Logitech G500 Manual de usuario

User’s guide

LogitechTM

Gaming Mouse G500

Contents 內容 ෹ഺ 목차

English Conﬁguration, 3 Mouse features, 4

繁體中文設定，8滑鼠功能，9

଼ᄏᒦᆪ ๼ᒙǈ13 ၡܪ৖ถǈ14

한국어 구성, 18 마우스 기능, 19

User’s Guide

English 3

Conﬁguration

Your Gaming Mouse G500 is combat-

ready, right out of the box. For access

to more advanced features—such as

using onboard memory to store personal

settings—download Logitech™ SetPoint

for the G500 and use it to tune your

mouse for maximum performance.*

Start SetPoint from the taskbar or the1

Windows Start menu.

Upon launching, SetPoint asks you

to select a Logitech device.

Double-click the thumbnail image of2

the G500.

The Overview appears, providing

general information about your

G500.

Overview

Displays your current proﬁle settings

Welcome screen

Double-click the image of your G500

mouse to view and modify settings

Download the latest version of SetPoint from

www.logitech.com/downloads

Gaming Mouse G500

4English

Mouse features

Gaming proﬁles to go

The G500 gives you onboard memory

for storing your gaming proﬁle—personal

game preferences you can take with you

to LAN parties or competitions.

With settings-to-go, you can play your

favorite titles on computers other than

your own, without installing driver software

or recreating game preferences.

You can store settings such as button

assignments, keyboard macros, DPI

settings, and USB report rate in your

proﬁle.

Use SetPoint software to create as many

proﬁles as you want and save them to

disk. Select any one of the saved proﬁles

to store on the G500, or use application

detection to automatically switch proﬁles

when you start a new game.

Proﬁle Manager

Choose a proﬁle to store in onboard memory

Macro Editor

Record keystrokes and other mouse actions as

macros you can save in proﬁles

User’s Guide

English 5

Adjustable DPI

Change your mouse DPI on the ﬂy to

instantly adapt to different game

situations—without pausing the action.

Before software installation, you can toggle

between three preset levels of resolution:

400 dpi, 800 dpi, and 2000 dpi.

Use low DPI for pixel-precise targeting.

Shift to high DPI for lightning-fast

maneuvering.

Storing DPI settings in memory

Use SetPoint to create up to ﬁve custom

DPI settings you can store in onboard

memory and take with you to LAN parties

and competitions. Specify custom DPI

settings between 200 dpi and 5700 dpi

(in increments of 100). Your mouse

indicates current DPI with different

patterns of LED panel lights.

Panel lights

indicate current

DPI setting

Mouse features

Press (+) to raise DPI

Press (-) to lower DPI

DPI settings

#1 #2 #3 #4 #5

Gaming Mouse G500

6English

Dual-mode scroll wheel

Provides two scrolling modes, click-to-click

and hyper-fast, and three programmable

buttons—middle button, tilt left, and tilt

right.

Scroll wheel mode

shift button

Press to shift between

hyper-fast and click-to-

click scrolling

Dual-mode

scroll wheel

Hyper-fast scrolling

When you’re not gaming, the

near-frictionless wheel lets you

ﬂy through long documents and

Web pages

Precision scrolling

Click-to-click scrolling mode is

perfect for selecting weapons

Mouse features

User’s Guide

English 7

Weight tuning system

Tune the weight and balance of your

G500 with an innovative weight tuning

system.

Mix and match up to 27 grams of weights

in 1.7-gram and 4.5-gram increments for

optimal customization of balance and heft.

A lighter mouse reduces fatigue and is

ideal for gamers who like to “skate.” Add

weight if you prefer a heavier mouse that’s

easier to control.

Mouse features

To add weights:

Press the cartridge release button on1

the base of the mouse to eject the

weight cartridge.

Snap the desired weights into the2

cartridge.

Slide the cartridge into the mouse.3

Cartridge

release

button

Mix and match weights

Snap up to six cylindrical

weights into the cartridge to

ﬁne-tune your G500 for optimal

inertia and balance

8 繁體中文

遊戲滑鼠 G500

設定

您只需將遊戲滑鼠 G500 從包裝盒中取

出，即可加入戰鬥。如果要使用更多進

階功能，例如使用內建記憶體來儲存個

人設定等，請下載用於 G500 的Logitech™

SetPoint，然後使用該軟體將您的滑鼠調

整到最佳性能。*

從工作列或 Windows「開始」功能表啟1

動SetPoint。

在啟動期間，SetPoint 會要求您選擇

一種 Logitech 裝置。

連按兩下 G500 滑鼠的縮圖。2

即會顯示「總覽」，其中包含有關

G500 的一般資訊。

總覽

顯示您目前的設定檔設定。

歡迎螢幕

連按兩下 G500 滑鼠影像以檢視和修改

設定。

從www.logitech.com/downloads 下載最新

版本的 SetPoint

繁體中文 9

使用者指南

滑鼠功能

遊戲設定檔與您隨行

G500 提供內建記憶體供您儲存遊戲設定

檔，您可以帶著這些個人遊戲偏好設定

加入連線遊戲或競賽遊戲。

透過使用這些儲存的設定，您可以在他

人的電腦上用您最喜歡的設定玩遊戲，

而無需安裝驅動程式軟體或重新建立遊

戲偏好設定。

您可以將按鈕指派、鍵盤巨集指令、DPI

設定以及 USB 報告頻率等設定儲存在您

的設定檔中。

您可以使用 SetPoint 軟體建立多份設定

檔，並將其儲存到磁碟中。從儲存的設

定檔中任選一份儲存到 G500 上，或使用

應用程式檢測在啟動新遊戲時自動切換

設定檔。

設定檔管理器

選擇一份設定檔儲存到板載記憶體中

巨集指令編輯器

將按鍵動作和其他滑鼠動作記錄為可以儲存到

設定檔中的巨集指令

10 繁體中文

遊戲滑鼠 G500

可調整 DPI

在遊戲期間變更滑鼠 DPI 以即時適應不同

的遊戲狀況，而無需暫停遊戲動作。

安裝軟體之前，您可以在預設的解析度

等級 400 dpi、800 dpi 和2000 dpi 之間

切換。

對於像素精度瞄準，可使用低 DPI 設定。

對於快速操縱，可切換到高 DPI 設定。

將DPI 設定儲存到記憶體中

使用 SetPoint 建立多達五種自訂 DPI 設

定，您可以將其儲存到內建記憶體中，

並帶著這些設定參加連線遊戲和競賽遊

戲。在 200 dpi 到5700 dpi 之間指定自

訂DPI 設定（以 100 為增量）。您的滑

鼠可使用不同模式的 LED 面板燈來指示

目前的 DPI 設定。

LED指示燈

顯示目前的

DPI 設定

滑鼠功能

按(+) 可提高 DPI

按(-) 可降低 DPI

DPI 設定

#1 #2 #3 #4 #5
