USER MANUAL

MODEL:

VS-34FD

Modular Matrix Switcher with I/O Flexible

Module Slots

Kramer Electronics Ltd.

VS-34FD –Contents
i

Contents
Introduction 1
Getting Started 1
Overview 2
Defining VS-34FD Modular Matrix Switcher 4
Mounting VS-34FD 7
Connecting VS-34FD 8
Port Numbering 9
Connecting to VS-34FD via RS-232 10
Connecting to VS-34FD via USB (VCOM) 10
Connecting to VS-34FD via Ethernet 10
Operating and Controlling –Front Panel 13
Starting Up 13
Changing Action Confirmation Mode 14
Switching –Front Panel 14
Locking Front Panel Buttons 17
Copying EDID –Front Panel 17
Restarting –Front Panel 18
Performing Factory Reset –Front Panel 18
Viewing Device Information –Front Panel 18
Operating and Controlling –Embedded Web Pages 19
Browsing Web Pages 20
Switching –Web Pages 22
Copying EDID –Web Pages 28
Configuring Ports 29
Configuring Advanced Port Settings 29
Input / Output Card Hardware Installation Instructions 31
Upgrading VS-34FD Firmware 32
Upgrading Firmware –Embedded Web Pages 32
Upgrading Firmware –K-Upload 32
Default EDID 33
H2-IN2-F34 / H2-OUT2-F34 33
H2A-IN2-F34 / H2A-OUT2-F34 34
DTAxrC2-IN2-F34 / DTAxrC2-OUT2-F34 35
DTAxrD2-IN2-F34 / DTAxrD2-OUT2-F34 37
F676-IN2-F34 / F676-OUT2-F34 38
Technical Specifications 41
VS-34FD Chassis 41
H2-IN2-F34 / H2-OUT2-F34 41
H2A-IN2-F34 / H2A-OUT2-F34 42
DTAxrC2-IN2-F34 / DTAxrC2-OUT2-F34 42
DTAxrD2-IN2-F34 / DTAxrD2-OUT2-F34 43
F676-IN2-F34 / F676-IN2-F34 44
VGAA-IN2-F34 / VGAA-OUT2-F34 45
SDIA-IN2-F34 45
Default Communication Parameters 46
Protocol 3000 47
Understanding Protocol 3000 47
Protocol 3000 Commands 48
Result and Error Codes 60

Kramer Electronics Ltd.

VS-34FD –Introduction

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world

of unique, creative, and affordable solutions to the vast range of problems that confront the

video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we

have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

•Review the contents of this user manual.

Go to www.kramerav.com/downloads/VS-34FD to check for up-to-date user manuals,

application programs, and to check if firmware upgrades are available (where appropriate).

Achieving Best Performance

•Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

•Do not secure the cables in tight bundles or roll the slack into tight coils.

•Avoid interference from neighboring electrical appliances that may adversely influence

signal quality.

•Position your Kramer VS-34FD away from moisture, excessive sunlight and dust.

Safety Instructions

Caution:

•This equipment is to be used only inside a building. It may only be connected to other

equipment that is installed inside a building.

•For products with relay terminals and GPI\O ports, please refer to the permitted rating

for an external connection, located next to the terminal or in the User Manual.

•There are no operator serviceable parts inside the unit.

Warning:

•Use only the power cord that is supplied with the unit.

•Disconnect the power and unplug the unit from the wall before installing.

•Do not open the unit. High voltages can cause electrical shock! Servicing by qualified

personnel only.

•To ensure continuous risk protection, replace fuses only according to the rating

specified on the product label which located on the bottom of the unit.

Kramer Electronics Ltd.

VS-34FD –Introduction

Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce

the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected

and recycled. To comply with the WEEE Directive, Kramer Electronics has made

arrangements with the European Advanced Recycling Network (EARN) and will cover any

costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on

arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular

country go to our recycling pages at www.kramerav.com/support/recycling.

Overview

Congratulations on purchasing your Kramer VS-34FD Modular Matrix Switcher with I/O

Flexible Module Slots.

VS-34FD is a high performance, 34-port, 8K-ready, multi-format, modular matrix switcher for

AV signals, The modular chassis features 17 module card slots for installing a full range of

signal formats. All slots support both input and output module cards, enabling the matrix to be

populated as 2x32, 32x2 or any other configuration in between in increments of two inputs or

two outputs. The chassis includes a control module, a test module that can monitor and test

any input and output in the matrix, and an additional redundant power supply for optional

installation.

Benefits and Features

•High-Performance Modular Matrix Switcher –Professional, 8K-ready matrix for switching

multi-format AV signals. Features Kramer Equalization & re-Klocking™ Technology that

rebuilds the digital signal to travel longer distances.

For optimum range and performance, use recommended Kramer cables.

•Modular & Fully Flexible Platform –Select from a full array of popular and legacy formats

to populate the chassis, including HDMI™, HDBaseT, fiber optic, VGA, SDI, as well as

analog and digital audio. All slots support both input and output slots, enabling the matrix

to be populated as 2 x 32, 32 x 2 or any configuration in between. This matrix is

compatible with existing modular matrix modules.

