Nortel Manager Manual de instrucciones

1166-025-511 Rev. C

Annex Manager R3.0 Release Notes

AnnexManagerisanSNMP-basedmanagementapplicationthatuses

the X Windows/Motif graphical user interface. Annex Manager is

specifically designed to manage Bay Networks Remote Access Servers,

and is not intended as a general purpose network manager. While Annex

Manager can detect SNMP devices that are not Annexes, you can not use

it to configure a non-Annex device. Annex Manager R3.0 runs on a

workstationplatformrunningBSDUnix(SUNSparc,HP,RS/6000).The

user interface is built to the X Windows/Motif standard. Annex Manager

is designed to run stand-alone and contains all the necessary SNMP

protocolroutines and X Windows/Motif binarylibraries. The installation

process copies the appropriate binary executable and all associated help

and data files from the distribution media onto the workstation's disk

store. Annex Manager can be loosely coupled with several standard

network management products such as SunNet Manager, HP/Openview,

orNetviewforIBMAIX.AnnexManagerdoesnotuse theAPIinterfaces

provided by those products.

Why Use Annex Manager?

Annex Manager allows a system administrator to monitor and configure

Annexes in a network. Annex Manager is a host based, window oriented,

configuration and management application. The displays and user

interface conform to the X Windows/Motif standard. Annex Manager

works best with a color monitor directly attached to a workstation or a

color X Windows terminal connected to a networked UNIX host. In

addition, it supports a grey-scale X Windows terminal attached to a

workstation.

Annex Manager's configuration tool is easy to learn and use. It supports

thefunctionalityoftheolderhost-basedNAconfigurationtoolinaneasier

to use format. Annex Manager is specifically designed to configure and

manage Annex products. Its features depend on the proprietary MIB

defined forthe Annex andon the variousstandard MIBs supported by the

Annex. Therefore, Annex Manager cannot manage other SNMP

166-025-511 Rev. C

Annex Manager R3.0 Release Notes

networked nodes. It is not intended to be a generic SNMP management

tool.

Annex Manager provides features that have not been available with the

NA utility. Users can:

• Configure Annexes in Setup or Customize mode.

• Setup mode allows users to configure one or more Annexes

by setting the most commonly used parameters.

• Customize mode lets users set individual Annex parameters

and provides access to all main menu commands.

• Save current configuration parameter settings in Script files and

restore the parameters from those files.

• Edit script files with a common editor on the workstation.

• Compare the configuration parameters of two ports on the same

Annex or on different Annexes.

• Copy the current configuration parameter settings from one port

to another or one Annex to another.

• Retrieve basic status and statistics information from the Annex.

• Define parameter groups to simplify configuration operations.

• Define site specific defaults.

• Discover Annexes in the network.

• Save Annex address lists after discovery and add names to the

lists manually.

• Display default values for each configuration parameter on

demand.

• Display on-line documentation for all Annex configuration

parameters, all Annex Manager windows and all widgets on the

screens.

• Boot and reset an Annex.

• Broadcast messages to users on Annex ports.

• Automatically reset ports or Annex subsystems after changing

configuration parameters.

Annex Manager R3.0 Release Notes

166-025-511 Rev. C

• Use the editor specified in the user's environment to locate and

edit an Annex configuration file.

Supported Annex Hardware

Annex Manager R3.0 supports the following Remote Annex hardware

running the specified Annex Software Release:

Table 1. Supported Annex Hardware

Hardware Software

RA2000 R13.3

RA4000 R13.3

RA6100 R13.3

5390 R13.3

5391 R13.3

5393 R13.3

5399 R14.0

RA6300 R13.3

Annex 3 R10.0

Micro Annex R10.0

MicroCS R10.0

Cabletron CSMIMII R13.3

Cabletron CSMIMT1 R13.3

Cabletron MODMIM R13.3

3COM 6133C-XS R13.3

3COM 6117C-XS R13.3

166-025-511 Rev. C

Annex Manager R3.0 Release Notes

System Requirements

Annex Manager Release 3.0 runs on several popular UNIX systems.The

following sections list the hardware and software requirements for

installing and running Annex Manager.

For all systems, aminimum of 10MB offree diskspace must be available

prior to installation. A minimum of 32 MB of RAM is recommended,

although specific memory requirements will vary, depending on the type

of workstation and the other tasks that may be concurrent with Annex

Manager. In all cases, a color monitor or X Windows terminal is

recommended, although Annex Manager is usable with a monochrome

X Windows terminal.

Sun Requirements

Annex Manager runs under Sun OS releases 4.1.3c and 4.1.4 and Solaris

releases 2.4 and 2.5.1 on SPARC systems. The following patches are

required for SunOS versions earlier than 4.1.3c:

• Patch number 100444-48 OpenWindows 3.0: OpenWindows

V3.0 Server Patch 3000-86.

• Patch number 100492-01_09 OpenWindows 3.0: jumbo patch

for olwm 3.0.

HP Requirements

Annex Manager runs under HP-UX 9.0.5 and 10.10 on HP 9000 Series

700 Workstations.

IBM Requirements

Annex Manager runs on an IBM RS/6000 workstations under AIX 4.1.4.

Annex Manager R3.0 Release Notes

166-025-511 Rev. C

Remote Display Requirements

If you use Annex Manager on an X Windows terminal, we recommend

that you have more than 2MB of RAM to avoid problems when you have

multiple windows open simultaneously.

New Features and Commands

Annex Manager Release 3.0 now supports the newly released 5399. For

more information on the new 5399 product features and commands,

please see the Remote Annex Release 5.0.12 Release Notes and updated

Annex Manager User’s Guide included with your documentation.

Known Problems/Limitations

• The following erroneous error condition and message should be

ignored:

If a PRI device (6300, 5393, 5399) is selected and the switch

type is changed the following message is displayed:

<annex_name (node port 0)> anxt1CasDnisDigits :

Parameter cannot be set: it does not exist or is

read-only.

There was an error setting one or more parameters.

This may be due to a timeout.
