Planet IPOE-E174 Manual de usuario
1-Port Ultra PoE to 4-Port 802.3af/at Gigabit
PoE Extender
IPOE-E174
User’s Manual
Table of Contents
1. Introduction.............................................................................. 3
1.1 Packet Contents.................................................................. 3
1.2 Application Diagram ............................................................ 4
1.3 Key Features ...................................................................... 5
1.4 TechnicalSpecications ....................................................... 7
1.5 Power over Ethernet Budget ...............................................10
2. InSTALLATION..........................................................................11
2.1 Physical Dimensions ...........................................................11
2.2 Front Panel .......................................................................12
2.3 Mounting Installation..........................................................14
2.3.1DIN-rail Mounting.......................................................14
2.3.2Wall-mount Plate Mounting .........................................15
2.4 Connecting IPOE-E174 to Power Source Equipment (PSE) .....16
2.5 Connecting IPOE-E174 to Powered Device (PD) ....................17
3. Customer Support ....................................................................19
3
1. Introduction
1.1 Packet Contents
Thank you for purchasing PLANET IPOE-E174- 1-Port Ultra PoE
to 4-Port 802.3af/at Gigabit PoE Extender. Open the box of
the IPOE-E174 and carefully unpack it. The box should contain the
following items:
Industrial Power over Ethernet Extender x 1
User’s Manual x 1
RJ45 Dust Cap x 5
Wall Mounting Kit x 1
If any of these are missing or damaged, please contact your dealer
immediately; if possible, retain the carton including the original packing
material, and use them again to repack the product in case there is a
need to return it to us for repair.
4
1.2 Application Diagram
The IPOE-E174 is designed as the repeater to forward both Gigabit
Ethernet data and IEEE 802.3at PoE power, thus extending the range
of PoE installation. With just plug and play and without additional
power supply and setup, one single IPOE-E174 can increase the PoE
range to 200m and drive up four remote PoE IP cameras or wireless
access point.
Ultra PoE Injector
Power
Data
DC
Switch
100meters
100meters
100meters
100meters
Power Line (DC)
DC
1000BASE-T UTP
PoE
1000BASE-T UTP with PoE
PoE
PoE
PoE
PoE
PoE
1000BASE-T UTP with Ultra PoE
PoE
5
1.3 Key Features
Physical Port
5-port 10/100/1000BASE-T Gigabit RJ45 interface
1-port data + power input
4-port data + power output
Power over Ethernet
1-port data + power input
Complies with ultra Power over Ethernet end-span and mid-
span PD
Complies with IEEE 802.3at High Power over Ethernet end-span
/ mid-span PD
Supports PoE input power up to 60 watts
4-port data + power output
Complies with IEEE 802.3af / IEEE 802.3at Power over Ethernet
/ end-span PSE
Up to 4 IEEE 802.3af / 802.3at devices powered
Supports PoE power up to 30.8 watts for each PoE port
Auto detects powered device (PD)
Extends the range of PoE to an additional 100 meters (328ft.)
Forwards both Ethernet data and PoE power to remote device
Layer 2 Features
Hardware based 10/100Mbps, half / full duplex and 1000Mbps full
duplexmode,owcontrol,auto-negotiationand autoMDI/MDI-X
Features Store-and-Forward mode with wire-speed ltering and
forwarding rates
IEEE 802.3x ow control for full duplex operation and back pres-
sure for half duplex operation
Integrates address look-up engine, supporting 8K absolute MAC
addresses
9K jumbo frame support in 1000Mbps duplex mode
6
Automatic address learning and address aging
Supports CSMA/CD protocol
Industrial Case / Installation
IP30 aluminum case protection
DIN rail and wall-mount design
Supports EFT protection for 6000V DC power, and 6000V DC
Ethernet ESD protection
-40 to 75 degrees C operating temperature
No external power cable required for installation
Plug and Play installation
Standard Compliance
IEEE 802.3 10BASE-T
IEEE802.3u100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3x Flow Control
IEEE 802.3at High Power over Ethernet
IEEE 802.3af Power over Ethernet
FCC Part 15 Class A, CE
Note
PSE (Power Sourcing Equipment) is a device (switch,
or hub for instance) that provides power in a PoE setup.
Maximum allowed continuous output power per such
device in IEEE 802.3af is 15.4W, and in IEEE 802.3at is
30W.
