LevelOne POH-1250 Manual de usuario

12 FE PoE Hub POH-1250

H/W Version: 1

Product Overview

LevelOne POH-1250 12 FE PoE Hub is equipped with

12 RJ-45 ports featuring PoE function to eliminate the

bulky power cable need while implementing your

network infrastructure thus allowing greater exibility

in the locating of network devices and signicantly

decreasing installation casts.

Advanced PoE Solution

POH-1250 is fully compliant with the IEEE 802.3af

standard and acts as a patch panel between a switch

and other network devices to provide power and data,

and it supplies PoE power of up to 15.4w per port over

existing Cat.5 Ethernet cable.

Easy to Use

The compact 19’’, IU rack-mountable design enables

the switch to be easily located in a server room in

order to centralize power management and simplify

network integration for various applications. For all

the functions featured in POH-1250 users can get the

benets of exible network solutions that can simplify

the installation of wireless access points, IP cameras,

IP phone and other devices or applications in the

network.

Key Features

- 12 ports Power over Ethernet Hub

- IEEE 802.3af compliant

- Remote power feeding up to 100 meters

- Centralized power distribution for PoE Powered

Device (PD)

- High safety short circuit protection

- Total PoE Power Budget: 200W

- Power protection: OVP/OCP/OTP

- Power auto recovery

- 19’’ Rack mountable size

- Provides maximum power of 15.4 watts per PoE port

POS-4001

Outdoor High Power

PoE Splitter (12V)

Works Well With

POR-0100

PoE Repeater

1. PoE LEDs

2. Data + Power Out

3. Power Switch

4. Panel Mounted Male Connecotr

12 1 2 1 2 3 4

PoE PD/PSE/Repeaters

www.level1.com

one world_one brand_one level_

Standards Compliance

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-Tx Fast Ethernet

IEEE 802.3af Power over Ethernet

Power Protection

Auto Recovery, OVP, OCP, OTP

PoE Power Output

Per Port DC 48V 15.4 watts

Power Pin Assignment: 4/5(+), 7/8(-)

PoE Power Budget

200 W

Technical Specication

Indicators

LEDs: Power x 1 (Green), PoE Status x 12 (Green)

Dimension (W x D x H) / Weight

480 x 60 x 44 mm (18.8 x 2.36 x 1.73 in) / 1.2kgs (2.64lbs)

Environmental Conditions

Operating Temperature: 0~50°C

Storage Humidity: 5~95% Non-condensing

Storage Temperature: -40 ~70°C

Regulation

FCC Part 15 Class A, CE

Product Diagram

Order Information POH-1250: 12 FE PoE Hub

Package Contents 12 FE PoE Hub x 1

Power Cord x 1

User Manual x 1

All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.

Ethernet Cable (RJ-45)

PoE

V1.0

POH-1250

100m

Ethernet Switch

POR-0100

IP camera

PoE IP phone

PoE Wireless AP

100m

100m 15.4W

15.4W
