PROAIM Swift Dolly Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Swi Dolly

A s s e m b l y M a n u a l

with 12 Straight Track (P-SFT-DT-12 )

15” Camera

Mounng Post

Swi Dolly with

Wheels Aached

14” Central

Support System

CONTENTS OF SWIFT DOLLY:

 Swi Dolly

 14” Central Support System

 15” Camera Mounng Post

12’ TRACK

 2x 4’ Central Secon with Nylon

Aachment Bushings

 4x 4’ Extension Rods

 2x Track Stoppers

 10x Track Riser Supports (Blue)

 10x Track Riser Supports (Black)

 Remove the Dolly from the storage bag.

Loosen the lock knob from the 27” central

secon.

 Now, arrange the 32” rods of Dolly to give it

a triangular shape. Then aach the 27” rod

to the wheel set and ghten the knob to

secure.

 Aach the 14” rod to the base and ghten the

screws to secure it. Now, aach 15” camera

mounng post as shown in the picture and

your Dolly is ready to use.

 Using the secons with the aached nylon

bushings remove the outboard set of screws,

slide an extension secon on to each end to

complete a 12’ run and install and ghten

the screws to secure.

Swi Dolly Setup

 Now, track is ready and place the dolly on

the tracks as shown in the picture.

 Aach the Track Spacers and Track Supports

to the track for it’s rigidity and to prevent

your Dolly from running o the rails.

Track Setup

YOUR PROAIM SWIFT DOLLY SYSTEM WITH 12FT STRAIGHT TRACK

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