PD (Powered Device) is a PoE-enabled terminal by
PSE and thus consumes energy, such as PoE IP Phones,
PoE IP cameras, PoE wireless access points, etc.
7
1.4 TechnicalSpecications
Model IPOE-E174
HardwareSpecications
Network Connector
PoE In Port
1 x 10/100/1000BASE-T Ethernet with ultra
PoE “Data + DC”in,autoMDI/MDI-X,
auto-negotiation RJ45 connector
PoE Out Port
4 x 10/100/1000BASE-T Ethernet with IEEE
802.3af/at PoE “Data + DC” out, auto
MDI/MDI-X,auto-negotiationRJ45connector
Switch Architecture Store-and-Forward switch architecture
MAC Address Table 8K MAC address table with auto learning
function
Data Buffer 1Mbit
Switch Fabric 10Gbps
Switch Throughput 7.44Mpps @ 64Bytes
Flow Control IEEE 802.3x pause frame for full duplex
Back pressure for half duplex
Jumbo Frame 9Kbytes
ESD Protection 6KV DC
EFT Protection 6KV DC
Enclosure IP30 aluminum metal case
Installation DIN rail kit and wall-mount ear
8
LED Display
System: PWR (Green)
Power Input: Midspan in (Green)
Power Input: Endspan in (Green)
PoE Power Usage (%): 25 (Green)
PoE Power Usage (%): 50 (Green)
PoE Power Usage (%): 75 (Green)
PoE Input Port: LNK/ACT (Green)
PoE Input Port: PoE in (Orange)
Per PoE Output Port: LNK/ACT (Green)
Per PoE Output Port: PoE-in-Use (Orange)
Cable
Twisted-pair cable:
10BASE-T: 2-pair UTP Cat. 3,4,5, up to 100
meters
100BASE-TX:2-pairUTPCat.5,5eupto
100 meters
1000BASE-T: 4-pair UTP Cat. 5e,6 up to
100 meters
Dimensions
(W x D x H) 135 x 87.8 x 56 mm
Weignt 715g
Power Consumption 60 watts / 204.6BTU (Full loading with PoE
function)
Power over Ethernet
PoE Standard
PoE in Port
IEEE 802.3at High Power over Ethernet
end-span / mid-span PD class 4 PD
Per PoE out Port
IEEE 802.3at High Power over Ethernet
end-span PSE
IEEE 802.3af Power over Ethernet end-span
PSE
9
PoE Power
PoE in Port
50~57V DC, max. 60 watts
Per PoE out Port
44~55V DC, max. 30.8 watts
Power Pin Assignment
PoE in Port
1/2(+), 3/6(-); 4/5(+), 7/8(-)
Per PoE out Port
1/2(+), 3/6(-)
PoE Power Budget
50 watts (max.) @ Ultra PoE input
20 watts (max.) @ IEEE 802.3at PoE+ input
No support @ IEEE 802.3af PoE input
Standards Conformance
Regulation Compliance FCC Part 15 Class A, CE
Stability Testing
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.3at High Power over Ethernet
Environment
Operating Temperature: -40 ~ 75 degrees C
Relative Humidity:5 ~ 95% (non-condensing)
Storage Temperature: -40 ~ 85 degrees C
Relative Humidity:5 ~ 95% (non-condensing)
10
1.5 Power over Ethernet Budget
The following table lists how many PoE devices can be powered by
IPOE-E174:
Power Source PoE Output
Budget*
Max. Number of PDs
supported
PLANET Ultra PoE PSE 50 watts max.
Class 4 PD@25-watt 2 units
Class 3 PD@15-watt 3 units
Class 2 PD@7-watt 4 units
IEEE 802.3at PoE+
PSE 20 watts max.
Class 4 PD@25-watt 0
Class 3 PD@15-watt 1 unit
Class 2 PD@7-watt 2 units
IEEE 802.3af PoE PSE 10 watts max. Class 2 PD@7-watt 1 unit
Remarks
1. The PoE Output Budget means the 4-port PD
aggregated power output. The aggregated power
consumption will be below 50 watts if with ultra PoE
PSE.
2. Please check the power input LED (60W PoE) for
optimal power output. Both mid-span and end-span
LEDs should be turned on for maximum capability.
