PoE Industrial Ethernet Extender
IVC-2004PT
User’s Manual
Trademarks
Copyright © PLANET Technology Corp. 2014
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. The
information in this manual is subject to change without notice. All other
trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work
properly in all environments and applications, and makes no warranty
and representation, either implied or expressed, with respect to
the quality, performance, merchantability, or tness for a particular
purpose.
PLANET has made every effort to ensure that this User’s Manual is
accurate; PLANET disclaims liability for any inaccuracies or omissions
that may have occurred.
Information in this User’s Manual is subject to change without notice
and does not represent a commitment on the part of PLANET. PLANET
assumes no responsibility for any inaccuracies that may be contained in
this User’s Manual. PLANET makes no commitment to update or keep
current the information in this User’s Manual, and reserves the right
to make improvements to this User’s Manual and/or to the products
described in this User’s Manual, at any time without notice.
FCC Warning
This equipment has been tested and found to comply with the
regulations for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in
accordance with this user’s guide, may cause harmful interference to
radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference, in which case the user will be
required to correct the interference at his own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to
take adequate measures.
WEEE Warning
To avoid the potential effects on the environment and human
health as a result of the presence of hazardous substances in
electrical and electronic equipment, end users of electrical
and electronic equipment should understand the meaning of
the crossed-out wheeled bin symbol. Do not dispose of WEEE as
unsorted municipal waste and have to collect such WEEE separately.
Revision
PLANET PoE Industrial Ethernet Extender User's Manual
For Model: IVC-2004PT
Rev 2.0 (March, 2014)
Part No.: 2350-AH0350-003
Table Of Contents
1. Introduction.............................................................................. 5
1.1 Checklist ............................................................................ 5
1.2 Ethernet over VDSL2 Bridge Description ............................... 5
1.3 Key Features ...................................................................... 7
1.4 Specications ..................................................................... 8
2. Hardware Description................................................................11
2.1 Front Panel .......................................................................11
2.1.1 LED Indicators for IVC-2004PT..................................12
2.1.2 DIP Switch Indication ...............................................13
2.2 The Upper Panel ................................................................14
3. Installation .............................................................................15
3.1 Installing PoE Industrial Ethernet Extender – IVC-2004PT......15
3.2 IVC-2004PT BNC / RJ-11 Proper Connection ........................16
3.3 IVC-2004PT Application Connection .....................................17
3.4 Wiring the Power Inputs.....................................................20
3.5 Wiring the Fault Alarm Contact ...........................................21
3.6 Mounting Installation..........................................................22
3.6.1 DIN-Rail Mounting....................................................22
3.6.2 Wall Mount Plate Mounting .......................................24
4. Troubleshooting ........................................................................25
5. FAQ ........................................................................................26
5
1. Introduction
1.1 Checklist
Check the contents of your package for the following parts:
zPoE Industrial Ethernet Extender x 1
zUser’s Manual x 1
zDIN Rail Kit
zWall Mount Kit
If any of these items are missing or damaged, please contact your
dealer immediately; if possible, retain the carton including the original
packing material, and use them again to repack the product in case
there is a need to return it to us for repair.
1.2 Ethernet over VDSL2 Bridge Description
PLANET's state-of-the-art Ethernet-over-VDSL2 products are based on
two core networking technologies: Ethernet and VDSL2 (Very-high-
data-rate Digital Subscriber Line 2). This technology offers the
absolute fastest possible data transmission speeds over the existing
copper telephone lines or coaxial cables without the need for rewiring.
The IVC-2004PT PoE Industrial Ethernet Extender has a switching
architecture with 4 PoE of RJ-45 10/100Mbps ports and Asymmetric
or Symmetric Ethernet over VDSL port (Asymmetric means upstream
and downstream rate are not the same and Symmetric means
upstream and downstream rate are similar) – the VDSL port can be
RJ-11 or BNC Connector. The IVC-2004PT can set to Master or Slave
mode via a DIP switch. When IVC-2004PT (RJ-11) is connected with
another IVC-2004PT device, the performance will go up to 99/63Mbps
for asymmetric data rate within 200m and go up to 28/2Mbps at
1.4km. The IVC-2004PT (BNC) performance is up to 99/65Mbps for
asymmetric data rate within 200m and up to 31/4Mbps at 2.4km. This
capability is ideal for use as an Ethernet extender for your existing
Ethernet network.
