Nortel INM 4.1 Manual de instrucciones

Release Notes

*NTse68HD.0100*

Integrated Network Management Products

INM Broadband Release 4.1

Release Notes For Release 4.1

Document release: Issue 1.0

Date: November 1998

INM Release 4.1 Release Notes Issue 1.0

Integrated Network Management Products

INM Broadband Release 4.1

Release Notes For Release 4.1

1998 Northern Telecom

Ethernet is a trademark of Xerox Corporation.

HP is a trademark of Hewlett-Packard Co.

NCD is a trademark of Network Computing Devices

S/DMS AccessNode is a trademark of Northern Telecom.

S/DMS TransportNode is a trademark of Northern Telecom.

Tektronix is a trademark of Tektronix Corporation.

UNIX is a registered trademark of UNIX System Laboratories, Inc.

VT100 is a trademark of Digital Equipment Corporation of Maynard, Mass.

X Window System is a trademark of the Massachusetts Institute of Technology.

Document status: Issue 1.0

Date: November 1998

iv of 32

INM Broadband Release 4.1 Issue 1.0

Publication history

November 1998

1.0 (Caroline Samson)

- Ofﬁcial release for INM 4.1 GA.

Table of Contents vof32

INM Release 4.1 Release Notes Issue 1.0

Table of Contents

About this document 7

Structure of the document 7

Audience 7

Summary of Features 9

Release Notes for INM 4.1 GUI 13

1. Installation 13

2. PM Threshold Provisioning 13

3. Protection Status and Control 14

4. Federated Networks 14

5. Partitioned Access 15

6. Conﬁguration Management 15

7. AccessNode/AccessNode Express 16

8. Bridging 17

9. MOAs 17

10. Fault Management 18

11. Connection Management 18

12. OC-192 Release 5.0 WEB UI 20

13. Remote Inventory and Shelf Level Graphics 20

14. On Line Help 20

15. Trouble Ticketing 20

Release Notes for INM 4.1 Building Blocks 21

1. Installation 21

2. Common issues to all Building Blocks. 21

3. AMGUI (Application Management GUI). 21

4. CORBA Gateway 22

5. SONET MOA 22

6. FMBB (Fault Management Building Block) 23

7. RMBB (Resource Management Building Block) 23

8. PMBB (Performance Management Building Block) 23

9. CMBB (Connection Management Building Block) 24

List of Terms 25

Appendix:

Technical support and information 29

INM Customer Care: How to reach us 29

Critical Issues 29

Product Warranty 30

INM Product Services 30

vi of 32 Table of Contents

INM Broadband Release 4.1 Issue 1.0

INM Release 4.1 Release Notes Issue 1.0

7of32

About this document

This document describes the INM Broadband Release 4.1 release notes (for

the GUI and the Building Blocks) that the users should be aware of before

using the software application.

The items that are listed in this document will be addressed in the upcoming

releases of INM Broadband.

It is strongly recommended that users and administrators read all relevant User

Guides prior to installing and using the product.

Structure of the document

This document is structured in a way to highlight the major considerations for

each of the features introduced in this release (GUI as well as Building

Blocks). The two main sections of the document are entitled Release Notes for

INM 4.1 GUI and Release Notes for INM 4.1 Building Blocks, and are divided

into several subsections corresponding to the actual new features introduced in

INM Broadband Release 4.1.

Audience This Release Notes document has been speciﬁcally prepared for the following

audience:

INM 4.1 GUI section

• INM Broadband Software Administrators

• INM Broadband Users

INM 4.1 Building Blocks section

• INM Broadband CORBA Programmers

8of32 About this document

INM Broadband Release 4.1 Issue 1.0

INM Release 4.1 Release Notes Issue 1.0

9of32

Summary of Features

The new features offered by the Integrated Network Management Broadband

Release 4.1 applications are summarized below.