•Flexible Infrastructure Conversion –Kramer Core™ technology enables copper, fiber or

twisted pair to be used at the same time, according to input/output module selection. The

matrix receives signals from compatible Kramer transmitters, automatically converts

between available infrastructure options and sends the signals to compatible Kramer

receivers.

•Quick and Efficient Management –Compatible with Kramer Network enterprise

management platform providing: Automatic discovery through the network, FW upgrade

management for matrix and cards, identification of card type and location, indication of

card status (module ID, actual firmware versions), matrix switching, specific card

features configuration (for example, volume levels on audio cards), store and recall of

predefined switching scenarios, integrated Maestro automation, and more.

Kramer Electronics Ltd.

VS-34FD –Introduction

•Content Protection Support –HDCP 2.2 compliant, with compatible HDMI, HDBaseT,

fiber optic, VGA, and SDI modules. Supports disabling HDCP when needed.

•Fast Switching Support on Outputs –Reduces or removes switching delay.

•EDID Management –Individual EDID management per input. Captures and stores the

EDID from a display device.

•Second Power Supply –Redundant, hot-swappable for optional installation.

•Flexible Control Options –Local control from the front panel, including switching,

executing multiple switches simultaneously, storage and recall of multiple switching

configurations, front panel lockout. Distance control with user-friendly web GUI via

Ethernet and Protocol 3000 API via Ethernet or RS–232.

•Modular Cooling System –2 easily replaceable, low-noise, hot-swappable fan racks.

•Cost-Effective Maintenance –Power LEDs and LCD display facilitate easy local

maintenance and troubleshooting. Local FW upgrade via mini USB port and reset button

for convenient unit reset ensure lasting, field-proven deployment.

•Easy Installation –19” enclosure for rack mounting in a 3U rack space with included rack

ears and universal 100-240V AC power supply.

Typical Applications

VS-34FD is ideal for the following typical applications:

•Professional display systems requiring video signal routing.

•Broadcast, presentation, and production facilities, as well as monitoring in large

duplication systems.

•Rental/staging applications.

Kramer Electronics Ltd.

VS-34FD –Defining VS-34FD Modular Matrix Switcher

Defining VS-34FD Modular Matrix

Switcher

This section defines VS-34FD.

Figure 1: VS-34FD Modular Matrix Switcher Front Panel

Feature

Function

Numeric Keypad

(When not in menu mode, these

buttons are for numeric input.)

Press 1 to 0 to enter port numbers for routing or to enter values for

navigating the LCD menu.

Press ◄ (backward) to shift the LCD display to the right (the LCD display

only shows 13 of the available matrix combinations).

Press ► (forward) to shift the LCD display to the left (the LCD display only

shows 13 of the available matrix combinations).

Menu Function Buttons

(After pressing the MENU

button four times, these buttons

light and are enabled.)

ALL

Press to switch an input to all outputs (see Switching an Input to

All Outputs –Front Panel on page 16).

OFF

Press to turn off an output.

STO

Press to store the current setup in a preset.

RCL

Press to recall a preset.

EDID

Press to copy an EDID from any input or output to any input

(see Copying EDID –Front Panel on page 17).

DELAY

Press to set the delay between confirming an action and the

execution of the action.

ESC Button

Press to exit the current menu operation.

ENTER Button

Press to complete the input-output setup when using a one-digit number

instead of two digits. For example, to enter input 5, you can press either 05

or 5, ENTER.

Press to enter the options in a setup menu.

10 11115 16

17 18 19 20

12 13 14

8 9

2 3

Kramer Electronics Ltd.

VS-34FD –Defining VS-34FD Modular Matrix Switcher

Feature

Function

EXIT MENU Button

Press to exit a menu or return to switching mode.

DEFAULT SETUP Button

Press to open the reset menu on the display.

TAKE Button

When flashing, press to confirm actions.

MENU Button

Press once to enable the ALL, OFF, STO and RCL buttons.

Press again to enter the configuration menu.

When in a menu, press to cycle through the menu items.

LOCK Button

Press and hold for approximately 2 sec to lock/unlock the front panel

buttons.

OUTPUTS/INPUTS

LCD Display

Displays the outputs (upper row) switched to the selected inputs (lower row).

Displays user interface messages and menus.

SERVICE Mini USB Connector

Use for controlling the matrix switcher and for firmware upgrade

(see Upgrading VS-34FD Firmware on page 32).

POWER LED

Lights yellow when the power supply is active and the device is powered on.

ERROR LED

Lights red when an error is detected. Briefly lights red immediately following

a power disruption (e.g., cable disconnection, power off, and so on).

PS-1 Power Module

Supplies power to the device.

PS-2 Power Module

Supplies power to the device.

Kramer Electronics Ltd.

VS-34FD –Defining VS-34FD Modular Matrix Switcher

Figure 2: VS-34FD Modular Matrix Switcher Back Panel

Feature

Function

PS-2 Power Module and Switch

Connect to the mains power supply (for the PS-1 power module) and use

switch to power the unit.

PS-1 Power Module and Switch

Connect to the mains power supply (for the PS-2 power Module) and use

switch to power the unit.

