USER MANUAL

MODEL:

VP-445

Presentation Switcher/Scaler

P/N: 2900-300502 Rev 3 www.KramerAV.com

VP-445 – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Defining the VP-445 Presentation Switcher/Scaler 5

4Installing in a Rack 8

5Connecting the VP-445 9

5.1 Connecting the Balanced Stereo Audio Output 11

5.2 Microphone Pinout 11

6Controlling the VP-445 12

6.1 Controlling via the Front Panel Buttons 12

6.2 Using the OSD Menu 12

6.3 Connecting to the VP-445 via RS-232 16

6.4 Operating via Ethernet 16

6.5 Using the Infrared Remote Control Transmitter 20

7Using the Embedded Web Pages 21

7.1 Browsing the VP-445 Web Pages 21

7.2 Input Select Page 22

7.3 Device Settings Page 25

7.4 Output Settings Page 28

7.5 HDCP Page 29

7.6 EDID Page 30

7.7 Audio Page 33

7.8 Advanced Page 34

7.9 RS-232 Page 35

7.10 About Page 36

8Technical Specifications 37

8.1Default Communication Parameters 38

8.2 Input Resolutions 38

9The RS-232/Ethernet (TCP) Communication Protocol 39

9.1 Understanding Protocol 3000 40

9.2 Kramer Protocol 3000 Syntax 42

9.3 Protocol 3000 Commands 43

9.4 Kramer Protocol 3000 –Command Keys 66

Figures

Figure 1: VP-445 Presentation Switcher/Scaler Front Panel 6

Figure 2: VP-445 Presentation Switcher/Scaler Rear Panel 7

Figure 3: Connecting the VP-445 Presentation Switcher / Scaler 10

Figure 4: Connecting the Balanced Stereo Audio Output 11

Figure 5: Connecting an Unbalanced Stereo Audio Acceptor to the Balanced Output 11

Figure 6: Condenser Microphone Pinout 11

Figure 7: Dynamic Microphone Pinout 11

Figure 8: Talkover Mode 14

VP-445 - Introduction

Figure 9: Local Area Connection Properties Window 17

Figure 10: Internet Protocol Version 4 Properties Window 18

Figure 11: Internet Protocol Version 6 Properties Window 18

Figure 12: Internet Protocol Properties Window 19

Figure 13: Infrared Remote Control Transmitter 20

Figure 14: Input Select Page 22

Figure 15: VP-445 Standby Mode 23

Figure 16: HDMI Input Edit Window 23

Figure 17: PC and CV Input Edit Window 24

Figure 18: Device Settings Page 25

Figure 19: Device Settings Page –Static IP Confirmation. 25

Figure 20: Device Settings Page –Uploading the New Firmware File 26

Figure 21: Device Settings Page –Uploading Process 27

Figure 22: Device Settings Page –New Firmware Updated 27

Figure 23: Output Settings Page 28

Figure 24: HDCP Page 29

Figure 25: EDID Page 30

Figure 26: EDID Page –Copying a Selected Input Resolution 31

Figure 27: EDID Page –Copying EDID Results 31

Figure 28: EDID Page –Copying EDID from an Output 32

Figure 29: Audio Page 33

Figure 30: Advanced Page 34

Figure 30: RS-232 Page 35

Figure 30: RS-232 Page –Writing a Command 36

Figure 33: RS-232 Page –Adding the Command 36

Figure 31: About Page 36

VP-445 –Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined by

function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer VP-445 Presentation Switcher/Scaler.

This product, which incorporates HDMI™ technology, is ideal for:

Projection systems in conference rooms, boardrooms, hotels and churches.

Home theater up-scaling.

VP-445 - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to www.kramerav.com/downloads/VP-445 to check for up-to-date user

manuals, application programs, and to check if firmware upgrades are

available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables).

Do not secure the cables in tight bundles or roll the slack into tight coils.

Avoid interference from neighbouring electrical appliances that may adversely

influence signal quality.

Position your Kramer VP-445 away from moisture, excessive sunlight and

dust.

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VP-445 –Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Do not open the unit. High voltages can cause electrical

shock! Servicing by qualified personnel only

Warning:

Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims

to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country go

to our recycling pages at www.kramerav.com/support/recycling/.
