LevelOne

GSW-1601TX

GSW-2401TX

16/24Port 10/100Mbps Switch

with Gigabit option

User's Manual

(Vision 1.0)

FCC Class A Appliance

This equipment generates and uses radio frequency energy. If it is not

installed and used properly in strict accordance with the manufacturer‘s

instructions, it may cause interference to radio and television reception.

It has been type-tested and found to comply the specifications in

sub-part J of Part 15 of FCC Rules, which are designed to provide

reasonable protection against such interference in a residential

installation. There is no guarantee that interference will not occur in a

particular installation. If this equipment does cause interference to radio

or television reception which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

Re-orient the receiving antenna

lRelocate the computing device with respect to the

receiver

lMove the computer away from the deceiver

lPlug the computer into a different outlet so that compute

and receiver are on different electrical circuits.

If necessary the user should consult the dealer or an experienced

radio or television technician for additional suggestions.

The information in this manual is subject to change without notice. All

the brand names are registered trademarks of their respective

companies

Contents

Package List---------------------------------------------------------------------- iii

Introduction---------------------------------------------------------1

Features------------------------------------------------------------------------------1

Identifying ExternalComponents---------------------------------3

Front Panel--------------------------------------------------------------------------3

Rear Panel---------------------------------------------------------------------------4

LED Indicators----------------------------------------------------------------------5

Connecting The Switch--------------------------------------------------5

Connecting End node or Hub or Switch--------------------------------------5

Connecting to Network Backbone or Server--------------------------------6

Configuration------------------------------------------------------8

Main Menu-------------------------------------------------------------------------9

Speed Mode-----------------------------------------------------------------------10

Address Learn---------------------------------------------------------------------12

VLAN--------------------------------------------------------------------------------13

Queues Priority-------------------------------------------------------------------16

Trunk--------------------------------------------------------------------------------17

Uplink Port-------------------------------------------------------------------------20

Monitor Port------------------------------------------------------------------------25

View Configuration---------------------------------------------------------------27

Restore To Factory Default----------------------------------------------------27

Switch Operation-----------------------------------------------------------28

Troubleshooting--------------------------------------------------30

Technical Specifications---------------------------------------31

RJ-45 Pin Specification----------------------------------------32

iii

Package List

Check the contents of your package for following parts:

l16/24 Port 10/100Mbps Switch

lUser's manual

lPower cord

l19” rack mount brackets.

lRS232 cable

If any of these pieces are missing or damaged, please contact your

dealer immediately, if possible, retain the carton including the original

packing material, and use them against to repack the product in case

there is a need to return it to us for repair.

INTRODUCTION

The LevelOne GSW-1601/2401TX 16/24 Port 10/100/1000Mbps

Switch with Gigabit option is designed to allow simultaneous

transmission of multiple packets via an internal high-speed data

channel. This means that it can partition a network more efficiently than

bridges or routers in most environments.

The LevelOne GSW-1601/2401TX 16/24 Port 10/100/1000Mbps

Switch with Gigabit option is equipped with Category 5 copper cable or

fiber optic cable for uplinking to a network backbone or network server.

It is compatible with all 10Mbps, 100Mbps and 1000Mbps Ethernet

environments. The increased speed and extra bandwidth offered by

Gigabit Ethernet will support faster and more users applications with

generating more traffic.

In addition, the LevelOne GSW-1601/2401TX 16/24 Port

10/100/1000Mbps Switch with Gigabit option is also support one

module slot for 2 Ethernet Gigabit ports to uplink to a server or network

backbone. These Gigabit Switches are designed for Plug and Play

installation, allows the network administrator to simply connect the

network and power cables and the Switching/bridging functions begin

automatically.

The front panel of these Gigabit Switches provide LEDs for easy

recognition of the switch operation status and for troubleshooting.

These LEDs display the power status for the system and link/speed/

collision, full-duplex, transmit and receive status for each port.

The built-in console interface can be used to configure the Switch’s

setting for Priority queuing, VLAN, and Port Trunk Groups, Port

Monitoring and Port Speed.

Features

lComplies with the IEEE802.3 Ethernet, IEEE802.3u Fast Ethernet

and IEEE802.3z/ IEEE802.3ab Gigabit Ethernet standard

lProvide a module slot for 2-port 10/100/1000T Gigabit Module

(copper model: MDU-0201T) and 2-port 1000SXGigabit Fiber

Module (fiber model: MDU-0200SX) option

lFeatures Store-and-Forward mode with wire-speed filtering and

forwarding rates

lFull/ Half-Duplex capability on each TX port, full duplex only on

1000Base-TX port

lAutomatic source address learning and aging.

lSupport up to 16K MAC address

lSupport up to total 64Mbit(16+2G), and 80Mbit (24+2G) packet

buffers

lIEEE802.3x compliant full-duplex flow control, half-duplex flow

control

lBroadcast storm control, runt and CRC Filtering eliminates

erroneous packets to optimize the network bandwidth

lSupport to handle up to 1536 bytes packet

lInternal power supply

lLED indicators for simple diagnostics and management

lAuto MDI/ MDI-X on all 10/100/1000Base TX ports

lSupport one console port for switch configuration change

lSupport per port Port-based VLAN and L2 Trunking with link

fail-over

lSupport IEEE802.1p four Priority queues on each port

IDENTIFYING EXTERNAL COMPONENTS

This product series provide three different running speed –10Mbps,

100Mbps, and 1000Mbps in the same hub and automatically

distinguish the speed of incoming connection.

This section describes the hardware features of these Gigabit

Switches. For easier management and control of the switch, familiarize

yourself with its display indicators, and ports. Front panel illustrations

in this chapter display the unit LED indicators. Before connecting any

network device to the hub, read this chapter carefully

There are two different module for expansion:

l2 Port 10/100/1000T Gigabit Module

l2 Port 1000SX Gigabit Fiber Module

Front Panel

The unit front panel provides a simple interface monitoring the

switching hub. It includes a power indicator for each port.

16 Port 10/100Mbps Switch with Gigabit option

24Port 10/100Mbps Switch with Gigabit option

16 Port 10/100Mbps Switch front panel

24 Port 10/100Mbps Switch front panel

2 Port 10/100/1000T Gigabit Module

Front Panel

2 Port 1000SX Gigabit Fiber Module

Front Panel

LED Indicator Panel

Refer to the next chapter for detailed information about each of

the switch’s LED indicators.

Twisted-Pair Ports

Use any of these ports to connect stations or hubs to the

switch. These ports are MDI-X ports, which means you can

use ordinary straight-through twisted-pair cable to connect the

switch to PCs, workstations, or servers through these ports.

If you need to connect to another device with MDI-X ports such

as another switch or hub, you should use a crossover cable, or

connect using the Uplink port (described below).

Rear Panel

16/24 Port 10/100/1000Mbps Switch with Gigabit option

AC Power Connector:

For the power cord.
