Olympia electronics GR-290 Manual de usuario

Page 1 from 5923292000_09_016

GENERAL

These devices are used indoors (ta 40 C) in

places where emergency luminaires are

needed. The luminaires GR-290 and GR-

292 are suitable for corridors lighting and

the GR-291 and GR-293 for open area

lighting. Each device must be permanently

connected to mains power supply. In

normal operation the battery is charging. In

case of a mains power supply failure the

device will light the illumination led

automatically in emergency mode. When

the mains power supply is restored the

device turns to normal operation.

INSTALLATION

To install the luminaire follow the installation

instructions οn page 2.

Battery Charging

The battery charging is completely

controlled. In this case, is achieved the

perfect battery maintenance , as well as

the elongation of its duration. When the

battery has completely charged, it charges

with a maintenance current.

Battery Cut-off

The device enters this mode when the

mains power supply fails and battery has

lost its energy. During this operation the

device enters the idle state and battery

consumption is negligible, in order to be

protected from deep discharge.

Manual Test

This test can be done by pushing the test

button. The light source and the emergency

circuit of the device is monitored. The

manual test can be conducted only if the

main power supply and the battery is

connected. During this test period all

indication LEDs are OFF.

Automatic Operational Test

This test includes all the operations that

provide the manual test and is conducted

automatically every 15 days. In order to be

performed, the mains power supply and the

battery should be connected.

Automatic Autonomous Test

The Automatic Autonomous Test is

conducted and measures the device’s back

up operation and emergency duration. The

BATTERY FAULT LED blinks during the

measurement, indicating this process to the

user. This test is conducted automatically

every six months. In order to be performed,

the mains power supply and the battery

should be connected and fully charged. If

NON MAINTAINED SELF TESTING SPOT LIGHT

EMERGENCY LUMINAIRES WITH 1 WHITE POWER LED

OPERATION TEMPERATURE RANGE

RELATIVE HUMIDITY

CONSTRUCTION MATERIAL

EXTERNAL DIMENSION

WEIGHT

GUARANTEE

OPERATION VOLTAGE

MAXIMUM POWER CONSUMPTION

BATTERY (Ni-MH)

CHARGE TIME

INDICATIONS - CONTROLS

BATTERY PROTECTION

MINIMUM DURATION

DEGREES OF COVER PROTECTION

PRODUCED IN ACCORDANCE WITH

EMERGENCY ILLUMINATION

LIGHT SOURCE

220-240V AC / 50-60Hz

3 hours1.5 hour

24 hours

Deep discharge and overcharge protection

IP40

4.8V/1.2Ah

270lm 160lm

1 white power LED

5 to 40 C

Up to 95%

ABS/PC, PC

3 years (1 year for the battery)

435gr.

Ø125 x 65 mm

EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3

Charge, lamp fault, battery fault, TEST button

GR-290 GR-291 GR-292 GR-293

3.7W / 4.1 VA

TECHNICAL CHARACTERISTICS (for LED MODULE specifications see page 4)

Thank you for your trust in our products

Olympia Electronics - European manufacturer

Page 2 from 5

the battery is not fully charged, the test is

postponed until the battery is completely

charged. If during this test, the autonomy is

less than the nominal then the battery fault

led turned on continuously and the battery

must be replaced.

Back Up Operation

The autonomous duration of battery during

emergency mode is at least the one that is

stated in the list of the technical

characteristics. During emergency mode, a

light source test is also performed.

Resetting Errors

Push the Test button for >10 seconds, to

delete all the indicated LED errors. Then

the device enters regular operation mode.

Test Switch

Pressing the test switch less than 5

seconds will initiate a light source test (last

for 3 secs). If the test switch is pressed for

more than 10 seconds, the device will be

reset (delete all errors).

ΑΤΤΕΝΤΙΟΝ!!!

1. Operations for installation, maintainance

or testing must be done by authorized

personnel only.

2. The device must be connected to the

mai n s po w e r su p ply t h rou g h a f u s e

dependent by the total amount of the line’s

power load.

3. The replacement of the battery and the

light source must be done using parts of the

same type, by the manufacturer or by a

competent person.

4. In case of inactive use for a period greater

than 2 months, disconnect the battery by

pulling out the battery’s connector.

5. I s not allowed to discard batteries t i

into common trash bins, they must

b e d i s c a r d e d o n l y i n b a t t e r y

recycling points. Do not incinerate.

The light source contained in this

luminaire shall only be replaced by

the manufacturer, or his agent, or a

similar qualified person.