6
With 4 PoE interfaces, the IVC-2004PT will be ideal for small
businesses and workgroups requiring to deploy the PoE for the wireless
access points, IP-based surveillance camera or IP phones in any places
easily, efciently and cost-effectively.
The IVC-2004PT PoE Industrial Ethernet Extender with the IP-30
aluminum metal shape is designed for easy deployment in Heavy
Industrial demanding environments.
PLANET PoE Industrial Ethernet Extender provides a lower cost
replacement and smooth migration for the existing Long Reach
Ethernet (LRE) networks.
The cable specications of the connection are listed as follows:
z10Base-T, Category 3, 4 or 5 UTP
z100Base-TX, Category 5, 5e or 6 UTP
zEthernet over VDSL2, Twisted-pair Telephone Wires
zEthernet over VDSL2, Coaxial Cable
Note
Slave device (CPE) must be connected to Master device
(CO) through the telephone wire or coaxial cable. It does
not allow connection like Master to Master or Slave to
Slave. To check whether the IVC-2004PT is connected to
Master or Slave, please refer to section 2.1.2 for more
details.
7
1.3 Key Features
The PoE Industrial Ethernet Extender provides the following key
features:
z4-port IEEE 802.3af Power over Ethernet Standard
zEach PoE port provides 15.4 watts
zCompatible with IVC-2002, VC-201A and VC-202A (17a Prole)
zCost-effective VDSL2 Master / Slave bridge solution via DIP Switch
zSelectable BNC and RJ-11 mode for the data transmission
z-40 to 75 degrees C operating temperature
zRedundant Power Design: 24V or 48V DC, redundant power with
polarity reverse protect function
zIP30 aluminum metal case protection
zDenes Asymmetric (Band Plan 998) and Symmetric band plans for
the transmission of Upstream and Downstream signals
zComplies with IEEE 802.3, IEEE 802.3u and IEEE 802.3x standards
zDMT (Discrete Multi-Tone) line coding
zHalf duplex back pressure and IEEE 802.3x full duplex fause frame
ow control
zSupports up to 1536 bytes packet size, 802.1Q VLAN tag transparent
zIntegrated address look-up engine, supporting 2K absolute MAC
addresses
zVDSL2 Stand-alone transceiver for simple bridge modem application
zSelectable Target Band Plan and Target SNR Margin
zSupport extensive LED indicators for network diagnostics
zDIN Rail and Wall-mount design
8
1.4 Specications
Product IVC-2004PT
Hardware Specications
Ports
10/100 Base-TX 4 x RJ-45, Auto-Negotiation and Auto-MDI/MDI-X
PoE 4 x PoE (Port1 ~ Port4)
VDSL 1 x RJ-11, female Phone Jack
1 x BNC, female connector
DIP Switch 4 position DIP switch
Functionality *1
Master / Slave mode select
Selectable BNC and RJ-11 mode
Selectable target Band Plan
Selectable target SNR mode
Encoding
VDSL-DMT
- ITU-T G.997.1
- ITU-T G.993.1 VDSL
- ITU-T G.993.2 VDSL2 (Prole 17a Support)
LED Indicators
P1 (Green)
P2 (Green)
Fault (Green)
Master (Green) and Slave (Green)
ACT (Green)
Sync. (Green)
PoE ( Orange)
Power
Over
Ethernet
PoE Standard IEEE 802.3af Power over Ethernet / PSE
PoE Type End-Span
PoE Power
Input 24V or 48V DC power input source
PoE Power
Output 48V DC Per Port, 350mA . Max. 15.4 watts
PoE Pin
