PROAIM P-GDTR-01 Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

Gladiator Ergonomic Body Support Camera Rig (P-GDTR-01)

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Assembly Manua l

Removable

Non-Skid Pad

Washable Pads

Wider Back Support

Accessory Loops

Quick height

Adjustment

Knobs

Gladiator Rig Setup

 Reghten the screws using an Allen key to

secure the shoulder pad posion.

 To adjust the shoulder pad posion, loosen

the top front & back screws using an Allen

key and adjust the shoulder pad as required.

Note: You can move the screws up and down

by loosening them. Moving the screw up helps

you extend the shoulder post upwards. Lower-

ing the screw lowers the shoulder pad.

 Detach the chest buckle and wear the

gladiator jacket on your right shoulder. Then,

reaach the waist buckle.

Note: The gladiator jacket comes assembled

on the right side. If you want to wear it on the

le side according to your requirement, its

steps are given separately.

 Buckle up the chest strap as shown in the

image.

Note: You can adjust the chest strap as per

your comfort.

 Adjust the height as required and reghten

the knobs properly. Then detach the waist

buckle.

Note: The jacket quickly adjusts to t dierent

body types and changes on the y to keep you

comfortable take-aer-take.

 Loosen both the front and back height ad-

justment knobs on the jacket.

Gladiator Rig Le shoulder Setup

 Loosen and take o both the height

adjustment knobs.

Note: If you don't interchange the shoulder

support plate of the gladiator rig and wear it on

the le shoulder, the gladiator jacket will not

adjust on your body, and the pad will go to the

back wrong side.

The steps to mount the pad correctly are given

below.

 Loosen all bolts on the front and back sides

of the jacket using an Allen key.

 You can adjust the boom plate of the

jacket anywhere on the rear-strut.

 Aach the middle plate and ghten the

knobs back securely.

 Remove the jacket's middle plate and shi it

along with the pad from one side to the

other.

Interchanging Shoulder Support from Right to Le

Rear strut

re-mountable

for dierent

body types

Shiing the Middle Plate & Pad

Note: Proaim Gladiator Rig prevents spinal

compression allowing you to comfortably

operate shoulder-mounted conguraons

without aecng the camera's movement or

balance. 100% of the weight is transferred from

your shoulders and back to your hips, bypass-

ing your spine.

It supports heavy-duty loads, such as

fully-accessorized ARRI, Red or Black Magic

Cameras.

 Buckle up and adjust the chest and the waist

straps as per your comfort.

 Shi the boom plate of the jacket from one

side to the other and ghten all the bolts us-

ing an Allen key, as shown in the image.

Note: Follow the same process on the other

side of the jacket.

YOUR PROAIM GLADIATOR BODY SUPPORT CAMERA RIG

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
