Multitech MTCBA-E Manual de usuario

MultiModem® CDMA & EDGE

Internal Wireless Modem

MTZPC-C

MTZPC-E

Quick Start Guide

2 Multi-Tech Systems, Inc.

MultiModem Quick Start Guide

Internal Wireless Modem

CDMA & EDGE

MTZPC-C & MTZPC-E

82100121L Rev. B

This publication may not be reproduced, in whole or in part, without prior expressed

Multi-Tech Systems, Inc. makes no representations or warranty with respect to the

contents hereof and specifically disclaims any implied warranty of merchantability or

fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves

the right to revise this publication and to make changes from time to time in the

content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or

organization of such revisions or changes. Check Multi-Tech’s Web site for current

versions of our product documentation.

Revision Date Description

A 02/09/07 Initial release.

B 02/23/07 Adding bundled & unbuldled packages & changing

number of antennas.

Trademarks

Multi-Tech, MultiModem, and the Multi-Tech logo are registered trademarks of

Multi-Tech Systems, Inc. Windows is a registered trademark of Microsoft in the U.S.

and other countires. All other brand and product names mentioned in this

publication are trademarks or registered trademarks of their respective companies.

Technical Support

Country By Email By Phone

France: [email protected] +(33) 1-64 61 09 81

Europe, Asia, Africa: [email protected] +(44) 118 959 7774

U.S., Canada. all others: [email protected] (800) 972-2439 or

+763-717-5863

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112 U.S.A.

(763) 785-3500 or (800) 328-9717 Fax (763) 785-9874

http://www.multitech.com

MultiModem Quick Start Guide

Multi-Tech Systems, Inc. 3

Introduction

This guide shows you how to set up your MultiModem. For detailed information,

product specifications, troubleshooting tips, and more, see the User Guide,

available on your MultiModem CD.

Check Multi-Tech’s Web site for current versions of our product documentation.

General Safety

The modem is designed for and intended to be used in fixed and mobile

applications. “Fixed” means that the device is physically secured at one location

and is not able to be easily moved to another location. In a “Mobile” application, the

device may be moved regularly from one location to another.

Caution: Maintain a separation distance of at least 20 cm (8 inches) between the

transmitter’s antenna and the body of the user or nearby persons. The modem is

not designed for, nor intended to be, used in applications within 20 cm (8 inches) of

the body of the user.

RF Interference Issues

Avoid possible radio frequency (RF) interference by carefully following the safety

guidelines below.

•Switch OFF your MultiModem when in an aircraft. The use of cellular

telephones in an aircraft may endanger the operation of the aircraft, disrupt the

cellular network and is illegal. Failure to observe this instruction may lead to

suspension or denial of cellular telephone services to the offender, or legal

action or both.

•Switch OFF your MultiModem when around gasoline or diesel-fuel pumps and

before filling your vehicle with fuel.

•Switch OFF your MultiModem in hospitals and any other place where medical

equipment may be in use.

•Respect restrictions on the use of radio equipment in fuel depots, chemical

plants or where blasting operations are in progress.

•There may be a hazard associated with the operation of your MultiModem in

the vicinity of inadequately protected personal medical devices such as

hearing aids and pacemakers. Consult the manufacturers of the medical

device to determine if it is adequately protected.

•Operation of your MultiModem in the vincinity of other electronic equipment

may cause interference if the equipment is inadequately protected. Observe

any warning signs and manufacturers’ recommendations.

MultiModem Quick Start Guide

4 Multi-Tech Systems, Inc.

Package Contents

Bundled Modem Only

•One MultiModem •One MultiModem

•One antenna (CDMA Models) •This Quick Start Guide

•Two antennas (EDGE Models)

•One product CD

•This Quick Start Guide

Establishing a Wireless Account

Obtain a wireless account through a Wireless Service Provider, for example,

Cingular, Sprint, or Verizon. Establishing an account is necessary in order for you

to use the service provider's network. If you establish a EDGE account, you will

receive, from the provider, a SIM pre-programmed for your use. You will need to

insert the SIM into your MultiModem module. If you obtain a CDMA account, no

SIM chip is needed.

Cingular and Sprint

Contact Multi-Tech, a certified national activation agent for Cingular and Sprint, to

set up one of these accounts.

Verizon and Others

For Verizon and other accounts, contact their activation agents directly.