Assignment 1/2(+), 3/6(-)
9
Cabling
Ethernet
• 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m
(328ft)
• 100Base-TX: 2-pair UTP Cat.5, 5e, 6 up to
100m (328ft)
VDSL (RJ-11) Twisted-pair telephone wires (AWG24 or better)
up to 1.4km
BNC 50 ohm: RG58A/U, RG58C/U, RG58/U and 75
ohm: RG6 (Distance 2.4km)
Performance *2
(Downstream /
Upstream)
Asymmetric Mode
VDSL (RJ-11) BNC
200m -> 99/63Mbps
400m -> 91/48Mbps
600m -> 71/32Mbps
800m -> 53/18Mbps
1000m -> 38/8Mbps
1200m -> 33/5Mbps
1400m -> 28/2Mbps
200m -> 99/65Mbps
400m -> 99/64Mbps
600m -> 97/59Mbps
800m -> 94/51Mbps
1000m -> 84/45Mbps
1200m -> 73/37Mbps
1400m -> 61/28Mbps
1600m -> 54/20Mbps
1800m -> 48/13Mbps
2000m -> 39/9Mbps
2200m -> 35/6Mbps
2400m -> 31/4Mbps
Symmetric Mode
VDSL (RJ-11)
BNC
200m -> 91/99Mbps
400m -> 74/79Mbps
600m -> 54/51Mbps
800m -> 38/34Mbps
1000m -> 27/21Mbps
1200m -> 24/15Mbps
1400m -> 21/10Mbps
200m -> 95/99Mbps
400m -> 92/97Mbps
600m -> 81/82Mbps
800m -> 71/70Mbps
1000m -> 60/57Mbps
1200m -> 50/44Mbps
1400m -> 42/33Mbps
1600m -> 37/27Mbps
1800m -> 29/22Mbps
2000m -> 23/21Mbps
2200m -> 19/17Mbps
2400m -> 19/13Mbps
10
Dimensions (H x W x D) 135mm x 87.8mm x 50mm
Weight 631g
Power Requirements
24V or 48V DC for PoE Devices
Redundant power with polarity reverse protection
function
Power Consumption /
Dissipation
66.4 watts / 226BTU max. (PoE)
5.64 watts / 19.24BTU (non-PoE)
Installation DIN Rail Kit and Wall-mount Ear
Standard Conformance
Stability Testing
IEC60068-2-32 (Free Fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
Operating Temperature -40 ~ 75ºC
Storage Temperature -40 ~ 85ºC
Operating Humidity 10% to 90%, relative humidity, non-condensing
Storage Humidity 10% to 90%, relative humidity, non-condensing
Regulation Compliance FCC Part 15 Class A, CE
Standards Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3af Power over Ethernet
IEEE 802.3x Full duplex pause frame ow control
ITU-T
1. G.997.1
2. G.993.1 VDSL
3. G.993.2 VDSL2 (Prole 17a)
*1. BNC and RJ-11 mode must switch to the same position for Master
and Slave. Otherwise, it may cause unstability.
*2. The actual data rate will vary on the quality of the copper wire and
environment factors.
Tabla de contenidos
Otros manuales de Extensor de Planet
Planet
Planet IPOE-E174 Manual de usuario
Planet
Planet IVC-4011-T-V2 Manual de usuario
Planet
Planet LRP-101C-KIT Manual de usuario
Planet
Planet IVC-2002 Manual de usuario
Planet
Planet WTB-1000 Manual de usuario
Planet
Planet IPOE-E302 Manual de usuario
Planet
Planet LRE-101 Manual de usuario
Planet
Planet WNAP-C3220 Manual de usuario
Planet
Planet LRP-104CET Manual de usuario
Planet
Planet WNAP-1110 Manual de usuario
Planet
Planet PL-510W Manual de usuario
Planet
Planet IPOE-E202 Manual de usuario
Planet
Planet WRE-1200 Manual de usuario
Planet
Planet IHD-410PT Manual de usuario
Planet
Planet LRP-101CE Manual de usuario
Planet
Planet VC-205PT Manual de usuario
Planet
Planet POE-E201 Manual de usuario
Planet
Planet POE-E304 Manual de usuario
Planet
Planet WAP-7500 Manual del operador
Planet
Planet WRE-1200 Manual de usuario
