mount the 4th Extension on the 3rd
Extension, then rotate and ghten it
properly.
• The 2nd Extension has been properly
mounted on the Double Male Thread
Adapter.
NOTE: The Bazooka, with its detachable
extensions, makes it fast and ultra-easy for
professional.
• The 3rd Extension has been properly
mounted on the 2nd Extension.
• Mount the 3rd Extension (4cm) on the 2nd
Extension, then rotate and ghten it
properly.
Assembling of Extension 3 (4cm)
Assembling of Extension 4 (10cm)
4
Mounng on Dolly
• Loosen the ratchet knob of the Flexino
Bazooka and mount it on the Euro Adapter
(Not Included) on the Doorway Dolly
(Not Included).
• Aer mounng the Flexino Bazooka, secure it
by properly ghtening the ratchet knob.
• Loosen the ratchet knob of the Euro-Mount
Oset Bracket (Not Included) and mount it on
the Flexino Bazooka.
NOTE: The Euro Mount Oset Adapter
accommodates all industry standard Euro
compable mounng opons.
NOTE: Top mounng is facilitated by a Euro
Male Adapter that lets you rig your camera
gear with utmost security.
• Mount the Euro Male Adapter (4.8cm) on
the 4th Extension, then rotate and ghten it
properly.
Assembling of Euro Adapter Male (4.8cm)
5
• Push the buon of the Fluid Head and
remove the Camera Plate.
• Now aach the Camera Plate to the Camera
(Not Included) by matching the threads and
properly secure with the help of a screwdriver
(Not Included).
Camera Mounng Setup
• Aer mounng the Fluid Head, aach the
Castle Ring to the boom of the Fluid Head
and properly secure it.
• Loosen the Castle Ring of the Fluid Head
(Not Included) and mount it on the Oset
Bracket.
Mounng of Fluid Head
• Aer mounng the Oset Bracket, secure it
properly by ghtening the ratchet knob.
NOTE: The adapter is equipped with a Ratchet
Knob on one side which provides secure
lock-o to the camera .
6
• Now the Camera has been properly
aached to the Camera Plate.
• Slide the Camera onto the Fluid Head and
properly lock with the help of the locking
pin.
NOTE: It provides a multude of camera
mounng conguraons using addional,
oponal mounng accessories.
NOTE: The durable Bazooka Set comes equipped with dierent extensions to give you just the amount of
elevaon you are looking for.
7
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our ut-
most support and care unl you use our product.
YOUR PROAIM FLEXINO BAZOOKA SET FOR VIDEO FILM
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
