MicroNet SP6824P Manual de usuario

User’s Manual

24-port 10/100Mbps Layer 2

Managed Switch With 370W

PoE output power

Model No.: SP6824P

Table of Contents

1. Introduction............................................................................................4

1.1 Package Contents ..............................................................................4

1.2 Feature ...............................................................................................4

1.3 Hardware Specification.......................................................................6

1.4 Environments Specification.................................................................7

1.5 Standard Conformance.......................................................................7

1.6 How to Use this Guide........................................................................8

2. Installation..............................................................................................9

2.1 Product Description Overview.............................................................9

2.2 Switch Overview .................................................................................9

2.3 LED Function....................................................................................10

2.4 Reset Button.....................................................................................11

2.5 Installing the Switch..........................................................................11

2.6 Rack- Mount Placement....................................................................13

3. Configuration .......................................................................................15

3.1 Web-based configuration..................................................................16

3.2 Command Line Interface (by Console or Telnet) ..............................48

3.3 Privileged Mode commands..............................................................49

3.4 Global Config mode commands........................................................56

3.5 Interface Config mode commands....................................................72

4. Specifications.......................................................................................76

4.1 Cable specifications..........................................................................76

4.2 Technical specifications....................................................................78

5 Warranty statement ............................................................................79

Notes and Cautions

A NOTE indicates important information that helps you make

better use of your device.

A NOTICE indicates either potential damage to hardware or loss

of data and tells you how to avoid the problem.

A CAUTION indicates a potential for property damage, personal

injury, or death.

1. Introduction

Micronet SP6824P 10/100Mbps Layer 2 Managed Switch with 370W

PoE output power offers high performance and a full set of layer 2 networking

management features at an affordable cost, suitable for high performance

workgroups and server applications. With 10/100Mbps RJ-45 ports and shared

mini-GBIC slots for fiber optic connection, it delivers maximum throughput to

high performance users or provides a backbone to a growing business

network.

1.1 Package Contents

Package contains the following:

SP6824P switch RS-232 cable Power cord or adapter

Rubber feet Brackets CD for user manual

and utilities

If any of the listed items is missing or damaged, please contact the place of

purchase for a replacement immediately.

1.2 Feature

zFour groups (history, statistics, alarms, and events) of embedded remote

monitoring (RMON) agents for network monitoring and traffic analysis

zProvides SNMP protocol(v1/v2c/v3) to monitor and control the switch by

using SNMP management applications such as HP Open View

zSupports IGMP snooping to limit flooding of IP multicast traffic and filtering

for controlling the set of multicast groups to which hosts on a switch port

can belong

zSupports 802.1d/1w/1s Spanning Tree Protocol for loop free installation.

zSupports 802.1Q VLAN for assigning users to VLAN associated with

appropriate network resources, traffic patterns, and bandwidth. Up to 256

VLAN entries can be configured

zSupports Management VLAN for administration to protect switch to be

attacked by client.

zSupports IEEE 802.3ad Link Aggregation, up to 14 LAG groups, and 8

ports for each LAG group

zBuilt-in DHCP client to get IP address from DHCP server automatically

zSupports SNTP to synchronize the precision time with Internet Time

server.

zSupports many-to-one, one-to-one Port Mirroring function.

zSupports for IEEE 802.1p/DSCP CoS scheduling for classification and

preferred high-priority traffic.

zSupports per port Ingress and Egress Rate Limiting.

zSupports Dynamic Learning mode for Port Security function, up to 24

MAC addresses can be learned for each port

zSupports 802.1X port-based authentication, and build-in RADIUS client to

co-operate with the RADIUS servers.

zSupports broadcast, multicast, and unknown unicast storm control

zSupports Protected Port feature.

zSupports SSL/SSH secure access.

zSupports Access Control List feature, up to 256 rules can be configured.

zSupports web-based interface for management

zSupports CLI interface for local console or remote Telnet management

zSupports TFTP, HTTP and X-modem protocol for firmware/configuration

upgrade or backup.

zSupports TACACS+ login authentication.