• Protection Status and Control GUI and Contract Interfaces (CI) which

provide GUI enhancements to support protection status display and

protection control for linear systems (1:1, 1+1, 1:N), 2 ﬁber-ring systems

(OC-12 and OC-48 BLSR), as well as OC-192 4-ﬁber rings. Protection

control will provide the ability to issue high speed protection control and

lockout commands from the Graphical Network Browser. This feature will

also provide the open, standards-based Contract Interfaces using the

CORBA Interface Deﬁnition Language (IDL) to perform high speed

protection switch control on the topologies mentioned above.

•Linear and 1:N Trafﬁc Display which provide GUI enhancements to

support the trafﬁc display for linear systems (1:1, 1+1, 1:N).

•OC48 Release 14 support (Connection Management Interface

Enhancements) which provide enhancements to the Connection

Management Building Block (CMBB) Contract Interface (CI) to support

connection provisioning of concatenated STS-3c (Uni/Bi) and STS-12c

(Uni/Bi) connections on OC-48 BLSR systems. Enhancements to

termination inventory and information services are also provided in order

to support OC-3 tributary cards on OC-48 Ring (BLSR) systems.

• Drop and Continue on Protection (DCP) GUI and Contract Interface

provides support for the new DCP provisioning scheme to be used when

provisioning uni-directional or bi-directional matched node connections

on OC-12 TBM and OC-48 BLSR systems. Enhancements to the GUI

support the selection of either the Drop and Continue on Working (DCW)

or the DCP provisioning scheme for creating bi-directional or

uni-directional matched node connections. As well, the editing of an

existing uni-directional or bi-directional matched node connection from

the DCW to the DCP scheme and vice versa is supported. Enhancements

to the Connection Management Building Block (CMBB) Contract

Interface (CI) provide the same DCP provisioning and editing capabilities

through the open, standards based CI using the CORBA Interface

Deﬁnition Language (IDL).

10 of 32 Summary of Features

INM Broadband Release 4.1 Issue 1.0

•PM Threshold Provisioning GUI and Contract Interface provides the user

the capability to get and set Performance Monitoring Threshold

parameters from within the INM Broadband GUI and PMBB

(Performance Management Building Block).

• OC3 Express Data Release 3.1 and 4.0 Contract Interfaces Support for

Fault Management, Connection Management, Performance Monitoring,

ResourceManagement.Thesupportforthenew EIM card is providedonly

through the INM Broadband GUI.

•OC192 Release 4 GUI and Contract Interfaces Support for Fault

Management, Remote Inventory (including Shelf Level Graphics),

Performance Monitoring and Connection Management (for 4 ﬁber BLSR

systems).

•Facility Provisioning Contract Interface Enhancements which support

additional attributes and additional facilities. This includes the support for

optical facilities (OC3, OC12, OC48) and electrical facilities (DS1, DS3,

STS1, STS3, STS12 and STS48 on OC3/OC12 TBM and OC48 Network

Elements.

•GUI Enhancements will be provided to the Alarm Dialog which will be

enhanced to permit resizing of the Dialog itself as well as different parts of

it. In addition, new GUI technology will allow the rearranging, removing,

restoring columns.

•Web User Interface for OC192 Support provides the user to login to the

OC-192 Network Element (which supports the Web UI) and use the new

Web Based NE User Interface that is being introduced in the

TransportNode OC-192 Release 5.0.

• Resource Management Contract Interfaces provide the equivalent support

and functionality existing in the INA Transport Release 2.0 by replacing

the Conﬁguration INA DPE Contract Interfaces with the CORBA Contract

Interfaces (CI). The CORBA CIs will provide functionality for Network

Element discovery/query, equipment inventory query, as well as Facility

provisioning for OC3/OC12 TBM and OC48 systems.

• Integrated Fault Management provides integrated support for fault

information across multi-domain, multi-vendor networks. The Fault

Management Building Block (FMBB) provides open, standards based

contract interfaces using CORBA IDL supporting alarm query and alarm

notiﬁcation functionality, as well as protection status and control.

•Express CX GUI Support of Fault Management, Performance Monitoring,

Remote Inventory, Electronic Software Delivery, Remote Login, Shelf

Level Graphics and Connection Management. The support for the Express

CXNetworkElementisprovidedthroughthe OC-3 Express MOA Release

3.1.
