Multitech SocketModem MT2456SMI-22 Manual de instrucciones

SocketModemÔ

Embedded Modem

MT2456SMI–22

Serial Interface

Developer’s Guide

Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide 2

SocketModemÔ

MT2456SMI–22

Developer’s Guide

PN S000281A, Version A

This publication may not be reproduced, in whole or in part, without prior expressed written permission from Multi-

Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents hereof and specifically

disclaims any implied warranties of merchantability or fitness for any particular purpose. Furthermore, Multi-Tech

Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof

without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.

Revisions

Revision Level Date Description

A03/20/03 Initial release.

Trademarks

Multi-Tech Systems, Inc. trademarks include the SocketModem and the Multi-Tech logo.

Microsoft, Windows, Windows 95, Windows NT, and Windows 2000 are registered trademarks or trademarks of

Microsoft Corporation in the United States and/or other countries.

Patents

This device covered by one or more of the following patents: 6,031,867; 6,012,113; 6,009,082; 5,905,794; 5,864,560;

5,815,567; 5,815,503; 5,812,534; 5,809,068; 5,790,532; 5,764,628; 5,764,627; 5,754,589; 5,724,356; 5,673,268;

5,673,257; 5,644,594; 5,628,030; 5,619,508; 5,617,423; 5,600,649; 5,592,586; 5,577,041; 5,574,725; 5,559,793;

5,546,448; 5,546,395; 5,535,204; 5,500,859; 5,471,470; 5,463,616; 5,453,986; 5,452,289; 5,450,425; 5,355,365;

5,309,562; 5,301,274

Other Patents Pending

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112

Phone: 763-785-3500 or 800-328-9717

Fax: 763-785-9874

Technical Support

Country By Email By Phone

France: support@multitech.fr (33) 1-64 61 09 81

India: support@multitechindia.com 91 (124) 6340778

U.K.: support@multitech.co.uk (44) 118 959 7774

U.S. and Canada: oemsales@multitech.com (800) 972-2439

Rest of the World: oemsales@multitech.com (763) 717-5863

Internet Address: http://www.multitech.com

Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide 3

Contents

Chapter 1 – Product Description and Specifications .................................................................................................4

Product Description....................................................................................................................................................4

Technical Specifications.............................................................................................................................................5

Chapter 2 – Mechanical Specifications........................................................................................................................6

Physical Dimensions ..................................................................................................................................................6

Pin Configurations......................................................................................................................................................7

Chapter 3 – Electrical Characteristics .........................................................................................................................9

Chapter 4 - V.22bis Commands, S-Registers, and Result Codes ............................................................................10

V.22bis Generic Modem Control Commands...........................................................................................................12

V.22bis DTE/DCE-Modem Interface commands......................................................................................................15

V.22bis Call Control Commands ..............................................................................................................................21

V.22bis Modulation Control Commands...................................................................................................................27

V.22bis Error Control and Data Compression Commands.......................................................................................29

V.22bis Synchronous Access Mode Commands .....................................................................................................31

V.22bis FastConnect Command ..............................................................................................................................33

V.22bis Line Side Device Commands ......................................................................................................................34

V.22bis S-Parameters ..............................................................................................................................................35

V.22bis Result Codes...............................................................................................................................................45

Appendix A – Test/Demo Card Information...............................................................................................................47

Block Diagram..........................................................................................................................................................47

Appendix B - Product Approvals, Compliance, and Layout Considerations .........................................................48

Product Safety and EMC Approvals.........................................................................................................................48

Regulatory Design Considerations...........................................................................................................................49

SocketModem Placement ........................................................................................................................................51

Compliance ..............................................................................................................................................................52

Index .............................................................................................................................................................................57

Chapter 1 – Product Description and Specifications

Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide 4

Chapter 1 – Product Description and

Specifications

The Multi-Tech SocketModem supports analog data modem operation with V.22bis Fast Connect, V.42bis data

compression, and V.80 synchronous access mode. The SocketModem is a space-efficient (1" × 2.5"), embedded

modem that is ready-to-integrate into your applications; therefore, dramatically reducing development time and

costs for system designers. The SocketModem also complies with telecom requirements globally and can be

shipped worldwide.