NOTE! The light source is non-user

replaceable.

INSTALLATION INSTRUCTIONS

Initial installation

1 Untighten the screw and pull up the reflector.

2 Always use in any case round mains cable, with a diameter of 5-10mm (H05RN-F type 2x1mm²

or any other type, at least equal to it’s mechanical and electrical properties). ATTENTION!!

The cable must not be deformed in any way (This requirement is important to ensure the ΙΡ

rating). Install the included gaskets in to the cable entry holes (verify that are not deformed). Make a

hole in the center by using a small screwdriver. Pass the round cable through the gasket. Detach the

power terminal, connect the wires as shown in the picture and attach the power terminal (10A max).

3 Place the battery’s connector to the corresponding connector on the P.C.B.

4 Refit the reflector (mind the correct orientation), tighten the screw securely and the luminaire is ready

for mounting.

NOTE!! After finishing the installation you must power the luminaire for, at least, 24 hours for

battery charging to perform the nominal autonomy.

Cable

entry

hole L

923292000_09_016

Page 3 from 5

Mounting the lamp in suspended ceiling

Set up the lamp to the suspended ceiling as it is shown bellow (Required opening 110mm):

Step 1

Bend the springs, to get into the hole of the suspended ceiling, as you can see to the next figure.

Step 2

Push up the luminaire, as shown in figure 2.

Step 3

Continue to push upwards until the lamp locks.

If you want to pull off the device, put a flat blade

screwdriver, between the device and the ceiling.

Figure 2

Figure 3

Figure 1

Ø110mm

Surface mounting

Install the luminaire according to the following steps:

Step 1. Follow the step 1 of the installation instructions.

Step 2. Unfasten the retaining screw (Figure 4) and detach the part for suspended ceiling installation.

Step 3. (Figure )Drill 2 holes on the base 5 using a 4mm drill bit in order to permit the retaining screws to

pass. Mark these two drilled points on the required mounting location, drill the holes and install

the supplied plastic plugs. ATTENTION!! Especially for the GR-290 and GR-292 luminaire

installation on the ceiling you must align the base with the indications on the luminaire’s base.

Step 4. Install the decorative rim (package included). Next, use the 2 fasteners to install the unit to the

require location.

Step 5. Follow the steps 2,3 and 4 of the installation instructions.

Figure 4 Figure 5

Retaining fastener

Drill here

Indications

923292000_09_016

Page 4 from 5

Lamp fault

indication LED

GR-290, GR-292

GR-291, GR-293

ATTENTION!!!

During installation follow this light direction.

Corridor

lighting

Open

area

lighting

Important notice for the installed luminaires in one area !!!

The installer must connect the battery’s connector first and then should power the luminaire.

The time between batteries connection must be, at least 1.5 minute.

With this variation, it is ensured that the non synchronized Automatic Autonomous Test for

two or more luminaires installed in one area, is not conducted in the same day.

Battery replacement.

It can be done only by a competent person and after the mains interruption.

1. Remove the luminaire from the suspended ceiling (figure 3).

2. Follow the step 1 of the installation instructions.

3. Disconnect the connector and remove the old battery.

4. Connect the new battery with the same type (step 2 of the installation instructions) and place it in

the position of the old one.

5. Replace the removed parts (step 1 and 4) and power the device.

FAULT

LAMP

CHARGE TEST

BATT.

FAULT

LAMP

CHARGE TEST

BATT.

125

FAULT

LAMP

CHARGE TEST

BATT.

FAULT

LAMP

CHARGE TEST

BATT.

Battery

fault

indication

LED

Battery

charge

indication

LED

Figure 6

Test

button

LED MODULE CHARACTERISTICS

Manufacturer

Model Number

Voltage Range

Connections

Nominal Power

Temperature (tc)

Olympia Electronics S.A

60 °C max. across the board 45 °C max. across the board

Non reversible connection between main pcb and led module

3-3.2VDC

2.2W 1.1W

1110143 2704143

GR-290

GR-291

GR-292

GR-293

Status of LEDs

LEDs Description of indication

CHARGE : Battery charging, : battery charged, : disconnected or unfunctional battery

LAMP FAULT : Operation check, : lamp fault, : normal operation

BATT. FAULT : Autonomy test, : battery fault, : normal operation

Note : Blinking, : constantly on, : off

CAUTION : Do not view directly with bare eyes.

