Kramer VP-690 Manual de usuario

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VP-690

Presentation Switcher/Scaler

P/N: 2900-000704 Rev 6

VP-690 – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Defining the VP-690 Presentation Switcher/Scaler 5

4Installing in a Rack 8

5Connecting the VP-690 9

6Controlling the VP-690 11

6.1 Controlling via the Front Panel Buttons 11

6.2 Using the OSD Menu 11

6.3 Connecting to the VP-690 via RS-232 15

6.4 Controlling via the ETHERNET 15

6.5 Controlling via the Infrared Remote Control Transmitter 17

7Technical Specifications 18

7.1 Input Resolutions 19

8RS-232 Communication Protocol 20

Figures

Figure 1: VP-690 Presentation Switcher/Scaler Front Panel 6

Figure 2: VP-690 Presentation Switcher/Scaler Rear Panel 7

Figure 3: Connecting the VP-690 Presentation Switcher/Scaler 10

Figure 4: Local Area Connection Properties Window 16

Figure 5: Internet Protocol (TCP/IP) Properties Window 16

Figure 6: Infrared Remote Control Transmitter 17

VP-690 – Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined by

function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Video Products.

Congratulations on purchasing your Kramer VP-690 Presentation Switcher/Scaler.

This product, which incorporates HDMI™ technology, is ideal for:

Projection systems in conference rooms, boardrooms, hotels and churches

Home theater up-scaling

VP-690 - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com to check for up-to-date user

manuals, application programs, and to check if firmware upgrades

are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VP-690 away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VP-690 – Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Do not open the unit. High voltages can cause electrical

shock! Servicing by qualified personnel only

Warning:

Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims

to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country go

to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VP-690 - Overview

3 Overview

The Kramer VP-690 is a high quality presentation switcher and scaler. It accepts

one of nine inputs: one SD/HD/3G HD-SDI signal, two HDMI signals, two computer

graphics signals on 15-pin HD connectors, two composite video signals on RCA

connectors and two component video (also known as Y, Pb, Pr, Y, Cb, Cr and YUV;

compatible with both SD and HD component ) signals on RCA connectors. It scales

the video, embeds the audio, and outputs the signal to the HDMI output as well as

to a computer graphics output and an RGBHV video output together with a digital

audio output and an analog stereo audio output.

The VP-690 is HDTV compatible and the resolution can be up- or down-scaled as

follows: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, WXGA, WSXGA, WUXGA,

NATIVE, VGA, SVGA, XGA, SXGA UXGA, 1280x800, WXGA+, 1600x900,

2048x1080@50 and 2048x1080@60

The VP-690 Presentation Switcher/Scaler:

Has a video bandwidth of up to 2.97Gbps

Is SMPTE 259M, 292M and 424M compliant

Is HDCP Compliant - The HDCP (High Definition Content Protection) license

agreement allows copy-protected data on the HDMI input to pass only to the

HDMI output

Has analog audio inputs which include volume control, and digital (S/PDIF)

and analog stereo audio outputs

Automatically detects and selects the audio source for the HDMI input. Default

selection is HDMI –if this is not present, then the machine uses the audio

from the analog input

Comes with an On-Screen Display (OSD) for easy setup and adjustment,

accessible via the IR remote control and via the front-panel buttons

Has a non-volatile memory that retains the last settings used

Supports firmware upgrade via RS-232

VP-690 – Overview

Control your VP-690:

Directly, via the front panel push buttons

By RS-232 serial commands transmitted by a touch screen system, PC, or

other serial controller

Remotely, from the infrared remote control transmitter

Via the Ethernet

The VP-690 is housed in a 19” 1U rack mountable enclosure, with rack “ears”

included, and is fed from a 100-240V AC universal switching power supply.

3.1 Defining the VP-690 Presentation Switcher/Scaler

This section defines the VP-690.

Figure 1: VP-690 Presentation Switcher/Scaler Front Panel

Feature

Function

IR Receiver

Receives signals from the remote control transmitter

INPUT

SELECTOR

Buttons

Press to select the composite video input (from 1 to 2)

COMPONENT

Press to select the component video input (from 1 to 2)

Press to select the computer graphics input (from1 to 2)

HDMI

Press to select the HDMI input (from 1 to 2)

SDI

Press to select the SDI input

BLANK Button

Press to toggle between a blank screen (blue or black screen) and the display

MUTE Button

Press to toggle between muting (blocking out the sound) and enabling the audio output

FREEZE Button

Press to freeze/unfreeze the output video image

Can be programmed to follow MUTE

MENU Button

Displays the OSD menu (see Section 6.2)

ENTER Button

Press to accept changes and change the SETUP parameters (see Section 6.2)

- Button

Press to decrease numerical values or select from several definitions

When not within the OSD menu mode, press to reduce volume (for embedded HDMI inputs,this doesnot affect the embedded output)

Button

Press to move up the menu list values (see Section 6.2)

+ Button

Press to increase numerical values or select from several definitions

When not within the OSD menu mode, press to increase volume (for embedded HDMI inputs, this does not affect the embedded

output)

Button

Press to move down the menu list (see Section 6.2)

RESET TO XGA/720p

Button

Press to reset the video resolution to XGA or 720p

Press and hold for about 2 seconds to reset to XGA; or press and hold for about 5 seconds to reset to 720p

PANEL LOCK Button

Press and hold (for about 2 seconds) to lock/unlock the front panel buttons

VP-690 –Overview