This guide provides the information needed to effectively integrate the SocketModem into your equipment. It also

includes the AT commands for the configuration and control of a data modem and the result codes that the

modem issues in response to the commands.

Product Description

The MT2456SMI SocketModem is a standard 64-pin modem used for integrating data communications. It is a

single-port 5V or 3.3V modem that integrates a modem controller, DSP, and DAA in a 1" x 2.5" form factor and

communicates to a host controller via an asynchronous serial interface.

A SocketModem kit is available. It includes one development board with an RS-232 DB-25 connector, wall power

adapter, RJ-11 jack, and RS-232 cable.

Chapter 1 – Product Description and Specifications

Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide 5

Technical Specifications

The SocketModem meets the following specifications:

Client-to-Server Data Rates V.22 bis

Client-to-Client Data Rates 2400, 1200, 0-300 bps

Data Format Serial, asynchronous

Modem Compatibility V.22bis, V.22; Bell 212A and 103/113; ITU-T V.21 & V.23

Error Correction ITU-T V.42 (LAP-M or MNP 2–4)

Data Compression ITU-T V.42bis

Speed Conversion Serial port data rates adjustable to 300, 1200, 2400, 4800, 9600, 19,200, 38,400,

57,600, and 115,200

Modes of Operation Full duplex over dial-up lines; data mode, command mode, and online command

mode

Flow Control XON/XOFF (software), RTS/CTS (hardware)

Command Buffer 50 characters

Transmit Level –12 dBm (varies by country setting)

Frequency Stability ±0.01%

Receiver Sensitivity –43 dBm under worst-case conditions

Interface Serial ITU-T V.24 logical interface

Diagnostics Local analog loop

Weight 0.02 Kg. (0.04 lb.)

Dimensions 1.045" × 2.541" × 0.680" (2.7 x 6.5 x 1.8 cm)

Power Consumption Typical: 70 mA (.235 W @ 3.3V DC); Maximum: 80 mA (.264 W @ 3.6V DC)

Operating Voltage Typical: 3.3V DC +/- 5%; Absolute Maximum Supply Voltage: 3.7 V DC

Operational Temperature 0 to +70° C ambient under closed conditions; humidity range 20% to 90% (non-

condensing)

Storage Temperature -10° to +85° C

Intelligent Features TIA-602 command compatible

V.22bis fast connect

Supports V.80

Supports Fast POS 9600

Line polarity reversal detection

Line current loss detection

Line-in-use detection during on-hook operation

Extension pickup detection

Call waiting detection

Caller ID (US configuration only)

DTMF detection

autodial, redial

pulse or tone dial

auto answer

call status display

Chapter 2 -Mechanical Specifications

Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide 6

Chapter 2 – Mechanical Specifications

Physical Dimensions

Figure 2–1. Maximum Component Height

Chapter 2 -Mechanical Specifications

Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide 7

Pin Configurations

The MT2456SMI SocketModem with a serial interface use a 16-pin interface to provide an on-board DAA with tip

and ring connections, audio circuit for call-progress monitoring and serial interface via logic level signals.

Figure 2–2. Serial SocketModem Pins

Pin Descriptions

Signal

Name

I/O

Type Description

1 Tip I/O Tip Signal from Telco. Tip connection to the phone line (RJ11 Pin 3).

SocketModem is Tip/Ring is polarity insensitive.

2 Ring I/O Ring Signal from Telco. Ring connection to the phone line (RJ11 Pin 4).

SocketModem is Tip/Ring is polarity insensitive.

24 –RESET I Modem Reset (with weak pull-up). The active low –RESET input resets the

SocketModem logic and returns the AT command set to the original factory

default values or to "stored values" in NVRAM. –RESET is tied to VCC

through a 250 ms time constant circuit for "Power-on-Reset" functionality. The

modem is ready to accept commands within 6.5 seconds of power-on or reset.

Reset must be asserted for a minimum of 300 ns.

26 DGND Ground.

29 DCDIND DCD LED Indicator.

30 RXIND RXD LED Indicator.

31 DTRIND DTR LED Indicator.

32 TXIND TXD LED Indicator.

33 –RTS I Request to Send. RTS signal is used for hardware flow control.