923292000_09_016

Page 5 from 5

NOTE: LED= Light Emitting Diode

LABELING EXPLANATION:

X: Self contained

0: Non maintained (*)

A: Including test device

90: 1.5 hour duration

180: 3 hours duration

(*) Non Maintained operation: The luminaire lights its illumination source, only in power

supply’s failure.

Maintained operation: The luminaire lights its illumination source, when it is powered by the

mains power supply or not.

WARRANTY

Olympia Electronics guarantees the quality, condition and operation of the goods. The period of warranty

is specified in the official catalogue of Olympia Electronics and also in the technical leaflet, which

accompanies each product. This warranty ceases to exist if the buyer does not follow the technical

instructions included in official documents given by Olympia Electronics or if the buyer modifies the goods

provided or has any repairs or re-setting done by a third party, unless Olympia Electronics has fully

agreed to them in writing. Products that have been damaged can be returned to the premises of our

company for repair or replacement, as long as the warranty period is valid.

Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge the

buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or not the

buyer the transportation cost.

HEAD OFFICE

72nd km. O.N.R. Thessaloniki-Katerini

P.C. 60300 P.O. Box 06 Εginio Pierias Greece

www.olympia-electronics.gr

[email protected]

923292000_09_016

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Linterna de olympia electronics

olympia electronics

olympia electronics LLB-26/90 Manual de usuario

olympia electronics

olympia electronics GR-8/leds Manual de usuario

olympia electronics

olympia electronics BAU LIGHT Series Manual de usuario

olympia electronics

olympia electronics EASY LIGHT Series Manual de usuario

olympia electronics

olympia electronics GR-290/M Manual de usuario

olympia electronics

olympia electronics GR-490/WP/ADR Manual de usuario

olympia electronics

olympia electronics OLY-1004 Manual de usuario

olympia electronics

olympia electronics GR-8/leds Manual de usuario

olympia electronics

olympia electronics GR-1935/15L Manual de usuario

olympia electronics

olympia electronics GR-939/30L/LT Manual de usuario

olympia electronics

olympia electronics Double Easy Light GR-391/L Manual de usuario

olympia electronics

olympia electronics POWER LIGHT Series Manual de usuario

olympia electronics

olympia electronics GR-220/DUO/M Manual de usuario

olympia electronics

olympia electronics BAU LIGHT Series Manual de usuario

olympia electronics

olympia electronics BAU LIGHT Series Manual de usuario

olympia electronics

olympia electronics GRL-38/90/M Manual de usuario

olympia electronics

olympia electronics GRL-29 WP Manual de usuario

olympia electronics

olympia electronics GRL-37/90/WP Manual de usuario

olympia electronics

olympia electronics Classic Light Series Manual de usuario

olympia electronics

olympia electronics POWER LIGHT Series Manual de usuario

olympia electronics

olympia electronics GR-900/30L/SC Manual de usuario

olympia electronics

olympia electronics CLASSIC LIGHT Series Manual de usuario

olympia electronics

olympia electronics SLD-28/DZ Manual de usuario

olympia electronics

olympia electronics WATERPROOF POWER LIGHT Series Manual de usuario

Manuales populares de Linterna de otras marcas

KYOWA

KYOWA KW-9114 Manual de usuario

Stahl

Stahl ECOLUX 6610 Series Manual de usuario

SNOWJOE

SNOWJOE SUNJOE 24V-LGT500-CT Manual de usuario

PRG

PRG VARI LITE VL5 Manual de usuario

Raytec

Raytec VARIO2 series Manual de usuario

ENSA

ENSA LEDBT18WS2 Manual de usuario

LUG

LUG OFFICE LB LED N/T Manual de usuario

GE Wallighter 250 Manual de usuario

Draper

Draper RLEDL19/B Manual de usuario

Green Lighting

Green Lighting TRI-SENSOR GL4612LU Manual de usuario

Panasonic

Panasonic EY3741B57 Manual de usuario

Clas Ohlson

Clas Ohlson LCC8T Manual de usuario

Coolon

Coolon WDN-140 Manual de usuario

Holiday Travel

Holiday Travel 834873 Manual de usuario

BEGA

BEGA 84 036 Manual de usuario

BEGA

BEGA 33 596 Manual de usuario

Dale Tiffany

Dale Tiffany GT701162 Manual de usuario

Wagan

Wagan Brite Nite Pop-Up USB Lantern Manual de usuario

olympia electronics GR-290 Manual de usuario

Manuales populares de Linterna de otras marcas
