PROAIM VI-SPCM-01 Manual de usuario

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Assembly Manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Spring-Cam Mitchell Vibraon Isolator (VI-SPCM-01)

Proaim Spring-cam Mitchell

vibraon Isolator

Mitchell Key

T– Type Allen Key

(4mm, 5mm, 5/16mm, 6mm)

• Remove the Male Mitchell ring from the

boom of the Spring-CAM Mitchell Vibraon

Isolator with the help of a Mitchell Key.

NOTE: The isolator oers great mounng

exibility with male Mitchell Mount.

Tripod (Not-Included) Setup

• Then mount the Spring-cam Mitchell

vibraon Isolator on the top of the Tripod

(Not Included) & ghten it with the help of

the Mitchell castle lock present at the boom

of the tripod.

• Manually ghten the Mitchell castle lock with

the help of the Mitchell key.

• Then insert the Mitchell Castle Nut with Ronin

Mount Clamp on Spring-cam Mitchell

vibraon Isolator and then ghten it with the

male Mitchell ring (Not Included) at the

boom of the Spring-cam Mitchell vibraon

Isolator.

• Then ghten it with the provided knob of the

DJI-QR Quick Release plate (Not Included).

• Remove the male Mitchell ring (Not Included)

from Mitchell Castle Nut with Ronin Mount

Clamp (Not Included).

• To secure the Camera (Not Included) with the

Gimbal (Not Included), lock it properly with

the lock lever of the gimbal, as shown in the

image.

• Push the buon of the gimbal (Not Included)

and place it on the DJI-QR Quick Release plate

(Not Included) by sliding it on the plate.

• Then ghten it with the knob of the DJI-QR

Quick Release plate (Not Included).

• Then properly ghten the male Mitchell ring

with the help of Mitchell Key.

• Remove the bolts of the Spring-cam Mitchell

vibraon Isolator with the help of the Allen

key, as shown in the image.

NOTE: It has 8 high-strength springs that absorb

ineral movements and supports a 5-50 kg /

11-110lb heavy payload. Also, you can use the

springs in dierent conguraons to precisely

achieve the li needed.

• Mount the Spring-cam Mitchell vibraon

Isolator on the mounng part of the Hi-Hat

and aach it with the male Mitchell ring.

Hi-Hat (Not-Included) Setup

Slider (Not-Included) Setup

Push Buon

• Then remove the spring of the Spring-cam

Mitchell vibraon Isolator.

NOTE: You can change the quanty of the

spring of the Spring-cam Mitchell vibraon

Isolator according to your requirement.

• Manually aach the male Mitchell ring at the

boom of the slider aer placing the

Spring-cam Mitchell vibraon Isolator on the

mounng part of the slider.

• Then insert the Mitchell Castle Nut

(Not Included) with Ronin Mount Clamp

from the top of the Spring-cam Mitchell

vibraon Isolator and ghten it with the

male Mitchell ring (Not Included) at the

boom of the Spring-cam Mitchell vibraon

Isolator.

YOUR PROAIM SPRING-CAM MITCHELL VIBRATION ISOLATOR

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.