34 –RXD O Received Data. Used to send data received from the telephone line and also

modem responses to the DTE. Modem response take priority over incoming

data. When no data is transmitted, the signal is held in mark condition.

35 –TXD I Transmit Data. The DTE uses this line to send data to the modem for

transmission over the telephone line or to transmit commands to the modem.

The DTE should hold this circuit in the mark state when no data is being

transmitted or during intervals between characters.

Chapter 2 -Mechanical Specifications

Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide 8

36 –RI O Ring Indicate. –RI output ON (low) indicates the presence of an ON segment

of a ring signal on the telephone line. The modem will not go off-hook when –

RI is active; the modem waits for –RI to go inactive before going off-hook.

37 –DSR O Data Set Ready. -DSR indicates modem status to the DTE. –DSR OFF

(high) indicates that the DTE is to disregard all signals appearing on the

interchange circuits except Ring Indicator (–RI). It reflects the status of the

local data set, and does not indicate an actual link with any remote data

equipment.

38 –CTS O Clear To Send. –CTS is controlled by the modem to indicate whether or not

the modem is ready to transmit data. –CTS ON, indicates to the DTE that

signals presented on TXD will be transmitted to the telephone line. –CTS OFF

indicates to the DTE that it should not transfer data across the interface on

TXD.

39 –DCD O Data Carrier Detect. –DCD output is ON (low) when a carrier is detected on

the telephone line or OFF (high) when carrier is not detected.

40 –DTR I Data Terminal Ready (Active Low). The –DTR input is turned ON (low) by

the DTE when the DTE is ready to transmit or receive data. –DTR ON

prepares the modem to be connected to the telephone line, and, once

connected, maintains the connection. –DTR OFF places the modem in the

disconnect state.

41 DGND Ground.

61 VCC 3.3V DC Power.

63 AGND Analog Ground. Analog ground is tied common with DGND on the

SocketModem. To minimize potential ground noise issues, connect audio

circuit return to AGND.

64 SPKR Speaker Output. SPKR is a single ended-output. SPKR is tied directly to the

CODEC. One side of a differential AC output coupled through a 6.8K ohm

resistor and capacitor.

The call progress speaker interface signal is:

Digital speaker output (DSPKOUT); output

DSPKOUT is a square wave output in data mode used for call progress or

carrier monitoring. This output can be optionally connected to a low-cost on-

board speaker, e.g., a sounducer, or to an analog speaker circuit.

Chapter 3 -Electrical Characteristics

Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide 9

Chapter 3 – Electrical Characteristics

3.3V and 5V Serial SocketModem

3.3V DC Characteristics (TA = 0°C to 70°C; VDD = 3.3 V ± 0.3 V) VDDMAX = 3.6 V

5V DC Characteristics (TA = 0°C to 50°C; VDD = 5 V ± 0.25 V) VDDMAX = 5.25 V

Inputs Input High Input Low

–DTR (40), –TXD (35), –RTS (33), –RESET (24) Min 2.0 V Max 0.8 V

Outputs Output High Output Low

–DCD (39), –CTS (38), –DSR (37), –RI (36), –RXD (34)

2mA, Z INT = 120 Ω

Digital Input Capacitance

Min 2.4 V Max 0.4 V

50pF

Handling Precautions

All electronic devices should be handled with certain precautions to avoid damage due to the accumulation of

static charge. Although input protection circuitry has been incorporated into the devices to minimize the effect of

this static buildup, proper precautions should be taken to avoid exposure to electrostatic discharge during

handling and mounting.

