Marsden MS-150 Manual de usuario

USER MANUAL

MS-150/MS-300

Marsden Floor Scale

Please take time to read these

instructions before starting

to use the scale

Version 1.0 05/18

Contents

Product Specification 3

Safety Instructions 4

Display Symbols 5

Operation: Basic Functions 6

Operation: Advanced Functions 7

Calibration Procedure 7

Contact Information 8

Page 2

Product Specification

Model

Marsden MS-150/MS-300

Capacity/Division

150kg x 50g/300kg x 100g

Units of Measure

Kg/lb/oz

Function Keys

HOLD, UNIT, TARE, ON/ZERO/OFF

Stabilization Time

1-2 Seconds

Operating Temperature

5 to 35°C

Power Supply

Rechargeable battery pack

12V 1500mA DC adaptor

Indicator Display

25mm LCD display with 4 ½ active digits

Platform Dimensions

575mm x 575mm x 55mm

Indicator Dimensions

285mm x 110mm x 55mm

Please note: Marsden’s policy is one of continuous development and therefore

we reserve the right to change product specification without notice.

Indicator images in this manual are for illustration purposes only.

Manufacturer’s Declaration of Conformity

This product has been manufactured in accordance with the harmonized

European standards, following the provisions of the below stated directives:

Electro Magnetic Compatibility Directive 2014/30/EU

Low Voltage Directive 2014/35/EU

Marsden Group Holdings Ltd.

Page 3

Safety Instructions

Before putting this scale into use, please read with care the information given in this user

manual, which contains important instructions for proper installation, use and maintenance

of the device.

Marsden/the manufacturer shall not be liable for damages arising from failure to heed the

following instructions:

•When using electrical components under increased safety requirements, always

comply with appropriate regulations.

•Inappropriate installation/use will render the warranty null and void.

•Ensure the voltage marked on the power supply unit matches your mains supply.

•This product is not waterproof. We do not recommend using the scale in humid,

damp or wet environments.

•Observe the permissible ambient temperatures for use.

•The device meets the requirements for electromagnetic capability. Do not exceed

the maximum values specified in the applicable standards.

If you have any problems, contact Marsden/your local dealer/your service partner.

Cleaning

•Please do not use corrosive liquids or large amounts of water to clean the scale.

•Always disconnect the scale from the mains power supply before cleaning.

Maintenance

•The scale does not require any routine maintenance. However, we recommend

checking the scale’s accuracy at regular intervals. If any inaccuracies occur, please

contact your local dealer or service partner.

•Service contracts for scales are available from Marsden. Find out more by calling

01709 364296.

Page 4

Display Symbols

➔

Scale in auto zero range (indication = accurate

zero)



Confirms that weight resuklt is stable

kg , lb or oz

Scale in weighing mode; denotes units of reading

Battery is low; approximately five minutes of

operation remaining before the scale will power

down

The Net Weight is being display (NW) or the Gross

Weight is displayed (GW)

Page 5

Operation: Basic Functions

Switching the Scale on

Press ON/ZERO/OFF to power-on the

scale. When the display shows zero it is

ready for weighing.

Switching the Scale off

To switch the scale off, press and

hold ON/ZERO/OFF. The scale will now

power down.

Setting the Scale to Zero

If at any time the reading shows

anything other than zero when there is

nothing on the scale, you can reset the

display by pressing ZERO once.

Page 6

Operation: Advanced Functions

Hold Function

To stabilise the weight reading on the

display, press HOLD and then add the

item to the scale. The Hold function can

be disabled by pressing HOLD again.

Tare Function

To remove the weight of an item from

the display, such as a container, add the

container to the scale and press TARE.

The display will only register new items

being added to the scale.

Unit Function

To change the weighing units on the

display, press UNIT to toggle between

kg, lb and oz.

Calibration Procedure

1) Turn the scale off.

2) Press and hold ON/ZERO/OFF then press UNIT key 3 times.

3) Release ON/OFF key, and display shows zero count.

4) Press TARE, display shows zero.

5) Press TARE again to enter calibration mode.2

6) In calibration mode, press UNIT key to select calibration weight unit (kg or lb).

7) Load calibration weight on platform.

For 150kg version, please use 100kg to calibrate

For 300kg version, please use 200kg to calibrate

8) Display shows span count.

9) Press TARE, display shows “CAL”, and then shows calibration weight in normal mode.

10) Remove the weight; calibration is now finished.

For further help with the functions of this scale, please contact Marsden or your dealer.

Page 8

Tel: 01709 364296 / 0800 169 2775

Fax: 01709 364293

E-mail: sales@marsdengroup.co.uk

Manufacturing and Distribution:

Unit 7, Centurion Business Park,

Coggin Mill Way,

Rotherham,

S60 1FB

Head Office:

Unit 1, Genesis Business Park,

Sheffield Road,

Rotherham

S60 1DX

www.marsden-weighing.co.uk

IN-0805 [3021J] REV 05/2018
