Multitech MultiModem ISIHP-2S Manual de usuario

MultiModemISI Hybrid Series

Models ISIHP- 2S/2U/4S/4U/4SD

User Guide

MultiModemISI Hybrid Model ISIHP-2S/2U/4S4U4SD

User Guide

88311551Revision B

without prior expressed written permission from Multi-Tech Systems, Inc. All rights

reserved.

Multi-Tech Systems, Inc. makes no representation or warranties with respect to the

contents hereof and specifically disclaims any implied warranties of merchantability

or fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc.

reserves the right to revise this publication and to make changes from time to time

in the content hereof without obligation of Multi-Tech Systems, Inc., to notify any

person or organization of such revisions or changes.

Record of Revisions

Revision Description

A Manual released. Preliminary (beta) release 3/15/99.

B Data for 4S/4U versions added (11/30/99)

Patents

This product is covered by one or more of the following U.S. Patent Numbers:

5.301.274, 5.309.562, 5.355.365, 5.355.653, 5.452.289, 5.453.986. Other patents

Pending.

Trademarks

The Multi-Tech logo is a registered trademark of Multi-Tech Systems, Inc.

NetWare is a registered trademark of Novell, Inc.

Pentium is a registered trademark of Intel Corporation.

SCO is a registered trademark of Santa Cruz Operation, Inc.

UNIX is a registered trademark of X/Open Company, Ltd.

Windows 95 and Windows NT are registered trademarks of Microsoft.

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112

(612) 785-3500 or (800) 328-9717

Fax (612) 785-9874

Tech Support (800) 972-2439

Internet Address: http://www.multitech.com

Contents

Introduction 4

Welcome and Product Description....................................................4

Peripiheral Component Interconnect (PCI) .......................................8

Communication Protocols.................................................................9

Hardware Installation

Introduction ...........................................................................................12

Computer Requirements ........................................................................ 12

Shipping Contents ................................................................................. 12

Safety Warnings ..................................................................................... 12

Hardware Installation Procedure ........................................................... 13

LED Indicators ...................................................................................... 16

Software Installation ....................................................................19

Installing the ISIHP in Windows NT 3.51/4.0 ........................................... 20

Installing TAs and Modems to COM Ports in Windows NT ........... 24

I/O Addresses and IRQ Codes .................................................................... 32

Removing ISIHP Card & Driver in Windows NT 3.51/4.0 ........................ 33

Installing the ISIHP in Windows 95 and Windows 98................................ 34

Windows 95 Installation ............................................................................. 34

To Remove the ISIHP Card and Drivers in Windows 95 .......................... 36

Windows 98 Installation ............................................................................. 36

To Remove the ISIHP Card & Drivers in Windows 98 ............................. 39

To Remove the ISIHP Card ............................................................. 39

To Remove the Drivers .................................................................... 39

Installing TAs & Modems to COM Ports in Windows 95 /98 ........ 40

Removing the Driver (Windows 95 only) ........................................ 49

Configuring the Terminal Adapter: Introduction ........................................49

North American Users ........................................................................... 50

International Users ........................................................................... 51

Optional Settings ................................................................................... 51

ISDN TA Configuration Utility .............................................................52

ConfigMenu Configuration Utility ........................................................58

ConfigMenu menus ............................................................................... 59

Terminal Adapter AT Commands ..........................................................60

Introduction

4 MultiModemISI Hybrid Series, ISIHP-2S/2U/4S/4U/4SD

Welcome to Multi-Techs new MultiModemISI Hybrid Series,

models ISIHP-2S/2U and ISIHP-4S/4U, multiport hybrid ISDN cards

that can be plugged into any PCI slot for applications that involve

ISDN or modem calls over ISDN BRI lines. When the ISIHP is used

with Remote Access Servers (RAS), remote users can call in using

either modems or ISDN terminal adapters (TAs). For V.90 modem

calls, a 56kbps download speed can be achieved without the expense

of T1, E1, or ISDN PRI lines. This manual also describes the ISIHP-

4SD, a serial interface card equipped with four terminal adapters only

(no analog modems are present). The ISIHP-4SD is otherwise like the

ISIHP-4S/4U models. S-models use the ISDN S interface; U-

models use the ISDN U interface.