Activation Instructions

See the Sprint, Verizon, or general Customer Activation Notice included with your

MultiModem for a list of the information you must give to the activation agent. You

will receive, depending upon your provider, one or two phone numbers and a

service programming code or lock code. Write these numbers down because you

will have to use them to configure the your unit.

The User Guide presents detailed instructions about establishing wireless accounts

and activating those accounts.

If you have any questions or want to set up your account, contact Multi-Tech

Systems, Inc. at:

800-972-2439 or 763-717-5863.

MultiModem Quick Start Guide

Installing your Modem

Installing your modem requires you to open your system. Please consult your

system manual in addition to the following instructions.

Prerequiste: For EDGE models only, you must have the SIM chip from your

wireless service provider before installing you MultiModem.

MTCBA-C MTCBA-E

1. Turn off your system and unplug it. Failure to do so may result in damage to

both the MultiModem and your system. Do not turn on the system until the

instructions tell you to do so.

2. Remove the cover from your system as instructed in the system manual.

3. Select an empty PCI expansion slot. Remove the expansion slot cover and

save the retaining screw.

4. Before handling the MultiModem, discharge static in your body by touching a

metal piece of the system chassis. Carefully remove the MultiModem from its

antistatic bag, handling it only by the mounting bracket and edges. Do not

touch the gold-plated connectors along the bottom edge.

5. For EDGE units only. Orient the SIM to match the marking on the SIM

compartment, the notch part of the SIM should be facing the mounting

bracket. Insert the SIM into its receptacle.

6. When installing the MultiModem, ensure that the antenna SMA connector is

facing out of the system.

7. Place the MultiModem directly above the expansion slot and gently, but

firmly, push it into the connector until the card’s retaining bracket is flush

against the system chassis.

8. Fasten the retaining bracket to the system chassis with the screw saved in

step 3.

9. Replace the system cover.

10. Attach the antenna to the threaded SMA connector on the mounting bracket.

11. Power up the system.

Multi-Tech Systems, Inc. 5

MultiModem Quick Start Guide

6 Multi-Tech Systems, Inc.

Driver Installation (Windows XP/2003/2000)

The following installation procedure assumes a Windows XP operating system.

Windows 2000 and 2003 have minor variances and are noted as they occur. For

detailed driver installation directions including screens, see the User Guide.

There are two parts to this procedure:

•Part A: Installing the PCI Card and COM port

•Part B: Installing your wireless modem

Part A: Installing the PCI Card and COM port

1. As the system boots up, the Welcome to the Found New Hardware Wizard

screen appears.

Accept the default “No, not this time” because Windows wants to search the

Internet. Click Next.

2. The Found New Hardware Wizard with This wizard helps you install

software for; PCI Serial Port screen appears.

Click Install from a list or specific location (Advanced). Click Next.

3. Insert the MultiModem Product CD into your CDROM drive. Insertion of the

product CD will trigger the Autorun feature. Click Exit to close the splash

screen.

4. The Found New Hardware Wizard with Please choose your search and

installation options screen appears.

Select Include this location in the search: option. Click the Browse button

and browse to the location of the CDROM drive (D:\). Click on the Drivers

folder. Click Next.

5. The Hardware Installation with The software you are installing for this

hardware: MTS 1-PORT UART PCI Card screen is displayed

Click the Continue Anyway button. In Windows 2000/2003, you would click

Yes at this point.

6. The Completing the Found New Hardware Wizard with MTS 1-Port UART

PCI Card screen appears.

Click Finish.

7. Now, the communication port will install. The Welcome to the Found New

Hardware Wizard screen. This install wizard will install the com port driver.

Select “No, not this time” and click Next.

8. The Found New Hardware Wizard with “Multifunction Device” screen

appears.

Click Install from a list or specific location (Advanced). Click Next.

9. The Found New Hardware Wizard with Please choose your search and

installation options screen is displayed.

MultiModem Quick Start Guide

Multi-Tech Systems, Inc. 7

Select Include this location in the search: option. Click the Browse button

and browse to the location of the CDROM drive, usually CD Drive (D:\). Click

on the Drivers folder. Click Next.

10. The Hardware Installation with The software you are installing for this

hardware: Multi-Tech Communications Port screen appears.

Click the Continue Anyway button. In Windows 2000/2003, you would click

Yes at this point.

11. The Completing the Found New Hardware Wizard with MTS

Communications Port screen appears.

Click Finish.

