LevelOne GSW-2457 Manual de usuario

24-Port Gigabit

Ethernet Switch GSW-2457

Gigabit Speed

GSW-2457 is a 24-port Gigabit Ethernet Switch that

gives you a high-performance, low-cost, easy-to-use,

seamless upgrade to boost your network to 1000

Mbps. Increase the speed of your network backbone

to a massive 48Gbps and bring Gigabit speeds all the

way to your computers.

Control Your Network

With an 8K MAC address table, the GSW-2457 has

no problems remembering where to send the data

packets. Also featuring IEEE 802.3x ow control and

IEEE 802.1p Quality of Service functions so you have

greater control over your networks. The switch also

supports Auto MDI/MDI-X cable detection on all ports

to eliminate the need for crossover or Uplink ports for

an easy plug-and-play installation.

Rack Mountable

This 19 inch rack mountable switch with internal

power is ideal for the professional oce environment.

Key Features

- 24-Port Combo Ethernet Switch for high-

performance oce networks

- Large 48Gbps Switch bandwidth

- Supports Auto-negotiation and Auto-MDI/MDI-X on

all ports

- Support 802.1p QoS

- Store-and-Forward switching architecture

- Compiles with 802.3, 802.3u and 802.3ab standards

- Wire-speed packet ltering and forwarding

- 8K MAC Address and 512KB buer memory

- 19-inch Rack-Mountable

GNC-0105T

32-bit Gigabit Ethernet PCI

Adapter

Works Well With

1. Power LED

2. LAN Port LEDs

3. LAN Ports

4. Internal power socket

H/W Version: 2

USB-0201

USB Gigabit Ethernet Adapter

2 431

www.level1.com

one world_one brand_one level_ Ethernet Switches

Buer

512KB

LED

Power, Link/ Act , 1000Mbps

Power Supply

100-240V ~50/60Hz , 0.6A

Power Consumption

18.6W

Operating Environment

Temperature: 0 to 40°C

Humidity: 10% ~ 90% ( Non-condensing)

Storage: -40°C ~ 70°C

Dimensions (L x W x H)

440mm x 180mm x 44mm

EMI and Safety

CE/ FCC ClassA

Technical Specications

Product Diagram

GSW-2457

Network Interface

Standard Compliance

IEEE 802.3 10-BASE-T Ethernet

IEEE 802.3u 100-BASE-TX

IEEE 802.3ab 1000-BASE-T

IEEE 802.3x Flow Control

IEEE 802.1p QoS

Interface

24 x 10/100/1000Mbps Auto-negotiation, Auto-MDIX ports

Protocol

CSMA/CD

Switching Method

Store-and-Forward switching architecture

MAC Address Table

Jambo Frame

10KB

Internet

Server

Order Information GSW-2457: 24-Port Gigabit Ethernet Switch

Package Contents GSW-2457

Power Cord

Rack-Mount Kit

User Manual

V2.0

All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.

Broadband Router

PCPCPCServerServer