The ISIHP-2S/2U contains two terminal adapters and four V.90/

K56flex modems. The ISIHP-2S/2U uses two ISDN BRI lines (each

offering two B-channels) to connect to the telco and these connect to

its two built-in terminal adapters. In addition to handling ISDN calls,

each terminal adapter can detect analog modem and fax calls. When

Induction Welcome and Product Description

NetWare Connect (Novell) Driver Installation (2S/2U only) .....................61

Configuring Ports for NetWare Connect .......................................... 61

Removing the Driver (Novell) ......................................................... 61

SCO Open Server 5 Driver Installation ......................................................62

MultiTech Installation Script ........................................................... 63

Activating Ports in SCO Open Server 5........................................... 65

Removing the Driver (SCO Open Server 5) .................................... 67

Linux Driver Installation ............................................................................68

Warranty & Service 71

AT Commands and S-Registers

............................................................................................................... 73

Troubleshooting

.............................................................................................................142

Regulatory Info ...........................................................................148

Index ............................................................................................154

Introduction

MultiModemISI Hybrid Series, ISIHP-2S/2U/4S/4U/4SD 5

analog calls are detected, they are automatically connected to one of

the four V.90 modems on the ISIHP board. In this way, these hybrid

cards can handle either ISDN calls or analog modem calls. Although

the ISIHP-2S/2U contains four ISDN TA ports and four analog

modem ports, only four ports can be active at any one time (because

only four B-channels are present). See Figure 1-1.

The ISIHP-4S/4U works like the ISIHP-2S/2U but contains four

terminal adapters and eight V.90/K56flex modems. The 4S and 4U

models each accommodate four ISDN BRI lines. The configuration of

modem and TA ports for the 4S and 4U models is shown in Figure 1-

The ISIHP-4SD contains four terminal adapters only (the daughter

card containing the eight modems is absent). Since it accommodates

four ISDN BRI lines (each offering two B-channels), it supports eight

independent digital data connections.

Each terminal adapter appears as two ports to the server PC using the

ISIHP card.

ISIHP cards also support dial-out applications via their modems or

terminal adapters.

The ISIHP-2S/2U card offers eight RAS ports using two Basic Rate

Interface (BRI) ISDN lines; the ISIHP-4S/4U has 16 ports using four

BRI ISDN lines. For the ISIHP-2S/2U, its eight ports allow a server

to accept any combination of analog modem and digital ISDN calls,

making a maximum of four simultaneous independent data

connections. For the ISIHP-4S/4U, its sixteen ports allow a server to

accept any combination of analog modem and digital ISDN calls,

making a maximum of eight simultaneous independent data

connections. This arrangement gives the user the flexibility to

customize the settings of the terminal adapters and modems. The

terminal adapters on the ISIHP-4SD can make eight simultaneous

independent connections.

Introduction

6 MultiModemISI Hybrid Series, ISIHP-2S/2U/4S/4U/4SD

RJ-45 jack

Com Ports

Line 1

Line 2

Modem

3456

5ISDN

RJ-45 jack

Figure 1-1: Modems and Terminal Adapters of ISIHP-2S/2U

3456

RJ-45 Jack

Modem

3456

RJ-45 Jack

Modem

3456

RJ-45 Jack

Modem

3456

RJ-45 Jack

Modem

Figure 1-2: Modems and Terminal Adapters of ISIHP-4S/4U (for ISIHP-4SD, no

modems are present)

Introduction

MultiModemISI Hybrid Series, ISIHP-2S/2U/4S/4U/4SD 7

From the perspective of the server PC, the ISIHP-2S/2U is an eight-

port serial card with eight devices permanently attached to the serial

ports (Figure 1-1). The first four ports are the two terminal adapters,

each of which appear as two ports. The remaining four ports are the

four central site modems. The following chart summarizes the

correlation of ports and devices.

2S/2U Port # Device ISDN Line Number

1TA 1

2TA 1

3TA 2

4TA 2

5 Modem 1

6 Modem 1

7 Modem 2

8 Modem 2

From the perspective of the server PC, the ISIHP-4S/4U is an sixteen-

port serial card with sixteen devices permanently attached to the serial

ports (Figure 1-2). The first eight ports are the four terminal adapters,

each of which appear as two ports. The remaining eight ports are the

eight central site modems. The following chart summarizes the

correlation of ports and devices. The ISIHP-4SD contains terminal

adapters only; no modems are present.

Introduction

8 MultiModemISI Hybrid Series, ISIHP-2S/2U/4S/4U/4SD

4S/4U Port # Device ISDN Line Number

1TA 1

2TA 1

3TA 2

4TA 2

5TA 3

6TA 3

7TA 4

8TA 4

9 Modem 1

10 Modem 1

11 Modem 2

12 Modem 2

13 Modem 3

14 Modem 3

15 Modem 4

16 Modem 4

This ISIHP Quick Start Guide contains installation instructions and

technical support information. Because its written for audiences with

basic PC skills, step-by-step instructions for such basic operations as

logging in and file editing are not included.