You can connect PS-1 and/or PS-2.

If one of them fails to operate, the other can power the unit.

48V DC Harness Connector

Connect to the PS-4812 PoE power supply add-on.

RS-232 9-pin D-sub Port

Connect to the remote operation PC or a controller.

RESET Recessed Button

Press to reboot the VS-34FD control card.

NET 1 RJ-45 Connector

Connect to a PC or controller via the Ethernet LAN (100Mb).

NET 2-1G RJ-45 Connector

Connect to a PC or controller via the Ethernet LAN (100/1000Mb).

IN/OUT Connector Cards

(2x17)

Insert an input or output card and connect sources/acceptors to the HDMI™

and/or AUDIO 3.5mm mini jacks to create a flexible matrix switcher (ranging

from 2x32 to 32x2).

Different card types are available.

Each port in a card operates independently.

Card slots support hot-plug connection, so the device immediately

identifies a card as IN or OUT.

AUDIO 3.5mm mini jacks can be set as inputs or outputs (the output is

the HDMI audio embedded audio) when a source/acceptor is connected.

The port numbers are fixed. Each card has 2 ports and they are

numbered accordingly (for example, in the card located under 19-20, the top

port is 19 and the lower one is 20).

21 22 26

24 2825

ININ IN IN IN IN IN INOUT OUT OUT OUT OUT OUT OUT OUT OUTCTRL

2723

48V

Kramer Electronics Ltd.

VS-34FD –Mounting VS-34FD

Mounting VS-34FD

This section provides instructions for mounting VS-34FD. Before installing, verify that the

environment is within the recommended range:

•Operation temperature –0to 40C (32 to 104F).

•Storage temperature –-40to +70C (-40 to +158F).

•Humidity –10% to 90%, RHL non-condensing.

Caution:

•Mount VS-34FD before connecting any cables or power.

Warning:

•Ensure that the environment (e.g., maximum ambient temperature & air flow) is compatible for

the device.

•Avoid uneven mechanical loading.

•Appropriate consideration of equipment nameplate ratings should be used for avoiding

overloading of the circuits.

•Reliable earthing of rack-mounted equipment should be maintained.

To mount the VS-34FD in a rack:

Attach both rack ears by removing the screws from each side of the

machine and replacing those screws through the rack ears or place the

machine on a table.

For more information go to www.kramerav.com/downloads/VS-34FD

Kramer Electronics Ltd.

VS-34FD –Connecting VS-34FD

Connecting VS-34FD

Always switch OFF the power on each device before connecting it to your VS-34FD.

Figure 3: Connecting to the VS-34FD Rear Panel

For optimum range and performance use the recommended Kramer cables available at

www.kramerav.com/product/VS-34FD.

Using third-party cables may cause damage!

The configuration of HDMI input/output cards shown in (Figure 3) is merely a sample

representation and different input / output cards may be mixed as required. For card

installation instructions, see Input / Output Card Hardware Installation Instructions

on page 31.

To connect the VS-34FD as illustrated in the example in Figure 3:

1. Insert the input and output cards into the card slots .

2. Connect 32 video sources (for example, a Blu-ray player and media player) and 2 video

acceptors, (for example, a video display and a projector), 2 video sources and 2 video

acceptors, or any configuration in between.

3. If required, connect a PC or remote controller to the RS-232 port (see Connecting to

VS-34FD via RS-232 on page 10) and/or the Ethernet port (see Connecting to VS-34FD

via Ethernet on page 10).

4. Connect the power cord.

5. If necessary, review and set the system configuration using the Menu (see Using the

Configuration Menus on page 24).

Otros manuales para VS-34FD

Tabla de contenidos

Otros manuales de Cambiar de Kramer

Kramer

Kramer VP-81SID Manual de usuario

Kramer

Kramer ASPEN-32UFX Manual de usuario

Kramer

Kramer VS-120 Manual de usuario

Kramer

Kramer VP-311DVI Manual de usuario

Kramer

Kramer ScaleMagix 2 VP-740HC Manual de usuario

Kramer

Kramer VP-443 Manual de usuario

Kramer

Kramer FC-46xl Manual de usuario

Kramer

Kramer ProScale VP-728 Manual de usuario

Kramer

Kramer VS-21HDCP Manual de usuario

Kramer

Kramer VS-33V Manual de usuario

Kramer

Kramer VP-445 Manual de usuario

Kramer

Kramer VP-773 Manual de usuario

Kramer

Kramer RC-10TBB Manual de usuario

Kramer

Kramer DIP-31M Manual de usuario

Kramer

Kramer VIA CONNECT PRO Manual de usuario

Kramer

Kramer VS-801USB Manual de usuario

Kramer

Kramer VS-41DVI-R Manual de usuario

Kramer

Kramer VS-41HC Manual de usuario

Kramer

Kramer VP-23N Manual de usuario

Kramer

Kramer VP-436N Manual de usuario

Kramer

Kramer VS-81DVI-R Manual de usuario

Kramer

Kramer VS-211XS Manual de usuario

Kramer

Kramer VP-81 Manual de usuario

Kramer

Kramer VS-211HA Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