12. Windows may or may not prompt you to reboot your system at this time. If

prompted too, please reboot your system to ensure successful hardware

installation.

Part B: Installing Your Wireless Modem

13. From the desktop, click Start I Control Panel I Phone and Modem Icon, for

Windows 2000/2003, Start I Settings I Control Panel I Phone & Modem

option. Select the Modems Tab and click on the Add button on the bottom

of the window. The Install New Modem screen appears.

Check Don’t detect my modem; I will select it from a list. Then click Next.

14. In the Install New Modem screen, click Have Disk.

15. In the “Models” list of the Install New Modem screen, if you are installing a

wireless CDMA modem, MTZPC-C, choose MultiTech Systems MTZPC-C

Wireless Modem. If you are installing a wireless EDGE modem, MTZPC-E,

choose MultiTech Systems MTZPC-E Wireless modem.

16. In the Install New Modem, Select the port(s) you want to install the modem

on. Choose the COM port that was earlier installed. This COM port usually is

the last one displayed in this screen. Click Next.

17. The Windows Logo Testing screen appears with Multi-Tech Systems

MTZPC-C Wireless Modem for a CDMA modem or MTZPC-E for an EDGE

modem.

Click Continue Anyway.

You have successfully installed your MultiModem, for additional information

on how to use your modem, refer to Chapter 3, Using your MultiModem, in

the User Guide on your product CD.

82100121L

Otros manuales para MTCBA-E

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Módem de Multitech

Multitech

Multitech MultiModem V.90/K56FLEX MT5600ZDX Manual de usuario

Multitech

Multitech Multimodem MTCBA-G-F2 Manual de usuario

Multitech

Multitech Multimodem MTCBA-G-F1 Manual de usuario

Multitech

Multitech MultiModem MTCBA-G-UF1 Manual de usuario

Multitech

Multitech MultiModem II BA-Series Manual de usuario

Multitech

Multitech MultiModem MT2834ZDX Series Manual de usuario

Multitech

Multitech MultiMobile MT5634ZLX Manual de usuario

Multitech

Multitech MTCBA-G-U Manual de usuario

Multitech

Multitech MultiModem Cell MTCBA-E1 Manual de usuario

Multitech

Multitech MultiModem MT5600ZDX Manual de usuario

Multitech

Multitech MultiModem DID MT5634ZBA-DID Manual de usuario

Multitech

Multitech MultiModem MT5600ZDX Manual de usuario

Multitech

Multitech QuickCarrier USB-D MTD-H5 Manual de usuario

Multitech

Multitech MultiModem ZBA MT9234ZBA Manual de usuario

Multitech

Multitech MultiModem II MT5600BA-V.90 Manual de usuario

Multitech

Multitech SocketModem MT5600SMI-32 Manual de instrucciones

Multitech

Multitech MultiModem MT5634ZPX-PCI-U Manual de usuario

Multitech

Multitech MultiModem MT5634ZPX-PCI-U-NV Manual de usuario

Multitech

Multitech CommPlete MT5634HD8 Manual de usuario

Multitech

Multitech MT1932ZDX Manual de usuario

Multitech

Multitech MultiModem MTCBA-G-F4 Manual de usuario

Multitech

Multitech SocketModem GSM Instrucciones de instalación

Multitech

Multitech MultiModem MT9234ZPX-UPCI Manual de usuario

Multitech

Multitech MultiConnect microCell MTCM2-L6G1 Manual de usuario

Manuales populares de Módem de otras marcas

Davicom

Davicom DM562AP Manual de usuario

EpiValley

EpiValley TATA indicom SXC-1080 Manual de usuario

Zte

Zte WiMAX Manual de usuario

Intelimax

Intelimax MA-2060 Manual de usuario

SMC Networks

SMC Networks D3CM1604V Manual de uso y cuidado

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manual de usuario

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manual de usuario

Samsung

Samsung AceLink SAM-335A Manual de usuario

Enfora

Enfora Enabler-G Guía de configuración rápida

iRZ

iRZ ATM2-232 Manual de usuario

Zhone

Zhone 6310 Manual de usuario

Paradyne

Paradyne Hotwire 7976 Manual de usuario

US Robotics

US Robotics 3453C Manual de usuario

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario

Zte

Zte MF823 Manual de usuario

Four-Faith

Four-Faith F1403 Manual de usuario

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manual de usuario

Gemtek

Gemtek WiMAX WIXFBR-103 Manual de usuario