Peripiheral Component Interconnect (PCI)

First developed by companies such as IntelTM, AT&TTM and Digital

Equipment CorporationTM, the Peripheral Component Interconnect

(PCI) bus used by your ISIHP card provides high performance and is

easy to use. Because PCI devices contain registers with the device

information required for configuration, full auto configuration of PCI

Local Bus add-in boards and components is supported. Performance

factors include a bus data path of 64 bits, clock speeds of 66 MHz,

and bandwidth of 264 Mbs.

Introduction

MultiModemISI Hybrid Series, ISIHP-2S/2U/4S/4U/4SD 9

Communication Protocols for ISIHP Ports

Ports on the ISIHP card can be associated with different protocols, as

follows:

Auto-Protocol. Modem or terminal adapter automatically negotiates

with host to operate using the hosts current protocol.

Central Site Modem. Common designation for analog modems built

into the ISIHP card. These are V.90 modems. For the ISIHP-2S/2U,

the last four modems should be designated as Central-Site modems;

for the ISIHP-4S/4U, the last eight modems should be designated as

Central-Site modems. (See Port/Device table on previous page.)

MultiLink PPP async. This protocol allows the functional bundling

together of three WAN ports so they function as a single high-

bandwidth data pipeline using only one IP address. Bundling occurs

on demand when the needed bandwidth exceeds that available on a

single circuit.

PPP async. (Point-to Point Protocol, asynchronous) Protocol

allowing computers a dial-up connection to the Internet. PPP includes

error detection, data compression and other improvements over Serial

Line Internet Protocol (SLIP) connections.

V.120. Terminal rate adaptation protocols. These apply to ISDN B-

channels when using a V interface. This protocol includes V.110.

X.75. An international standard that allows X.25 packet-switched

networks to communicate with each other. X.75 is a gateway protocol

for interconnection of X.25 public networks.

Introduction

10 MultiModemISI Hybrid Series, ISIHP-2S/2U/4S/4U/4SD

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Módem de Multitech

Multitech

Multitech MultiConnect Cell 100 series Manual de usuario

Multitech

Multitech MultiModem CMDA MTCBA-C1X Manual de usuario

Multitech

Multitech MultiModem MT5634ZBA-V-V92 Manual de usuario

Multitech

Multitech CC1600 Series Manual de usuario

Multitech

Multitech MultiModem MTCBA?H3?U1 Manual de usuario

Multitech

Multitech MTCBA-E-U Manual de usuario

Multitech

Multitech MTCBA-E-U Manual de usuario

Multitech

Multitech BA-Series Manual de usuario

Multitech

Multitech MultiModem ISI5634UPCI-4 Manual de funcionamiento

Multitech

Multitech MultiModem MT5634ZPW-PCI Manual de usuario

Multitech

Multitech MultiModem ZBA USB MT5634ZBA-USB Manual de usuario

Multitech

Multitech SocketModem EDGE Manual de instrucciones

Multitech

Multitech MultiModem MT5634ZPX-PCI-U-NV Manual de usuario

Multitech

Multitech SocketModem MT2456SMI-22 Manual de instrucciones

Multitech

Multitech MultiModem Cell MTCBA-E1 Manual de usuario

Multitech

Multitech MultiModem V.90/K56FLEX MT5600ZDX Manual de usuario

Multitech

Multitech MultiModem DID Manual de usuario

Multitech

Multitech MultiModem II MT5600BA-V.92 Manual de usuario

Multitech

Multitech MTCBA-C Manual de usuario

Multitech

Multitech MultiConnect Cell MTC-G3 Manual de usuario

Multitech

Multitech QuickCarrier USB-D MTD-H5 Manual de usuario

Multitech

Multitech MultiMobile MT5634ZLX/FE Manual de usuario

Multitech

Multitech MultiModem MTCBA?H3?U1 Manual de usuario

Multitech

Multitech MultiModem IND MT5634IND Manual de usuario

Manuales populares de Módem de otras marcas

Davicom

Davicom DM562AP Manual de usuario

EpiValley

EpiValley TATA indicom SXC-1080 Manual de usuario

Zte

Zte WiMAX Manual de usuario

Intelimax

Intelimax MA-2060 Manual de usuario

SMC Networks

SMC Networks D3CM1604V Manual de uso y cuidado

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manual de usuario

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manual de usuario

Samsung

Samsung AceLink SAM-335A Manual de usuario

Enfora

Enfora Enabler-G Guía de configuración rápida

iRZ

iRZ ATM2-232 Manual de usuario

Zhone

Zhone 6310 Manual de usuario

Paradyne

Paradyne Hotwire 7976 Manual de usuario

US Robotics

US Robotics 3453C Manual de usuario

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario

Zte

Zte MF823 Manual de usuario

Four-Faith

Four-Faith F1403 Manual de usuario

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manual de usuario

Gemtek

Gemtek WiMAX WIXFBR-103 Manual de usuario
