PROAIM LB230 Manual de usuario

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

SnapRig L-Bracket (LB230)

Assembly Manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

What’s In The Box

Magnezed Screwdriver

Camera bolt size: 1/4

SnapRig L-Bracket

SnapRig L-Bracket Setup

• There is a magnezed screwdriver at the

boom of the SnapRig.

• Use the magnezed screwdriver to loosen

the screw.

• Mount the SnapRig and ghten the knob of

the ball head.

• Loosen the knob of the ball head and remove

the camera plate.

• Now, extend the side plate.

YOUR PROAIM SNAPRIG PROFESSIONAL KIT

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.

• Now, mount the SnapRig vercally on the ball

head.