Chapter 4 - V.22bis Commands

Multi-Tech Systems, Inc. MT2456SMI-22 SocketModem Developer’s Guide 10

Chapter 4 - V.22bis Commands, S-

Registers, and Result Codes

The V.22bis Commands are covered in the following order in this chapter:

Generic Modem Control Commands

Z Soft Reset and Restore Profile

+VCID Caller ID

+VRID Report Retrieved Called ID

\N Operating Mode - Error Correction

I Identification

+GCI Country of Installation

&F Restore Factory Configuration (Profile)

&T Local Analog Loopback Test

** Load to Internal RAM

DTE/DCE Commands

E Echo

Q Quiet Result Codes

V Result Code Form

W Connect Message Control

X Extended Result Codes (& Call Progress Information)

&C RLSD Option

&D DTR Option

&K Flow Control

&R RTS/CTS Option

\G Modem-to-Modem Flow Control (XON/XOFF)

+IFC DTE-Modem Local Flow Control

+IBC In Band Commands

Call Control Commands

DDial

T Set Tone Dial (Default)

P Set Pulse Dial

A Answer

H Disconnect (Hang Up)

O Return to On-line Data Mode

L Monitor Speaker Volume

M Monitor Speaker Mode Control

&G Select Guard Tone

&P Select Pulse Dial Make/Break Ratio

&V Display Current Configuration and Stored Profiles

%L Report Line Signal Level

%Q Report Line Signal Quality

*B Display Blacklisted Numbers

*D Display Delayed Numbers

-STE Set Telephony Extension

+PCW Call Waiting Enable

+VDR Distinctive Ring

Modulation Control Commands

+MS Modulation Selection

%E Enable/Disable Line Quality Monitor

BITU-TorBell

Tabla de contenidos

Otros manuales de Módem de Multitech

Multitech

Multitech MTCBA-E-U Manual de usuario

Multitech

Multitech MultiModem MTCBA-G-F4 Manual de usuario

Multitech

Multitech MultiModem II MT5600BA-V.90 Manual de usuario

Multitech

Multitech SocketModem Cell Cat M1 Guía de aplicación

Multitech

Multitech Multimodem MTCBA-G-F1 Manual de usuario

Multitech

Multitech MultiModem MT5634ZPX-V.92-ISA Manual de usuario

Multitech

Multitech Multimobile MT10100ZL-X/E Manual de usuario

Multitech

Multitech MultiConnect microCell Manual de usuario

Multitech

Multitech MTCBA-C-U-N1 Manual de usuario

Multitech

Multitech MultiModem GPRS with Ethernet Interface Manual de usuario

Multitech

Multitech QuickCarrier USB-D MTD-MNA1 Manual de usuario

Multitech

Multitech MultiModem MT5600ZDX Manual de usuario

Multitech

Multitech MultiConnect MTCM Manual de usuario

Multitech

Multitech MTSMC-H5 Guía de aplicación

Multitech

Multitech QuickCarrier USB-D Manual de usuario

Multitech

Multitech MultiModem Cell MTCBA-E1 Manual de usuario

Multitech

Multitech Dragonfly MTQ-LEU7 Guía de aplicación

Multitech

Multitech MultiModem MTCBA-C Manual de usuario

Multitech

Multitech MultiMobile MT9234MU-CDC Manual de usuario

Multitech

Multitech MultiModem V.90/K56FLEX MT5600ZDX Manual de usuario

Multitech

Multitech MultiModem DSVD MT5600DSVD Manual de usuario

Multitech

Multitech MT2834BA Manual de usuario

Multitech

Multitech MT2834MR Manual técnico

Multitech

Multitech MessageSaver MT5634MSV Manual de usuario

Manuales populares de Módem de otras marcas

Davicom

Davicom DM562AP Manual de usuario

EpiValley

EpiValley TATA indicom SXC-1080 Manual de usuario

Zte

Zte WiMAX Manual de usuario

Intelimax

Intelimax MA-2060 Manual de usuario

SMC Networks

SMC Networks D3CM1604V Manual de uso y cuidado

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manual de usuario

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manual de usuario

Samsung

Samsung AceLink SAM-335A Manual de usuario

Enfora

Enfora Enabler-G Guía de configuración rápida

iRZ

iRZ ATM2-232 Manual de usuario

Zhone

Zhone 6310 Manual de usuario

Paradyne

Paradyne Hotwire 7976 Manual de usuario

US Robotics

US Robotics 3453C Manual de usuario

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario

Zte

Zte MF823 Manual de usuario

Four-Faith

Four-Faith F1403 Manual de usuario

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manual de usuario

Gemtek

Gemtek WiMAX WIXFBR-103 Manual de usuario