zSupports DSCP remarking

zSupports DHCP Relay

zSupports IGMP Proxy

zSupports IGMP Querier

zSupports LLDP

zSupports IGMP Immediate Leave

zSupports RSTP Root Guard

zSupports DHCP/TFTP configuartion download

zSupports Port Self-Loop Detection

zSupports DHCP Snooping

zSupports Dynamic ARP Inspection

zSupports IP Source Guard

zSupports Green Ethernet

zSupports Auto Dos

1.3 Hardware Specification

zSupport 24 10/100Mbps copper ports with 2 shared mini-GBIC slots

zUser configurable 100FX or 1000Base-SX/LX mini-GBIC fiber module on

mini-GBIC ports

zSupports half duplex and full duplex modes and auto-negotiation for all

10BASE-T/100BASE-TX/1000BASE-T ports

zIEEE 802.3ab Auto MDI/MDI-X on all 100/1000 twisted-pair ports

zAutomatic polarity detection and correction on all RJ-45 ports for

automatic adjustment of wiring errors

zThroughput up to 48 Gbps.

zProvides IEEE802.3x Flow Control mechanism ensures zero packet loss,

which uses Back Pressure for half-duplex operation and Flow Control for

full duplex operation.

zSupports 8K MAC address and Up to 4Mb packet buffer

zSupports Store & Forward architecture and performs forwarding and

filtering

zProvides non-blocking switching performance

zSupports Jumbo Frame up to 9KB

zProvides a RS-232 port for system configuration.

zFlexible TCAM-based Compact Field Process for packet classification and

filtering.

zLow power consumption.

Supports 802.3af standard with up to 15.4W/port at each port up to 24 ports

maximum.

Supports non-standard PoE up to 30W/port up to 12 ports

1.4 Environments Specification

Size (H x W x D) H 44.5 x W 430 x D 350mm

Weight(Net/Gross) 4.6kg /6.5kg

Power 30W

Operating Temp. 0 ~ 40 (32 ~ 104 )℃℃℉ ℉

Storage Temp. -20 ~ 70 (℃℃-4 ~ 158 )℉℉

Operating Humidity 20% to 85% relative humidity, Non-Condensing

Storage Humidity 10% to 90% relative humidity, Non-Condensing

1.5 Standard Conformance

EMC Certification FCC Class A, CE

1.6 How to Use this Guide

This user guide is structured as follows:

Chapter 2,Installation explains the functions of the switch and how to

physically install it.

Chapter 3, Configuration explains how to set up and modify the configuration

of the switch.

Chapter 4, Specifications contains information about the cables, and the

technical specifications of the switch.

Appendices include the Warranty Statement. Read them as

necessary.

2. Installation

This chapter describes the function of the management switch components

and shows how to install it on the desktop or shelf. Basic knowledge of

networking is assumed. Read this chapter completely before continuing.

2.1 Product Description Overview

Micronet SP6824P supports 802.1Q VLAN, QoS, 802.1d / 1w/ 1s Spanning

Tree Protocol, 802.1x, Port Security, Port Mirroring, IGMP Snooping, SNTP,

Storm Control, Rate Control, SNMP etc. features.

2.2 Switch Overview

Figure 2.2.1a Front Panel

Figure 2.2.1b Rear Panel

Table 2.2.1c Port Function

Port Function

1~24 This is where you connect the Cat. 5e or better ethernet

cable for 10/100Mbps ethernet connection

miniGBIC This is where you connect the SFP module for fiber

connection.

Front

panel

Console This is where you connect the RS-232 cable for CLI

management.

Real Panel Power This is where you connect the AC power cord or DC

adapter.

2.3 LED Function

This section explains the definition of the Switch’s LEDs on the front panel.

PWR ▓(Green)LED lights up, it shows the system is powered up.

LINK/ACT ▓(Green)

LED lights up, it indicates a successful connection of that port is

established. Otherwise, it indicates the link is off or no-link

detected of that port. When the LED blinks, it indicates the port

is activating and transmitting data;

PoE ▓(Amber) LED lights up only when the corresponding port supply power.

1000M ▓(Amber) LED lights up only when the corresponding port works at

1000Mbps,
