Introduction

Overview

LevelOne HomePlug Adapter allows you to connect any device

which has an Ethernet port to a HomePlug network. In operation, the

HomePlug Adapter is completely transparent, and simply passes data

between the Ethernet port and the HomePlug network. Any device may

be connected to the HomePlug Adapter's Ethernet port, but a

Windows PC must be used for configuration.

Physical Details

Figure 1: HomePlug Adapter

Front Panel LEDs

Power On - Normal operation.

Off - No power

Homeplug On - The HomePlug network is active. This

means that at least one other HomePlug device

was detected.

Off - HomePlug network is not available - no

other HomePlug devices were detected.

Ethernet On - Ethernet connection is active.

Off - No Ethernet connection.

Flashing - Data is being transmitted or received

via the Ethernet Port.

Rear Panel

The rear panel contains only the AC plug and a sticker containing the

HomePlug adapter's Password. (Each HomePlug device has a unique

Password.)

Setup

Configuration requires the use of a Windows PC. Once configured, any

device may be connected to the HomePlug Adapter's Ethernet port. To

perform configuration, follow this procedure.

1. Connect a standard LAN cable from the HomePlug Adapter's

Ethernet port to your PC.

2. Plug the HomePlug Adapter into a normal AC power point.

3. Wait a few seconds for startup to be completed, and then check

the LEDs

zThe Power LED should be ON.

zThe HomePlug LED will be ON if other HomePlug

devices are detected, otherwise it will be OFF.

zThe Ethernet LED should be ON.

4. Insert the supplied CD-ROM into your Windows PC, and wait for

it to start. If it does not start, locate and run SETUP.EXE.

5. Follow the prompts to install the LevelOne PLI-2020 utility.

6. Once installation is completed, run the LevelOne PLI-2020 utility

program. The first screen (Main Tab) will display all compatible

devices found.

Figure 2: LevelOne PLI-2020 - Main Tab

zIf only one (1) device is found, a connection will

automatically be established, as indicated in the status

area above the "Connect" button.

zIf multiple devices are listed, select the device you wish

to configure, and click the "Connect" button.

7. Once the status area indicates you are connected to the correct

HomePlug device, click the Security tab. You will see a screen

like the example below.

Figure 3: LevelOne PLI-2020 - Security Tab

8. Enter the desired Network Name in the field provided and click

Set Local Device Only or Set All Devices to save this value

to the HomePlug Adapter

zAll HomePlug devices must use the same Network Name,

or they will not be able to communicate with each other.

zOn this screen, you can also click Use Default to use the

HomePlug Adapter's default Network Name.

9. Click Close to exit the LevelOne PLI-2020 utility.

Setup is now complete.

If your PC is not the device you wish to use with the HomePlug

Adapter, connect the Ethernet cable from the HomePlug

Adapter to the desired device.

The HomePlug Adapter is now ready for use.

Operation

Operation is completely automatic, and no user intervention is

required.

If your HomePlug devices have difficulty communicating with each

other, check the following:

zEach HomePlug device must use the same Network Name.

You can use the Security tab of the LevelOne PLI-2020 utility to

assign a Network Name to other HomePlug devices, provided

you know the unique Password for each device. The Password

is normally shown on a sticker on each device. It consists of 4

groups of 4 characters, in the following format:

xxxx-xxxx-xxxx-xxxx

zAll HomePlug devices must have compatible IP addresses. If

you have a DHCP Server to assign an IP address to each

network device, then Windows PCs will self-assign an IP

address, and all Windows PCs should be able to communicate

with each other.Otherwise you need to manually

assign suitable IP address to other network devices.
