Olympia electronics POWER LIGHT Series Manual de usuario

GENERAL

These luminaires are used where emergency

light is needed. Each luminaire must be

permanently connected to mains power supply.

In normal operation the power indicator lights

and the charge indicator blinks to show that the

batteries are in charging condition. In case of a

mains power supply failure the power and the

charge indicators turns off and the luminaire

will light the spot lamps automatically in

emergency mode. When the mains power

supply is restored the device turns to normal

operation.

INSTALLATION

To install the luminaire follow the installation

instructions οn page 3.

OPERATION

When the device is powered from the mains, the

charge indicator blinks and confirms the

charging of the batteries. When the batteries

are charged, it lights constantly. If it does not

light, probably, the batteries are disconnected.

If it does not light and the batteries are

connected, then contact the technician. As long

as the charge indicator blinks, the batteries of

the luminaire are charging and in this period,

any autonomy test must be avoided. When the

charging circle is complete, the indicator lights

continuously (it can be used as an indication of a

power interruption). The batteries charging is

done by a 3 stages technological advanced

procedure, to ensure the appropriate and full

charging of the batteries. The power indicator

confirms the proper connection to the mains. The

TEST button, has a dual use. If pressed instantlly

while the device is connected to the mains, the

device simulates the power interruption, by

lighting the lamps for 3''. In this way, we can

control the driver circuit of the lamps and the

lamps as indicated in paragraph 3 in the text

below.

Dimming option

When the voltage is interrup ted,with

corresponding pressings of the button, we can

choose the illumination of 100%, 50%, 33% or

turned off, either to increase the autonomy time

or not to consume the battery power

unnecessarily. This option is canceled when the

network is restored.

ΑΤΤΕΝΤΙΟΝ!!!

1. Operations for installation, maintainance or

testing must be done by authorized personnel

only.

2. The device must be connected to the mains

Page 1 from 3 923029010_09_013

Thank you for your trust in our products

Olympia Electronics - European manufacturer

ABS/PC, PC

OPERATION TEMPERATURE RANGE

RELATIVE HUMIDITY

EXTERNAL DIMENSIONS

CONSTRUCTION MATERIALS

TYPICAL WEIGHT

GUARANTEE

OPERATION VOLTAGE

MAXIMUM POWER CONSUMPTION

BATTERY (Pb)

CHARGING TIME

INDICATIONS - CONTROLS

BATTERY PROTECTION

MINIMUM AUTONOMOUS DURATION

DEGREES OF COVER PROTECTION

PRODUCED IN ACCORDANCE WITH

EMERGENCY ILLUMINATION

LIGHT SOURCE

24h

Power indicator, battery charge indicator, TEST button

From overcharge and deep discharge

IP65

5 to 40 C

Up to 95%

3 years (1 year for the battery)

180 min

1620lm

White LEDs

3760gr.

EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3

GRL-29/WP

220-240V AC/50-60Hz

12V/7Ah

14.4W/16VA

307 x 100 x 350 mm

``POWER LIGHT`` SERIES FOR WATERPROOF NON MAINTAINED EMERGENCY LUMINAIRES

TECHNICAL CHARACTERISTICS (for LED MODULE Specifications see page 2)

Page 2 from 3

power supply through a fuse dependent by

the total amount of the line’s power load.

3. It is suggested to check every month the

indication LED for battery charging, and by

pushing instantly the TEST button to check

the emergency circuit and the lamps. If the

luminaire does not light

4. It is suggested to check every 6 months the

minimum autononous duration by

disconnecting the mains power supply.

Count the time that the lamps light and in

case of less time than the minimum

autonomous duration the batteries must be

replaced. If the measured time is

considerably less than the minimum

autonomous duration

The replacement of the battery and the light

source must be done using parts of the

same type, by the manufacturer or by a

competent person.

t i

in battery recycling

points. Do not incinerate.

contact the installer.

In case of inactive use for a period greater

than 2 months, disconnect the battery by

pulling out the battery’s connector.

6. I s not allowed to discard batteries in to

common trash bins, they must be

discarded only

Battery replacement

It can be done only by a competent person

and after the mains interruption.

1. Follow the step 2 of the installation

procedure.

2. Disconnect the cables and remove the old

battery.

3. Connect the new battery with the same type

(step 3 of the installation procedure) and

place it in the position of the old one.

4. Follow the step 6 of the installation

procedure and power the device.

923029010_09_013

NOTE: LED= Light Emitting Diode

LABELING EXPLANATION:

X: Self contained

0: Non Maintained (*)

A: Including test device

*180: 3 hours duration

(*) Non Maintained operation: The luminaire lights its illumination source, only in power supply’s

failure.

Maintained operation: The luminaire lights its illumination source, when it is powered by the mains

power supply or not.

The light source contained in this luminaire shall only be replaced by the manufacturer, or

his agent, or a similar qualified person.

NOTE! The light source is non-user replaceable.

LED MODULE CHARACTERISTICS

Olympia Electronics S.A.

60 °C max. across the board

Cable connection between main pcb and led module

20-25V

5.5W

2002163

Manufacturer

Voltage Range

Connections

Nominal Power

Temperature (tc)

GRL-29/WP

INDICATION LED STATUS (with the mains power supply connected)

CHARGE POWER

Disconnected battery / not charging

Charged battery Normal operation mode

No mains power supply

Battery under charge

Indicator ON Indicator Blinking

Indicator OFF

Page 3 from 3923029010_09_013

WARRANTY

Olympia Electronics guarantees the quality, condition and operation of the goods. The period of

warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,

which accompanies each product. This warranty ceases to exist if the buyer does not follow the

technical instructions included in official documents given by Olympia Electronics or if the buyer

modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia

Electronics has fully agreed to them in writing. Products that have been damaged can be returned to

the premises of our company for repair or replacement, as long as the warranty period is valid.

Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge

the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or

not the buyer the transportation cost.

HEAD OFFICE

72nd km. O.N.R. Thessaloniki-Katerini

P.C. 60300 P.O. Box 06 Εginio Pierias Greece

www.olympia-electronics.gr

[email protected]

1. Use the supplied mounting accessories to mount the device (Fig1).

2. Remove the four cover retaining screws (Fig 1).

3. Install the battery cable connectors to the batteries taking care of the polarity, black cable (-)

and red cable (+).

4. Always use in any case round mains cable, with external diameter of 6-9mm (H05RN-F

type 2x1mm² or any other type, at least equal to it’s mechanical and electrical

properties). ATTENTION!! The cable must not be deformed in any way (This

requirement is important to ensure the tightness isolation IP65). Install the cable gland,

pass the round cable through and tighten it all the way.

5. Connect the cables to the respective positions in the terminal block L for phase and N for

neutral.

6. Reinstall the front cover and fasten the retaining screws. (Tightening torque 1Nm).

Pay attention to the 4 sealing o-rings.

WARNING!!

After the installation has finished, charge the batteries for at least 24 hours so as to

obtain the rated autonomous duration.

INSTALLATION PROCEDURE (wall installation only)

TEST

button

Cover

retaining

screws

Fig. 1

Mounting holes

Charge

indicator

Power

indicator
